  • Page 1 UPER ® SC119 Chassis Series SC119TQ-R700UB SC119TQ-R700WB USER’S MANUAL 1.0a...
  • Page 2 SC119 Chassis Manual The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SC119 1U chassis. Installation and maintenance should be performed by experienced technicians only. This manual lists compatible parts available when this document was published. Always refer to the our web site for updates on supported parts and configurations.

  • Page 4: Manual Organization

    SC119 Chassis Manual Manual Organization Chapter 1 Introduction The first chapter provides a list of the main components included with this chas- sis and describes the main features of the SC119 chassis. This chapter also includes contact information. Chapter 2 Standardized Warning Statements for AC Systems This chapter lists warnings, precautions, and system safety.

  • Page 5: Table Of Contents

    Preface Table of Contents Preface About This Manual ......................iii Chapter 1 Introduction Overview ......................1-1 Shipping List ....................1-1 Chassis Features .................... 1-2 Hard Drives ..................... 1-2 I/O Expansion Slots ..................1-2 Peripheral Drives ..................... 1-2 Other Features ....................1-2 Contacting Supermicro ..................
  • Page 6 SC119 Chassis Manual Chapter 3 Chassis Components Overview ......................3-1 Components ....................3-1 Hard Drives and Peripheral Drives ..............3-1 Backplane ......................3-1 Fans ........................ 3-1 Power Supply ....................3-2 Air Shroud ....................... 3-2 Where to get Replacement Components ............3-2 Chapter 4 System Interface Overview ......................
  • Page 7 Preface Rack Precautions .................... 6-2 General Server Precautions ................6-2 Rack Mounting Considerations ............... 6-3 Ambient Operating Temperature ..............6-3 Reduced Airflow ..................6-3 Mechanical Loading ................... 6-3 Circuit Overloading ..................6-3 Reliable Ground ..................6-3 Rack Mounting Instructions ................6-4 Identifying the Sections of the Rack Rails ............
  • Page 8 SC119 Chassis Manual Notes viii...

  • Page 9: Chapter 1 Introduction

    Visit the Supermicro web site for the latest shipping lists and part numbers for your particular chassis model at www.supermicro.com. SC119 Chassis Power Model I/O Slots Supply 700W SC119TQ-R700UB 8x SAS/SATA 2x FH, 1x LP (Gold Level) 700W SC119TQ-R700WB 8x SAS/SATA 2x FH, 1x LP...

  • Page 10: Chassis Features

    SC119 Chassis Manual Chassis Features The SC119 1U high-performance chassis includes the following features: Hard Drives The SC119 chassis features eight hard drive bays for 2.5" hot-swappable SAS/ SATA drives. Once setup correctly, these drives can be removed without powering- down the server.

  • Page 11: Contacting Supermicro

    Chapter 1 Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...

  • Page 12: Returning Merchandise For Service

    SC119 Chassis Manual Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required be- fore any warranty service will be rendered. You can obtain service by calling your vendor for a Returned Merchandise Authorization (RMA) number. When returning to the manufacturer, the RMA number should be prominently displayed on the outside of the shipping carton, and mailed prepaid or hand-carried.

  • Page 13: Chapter 2 Standardized Warning Statements For Ac Systems

    Chapter 2: Warning Statements for AC Systems Chapter 2 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 14 SC119 Chassis User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 15 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 16: Installation Instructions

    SC119 Chassis User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 17: Circuit Breaker

    Chapter 2: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 18: Power Disconnection Warning

    SC119 Chassis User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 19 Chapter 2: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 20: Equipment Installation

    SC119 Chassis User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 21: Restricted Area

    Chapter 2: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 22: Battery Handling

    SC119 Chassis User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬...
  • Page 23 Chapter 2: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 24: Redundant Power Supplies

    SC119 Chassis User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 25: Backplane Voltage

    Chapter 2: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 26: Comply With Local And National Electrical Codes

    SC119 Chassis User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 27: Product Disposal

    Chapter 2: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 28: Hot Swap Fan Warning

    SC119 Chassis User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 29 Chapter 2: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 30: Power Cable And Ac Adapter

    SC119 Chassis User's Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
  • Page 31 Chapter 2: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
  • Page 32 SC119 Chassis User's Manual Notes 2-20...

  • Page 33: Chapter 3 Chassis Components

    Chapter 3 Chassis Components Chapter 3 Chassis Components Overview This chapter describes the most common components included with your chassis. Some components listed may not be included or compatible with your particular chassis model. For more information, see the installation instructions detailed later in this manual.

