Summary of Contents for Intermec CK70

  • Page 1 CK 70 |CK 71 Back Accessory Interface (BAI) Integration Guide...
  • Page 2 The information contained herein is provided solely for the purpose of allowing customers to operate and service Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation.
  • Page 3: Table Of Contents

    After Installing the Data Collection Resource Kit ........11 CK70 and CK71 Back Accessory Interface (BAI) Integration Guide...
  • Page 4 CK70 and CK71 Back Accessory Interface (BAI) Integration Guide...
  • Page 5: About This Integration Guide

    About This Integration Guide This guide provides information about the Back Accessory Interface (BAI) for the Intermec CK70 and CK71 Mobile Computers. Use this guide to understand the BAI and to help develop BAI-compatible adapter accessories. For more information, or if you would like to continue with this development, contact Intermec Product Support.
  • Page 6 Output logic - high I/O_Voltage - 0.4 Output logic - low 0.4 V 5 - OTB_I/O_Voltage Voltage range 1.65 V 5.5 V Current consumption 5 uA Signals active from I/O voltage 12 nS CK70 and CK71 Back Accessory Interface (BAI) Integration Guide...
  • Page 7: Mechanical Specifications

    8 - OTB_CTS Output logic - high I/O_Voltage - 0.4 Output logic - low 0.4 V Note: All signal directions are referenced from the mobile computer. Mechanical Specifications BAI Front and Side Views CK70 and CK71 Back Accessory Interface (BAI) Integration Guide...
  • Page 8: Accessory Attachment

    Accessory Attachment For more information on mating surfaces and dimensions, contact Intermec Product Support. The Product Support team will assist in providing 3D CAD files in .stp format of the CK70 or CK71 mobile computer, and software related information. Installation You can attach your adapter accessory to the BAI by sliding it into the notch at the bottom of the mobile computer, and securing it with an 8-32 UNC screw.
  • Page 9: Magnet Specifications

    IrDA can still communicate wirelessly. To configure the COM Port 1 Tap Start > Settings > System > Intermec Settings > Communications > Serial Port Switch > select COM5 back accessory. 2 When prompted to save and reboot, tap ok.
  • Page 10: About The Data Collection Resource Kit

    Downloads page appears. The “Developer Tools” section includes a list of the Resource Kits. 3 Click IDL Resource Kit - Data Collection ver. x.xx.xx.xxxx and follow the prompts to install it. When the process is complete, the window closes automatically. CK70 and CK71 Back Accessory Interface (BAI) Integration Guide...
  • Page 11: After Installing The Data Collection Resource Kit

    You can find shortcuts to documents, example folders, and other information for the resource kits in this location on your desktop PC: Start > All Programs > Intermec > Resource Kits. You can also double-click the IDL Resource Kits icon on your desktop to browse the Resource Kit installation.
  • Page 12 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2013 Intermec Technologies Corporation. All rights reserved. CK70 and CK71 Back Accessory Interface (BAI) Integration Guide *944-634-002* P/N 944-634-002...