  • Page 34: Power Supply

    SC119 Chassis Manual Power Supply Each SC119 chassis model includes redundant high-efficiency power supplies rated at 700 Watts. In the unlikely event of a power supply failure, the hot-swappable power supply can be replaced without powering-down the system. Air Shroud Air shrouds are shields, usually plastic, that channel air directly to where it is needed.

  • Page 35: Chapter 4 System Interface

    Chapter 4 System Interface Chapter 4 System Interface Overview There are LEDs on the control panel and on the drive carriers that provide system and component status. This chapter explains the meanings of these LED indicators and the appropriate responses that need to be taken. Figure 4-1: Control Panel Buttons and LEDs...

  • Page 36: Control Panel Buttons

    SC119 Chassis Manual Control Panel Buttons The SC119 chassis includes three push-buttons located on the front panel: a reset button, a power on/off button, and a UID button UID: When used with a UID-compatible motherboard, the UID button is used to turn on or off the blue light function of the the U-LED.

  • Page 37: Control Panel Leds

    Chapter 4 System Interface Control Panel LEDs The control panel located on the front of the SC119 chassis has five LEDs. These LEDs provide critical information related to different parts of the system. This sec- tion explains what each LED indicates when illuminated and any action that may be required.

  • Page 38: Drive Carrier Leds

    SC119 Chassis Manual Drive Carrier LEDs The SC119 chassis uses SAS/SATA hard drives. SAS/SATA Drives Each SAS/SATA drive carrier has two LEDs. • Green: Each Serial ATA drive carrier has a green LED. When illuminated, this green LED (on the front of the SATA drive carrier) indicates drive activity. A con- nection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed.

  • Page 39: Chapter 5 Chassis Setup And Maintenance

    Chapter 5 Chassis Setup and Maintenance Chapter 5 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform main- tenance on the chassis. The only tool needed to install components and perform maintenance is a Phillips screwdriver. Review the warnings and precautions listed in the manual before setting up or servicing this chassis.

  • Page 40: Removing The Chassis Cover And Front Bezel

    SC119 Chassis Manual Removing the Chassis Cover and Front Bezel Figure 5-1: Removing the Chassis Cover Removing the Chassis Cover: 1. Power down the system and disconnect the power cords from the rear of the power supplies. 2. Remove the screws securing the top cover to the chassis. 3.

  • Page 41: Installing Hard Drives

    Chapter 5 Chassis Setup and Maintenance Installing Hard Drives Figure 5-2: Removing a Hard Drive The SC119 chassis supports eight hot-swappable hard drives, so it is not necessary to power-down the server when replacing hard drives. Only enterprise level SAS or SATA hard drives are recommended for use in Supermicro chassis.
  • Page 42 SC119 Chassis Manual Figure 5-3: Hard Drive Carrier Installing a Hard Drive into a Drive Carrier 1. Remove the dummy drive which comes pre-installed in the drive carrier, by removing the screws securing the dummy drive to the carrier. 2. Insert a hard drive into the carrier with the PCB side facing down and the connector end toward the rear of the carrier.

  • Page 43: Dvd-Rom Drive Installation

    Chapter 5 Chassis Setup and Maintenance DVD-ROM Drive Installation The SC119 chassis models support an optional DVD-ROM. Installing or Replacing a DVD-ROM Drive 1. Power down the system and disconnect the power cords from the rear of the power supplies. Remove the chassis cover as described in Section 5-2. 2.

  • Page 44: Removing The Backplane

    SC119 Chassis Manual Removing the Backplane The SC119 chassis backplane is located behind the hard drives and in front of the front system fans. In order to change jumper settings on the backplane, it may be necessary to remove the backplane from the chassis. Removing the Backplane from the Chassis 1.

  • Page 45: Backplane Installation

    Chapter 5 Chassis Setup and Maintenance Backplane Installation Installing the Backplane 1. Slide the backplane into the chassis as shown, inserting the lower edge of the backplane into the clips on the floor of the chassis. 2. Align the mounting holes in the backplane with the mounting holes in the chassis.

  • Page 46: Installing The Motherboard

    SC119 Chassis Manual Installing the Motherboard Optional Standoff Figure 5-7: Chassis Standoffs Permanent and Optional Standoffs Standoffs prevent short circuits by creating space between the motherboard and the chassis surface. The SC119 chassis includes permanent standoffs in locations used by most motherboards. These standoffs accept the rounded Phillips head screws included in the SC119 accessories packaging.

  • Page 47: Motherboard Installation

    Chapter 5 Chassis Setup and Maintenance Motherboard Installation Installing the Motherboard 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, and precautions. 2. Power down the system and disconnect the power cords from the rear of the power supplies.

  • Page 48: Expansion Card Setup

    SC119 Chassis Manual Expansion Card Setup SC119 chassis includes I/O slots for expansion cards. The SC119-R700UB is a "U" model chassis which includes one low-profile and two full-height PCI slots for expansion cards. Note: A riser card must be used to install expansion cards into any SC119 chassis. Riser cards are sold separately.
  • Page 49 Chapter 5 Chassis Setup and Maintenance Riser Card Riser Card Figure 5-10: Installing a Riser Card Installing Expansion and Riser Cards 1. Confirm that you have the correct riser card for your chassis model and the expansion card includes a standard bracket. 2.
  • Page 50 SC119 Chassis Manual Figure 5-11: Expansion Card Bracket Installation 6. From inside the chassis, remove the PCI slot cover. 7. Slide the expansion card into the riser card. Figure 5-12: Add-On Card Installation 8. Attach the expansion card bracket in place of the I/O panel. 9.

  • Page 51: Installing The Air Shroud Optional

    Chapter 5 Chassis Setup and Maintenance Installing the Air Shroud (Optional) Air shrouds concentrate airflow to maximize fan efficiency. The SC119 chassis air shroud does not require screws to set up. Notch Screw Figure 5-13: Air Shroud Installation Air Shroud Installation 1.

  • Page 52: Checking The Air Flow

    SC119 Chassis Manual Checking the Air Flow Check the Airflow 1. Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.

  • Page 53: System Fans

    Chapter 5 Chassis Setup and Maintenance System Fans Figure 5-14: System Fans in the Fan Tray (Optional Sixth Fan Shown in Illustration) Five heavy-duty fans provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the chassis' internal temperature. The SC119 chassis contains counter-rotating fans.
  • Page 54 SC119 Chassis Manual Figure 5-15: Chassis Fans Replacing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan has failed. Never run the server for an extended period of time with the chassis open.

  • Page 55: 5-10 Power Supply

    Chapter 5 Chassis Setup and Maintenance 5-10 Power Supply The SC119 chassis includes redundant 700W power supplies. These power supplies are auto-switching capable. The power supply automatically senses and operates at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
  • Page 56 SC119 Chassis Manual Notes 5-18...

  • Page 57: Chapter 6 Rack Installation

    Chapter 6 Rack Installation Chapter 6 Rack Installation Overview This chapter provides a quick setup to install the chassis into a rack. Following these steps in the order given should enable you to have the system installed within a minimal amount of time. Unpacking the System You should inspect the box the chassis was shipped in and note if it was damaged in any way.

  • Page 58: Rack Precautions

    SC119 Chassis Manual Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installation, stabilizers should be attached to the rack. •...

  • Page 59: Rack Mounting Considerations

    Chapter 6 Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 60: Rack Mounting Instructions

    SC119 Chassis Manual Rack Mounting Instructions This section provides information on installing the SC119 chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will vary slightly. Refer to the installation instructions that came with the rack unit.

  • Page 61: Inner Rail Extension (Optional)

    Chapter 6 Rack Installation Figure 6-2: Identifying the Sections of the Rack Rails (right side rail shown) Inner Rail Extension (Optional) The SC119 chassis includes a set of inner rails in two sections: Inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack.

  • Page 62: Outer Rails

    SC119 Chassis Manual Attach Outer RailsTogether Secure to the Rear Secure to the of the Rack Front of the Rack Figure 6-3: Assembling the Outer Rails Outer Rails Installing the Outer Rails to the Rack 1. Attach the shorter outer rail to the outside of the longer outer rail. You must align the pins with the slides.
  • Page 63 Chapter 6 Rack Installation Figure 6-5: Installing the Rack Rails Note: figures are for illustrative purposes only. Servers should always be installed in racks from the bottom up. Installing the Chassis into a Rack 1. Confirm that chassis includes the inner rails and rail extensions, and confirm that the outer rails are installed on the rack.

  • Page 64: Installing The Chassis Into A Telco Rack

    SC119 Chassis Manual Installing the Chassis into a Telco rack Installing the Chassis into a Telco Rack 1. Locate the two L-shaped brackets (four total). 2. Determine how far the server will extend out the front of the rack. Larger chassis should be positioned to balance the weight between front and back.

  • Page 65: Appendix A Sc119 Chassis Cables

    This appendix lists supported cables for your system. It only includes the most commonly used components and configurations. For more compatible cables, refer to the manufacturer of the motherboard you are using and our Web site at: www. supermicro.com. A-2 Included SAS/SATA Cables SC119TQ-R700UB, SC119TQ-R700WB Part # Type Length Description...
  • Page 66 SC119X Chassis Manual A-3 Compatible Cables These cables are compatible with the SC119X chassis. This section lists cables included with the SC119X chassis packages. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables.
  • Page 67 Appendix A Chassis Cables Extending Power Cables Although Supermicro chassis are designed with to be efficient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the moth- erboards.
  • Page 68 SC119X Chassis Manual Notes...

  • Page 69: Appendix B Sc119 Power Supply Specifications

    Appendix B Power Supply Specifications Appendix B SC119 Power Supply Specifications This appendix lists power supply specifications for your chassis system. SC119TQ-R700UB, SC119TQ-R700WB 700W (80 PLUS Gold Certified) MFR Part # PWS-704P-1R 700W: 100 - 140 V, 50-60 Hz, 8.5 - 6 Amps AC Voltage 750W: 180 - 240 V, 60-50 Hz, 5 - 3.8 Amps...
  • Page 70 SC119X Chassis Manual Notes...

  • Page 71: Appendix C Sas-113Tq Backplane Specifications

    Appendix C SAS-113TQ Backplane Specifications Appendix C SAS-113TQ Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
  • Page 72 SC113 Chassis Manual C-3 An Important Note to Users All images and layouts shown in this user's guide are based upon the latest back- plane revision available at the time of publishing. The card you have received may or may not look exactly the same as the graphics shown in this manual. C-4 Introduction to the SAS-113TQ Backplane The SAS-113TQ backplane has been designed to utilize the most up-to-date tech- nology available, providing your system with reliable, high-quality performance.
  • Page 73 Appendix C SAS-113TQ Backplane Specifications Connectors, Jumpers and LEDs Front Connectors +12V +12V 9072 RST UPGRADE J P46 M H3 M H4 M H2 J P52 SB#2 SB#1 J P33: M ODE SEL J P29 1- 2: SGPI O J P13 2- 3: I 2C I 2C#2 J P45...
  • Page 74 SC113 Chassis Manual Front Connector and Pin Definitions #1. Backplane Main Power Connectors Backplane Main Power The 4-pin connectors designated JP10, provide 4-Pin Connector power to the backplane. See the table on the Pin# Definition right for pin definitions. +12V 2 and 3 Ground #2 Upgrade Connector...
  • Page 75 Appendix C SAS-113TQ Backplane Specifications #6 and #7. I C Connectors C Connector Pin Definitions The I C connectors, designated JP44 and Pin# Definition JP45, are used to monitor HDD activity and Data status. See the table on the right for pin Ground definitions.

  • Page 76: Explanation Of Jumpers

    SC113 Chassis Manual Front Jumper Locations and Settings JP29 JP33 JP18 +12V +12V 9072 RST UPGRADE J P46 M H3 M H4 M H2 SB#2 J P52 SB#1 J P33: M ODE SEL J P29 1- 2: SGPI O J P13 2- 3: I 2C I 2C#2 J P45...
  • Page 77 Appendix C SAS-113TQ Backplane Specifications C and SGPIO Modes and Jumper Settings This backplane can utilize I C or SGPIO. SGPIO is the default mode and can be used without making changes to your jumpers. The following information details which jumpers must be configured to use I C mode or restore your backplane to SGPIO mode.
  • Page 78 SC113 Chassis Manual Rear Connectors and LED Indicators SAS #1 SAS #5 SAS #3 ACT#3 FAIL#1 ACT#0 C106 ACT#6 ACT#2 FAIL#0 FAIL#2 FAIL#6 SAS #4 SAS #2 SAS #0 SAS #6 SAS #7 Figure C-4: Rear Connectors Rear SAS/SATA Connectors Rear Connector SAS/SATA Drive...
  • Page 79 Appendix C SAS-113TQ Backplane Specifications Notes...
  • Page 80 SC113 Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
