Summary of Contents for Supero SC819TQ-R700UB
- Page 1 UPER ® SC819 Chassis Series SC819TQ-R700UB SC819TQ-R700WB USER’S MANUAL 1.0b...
- Page 2 SC819 Chassis Manual The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
- Page 3 Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SC819 1U chassis. Installa- tion and maintenance should be performed by experienced technicians only. Supermicro's SC819 1U chassis features a unique and highly-optimized design for 1U UIO servers.
-
Page 4: Manual Organization
SC819 Chassis Manual Manual Organization Chapter 1 Introduction The first chapter provides a list of the main components included with this chassis and describes the main features of the SC819 chassis. This chapter also includes contact information. Chapter 2 Standardized Warning Statements for AC Systems This chapter lists warnings, precautions, and system safety. -
Page 5: Table Of Contents
Preface Table of Contents Preface About This Manual ......................iii Chapter 1 Introduction Overview ......................1-1 Shipping List ....................1-1 Chassis Features .................... 1-2 CPU ......................... 1-2 Hard Drives ..................... 1-2 I/O Expansion slots ..................1-2 Peripheral Drives ..................... 1-2 Other Features .................... - Page 6 SC819 Chassis Manual Power Supply ....................3-2 Air Shroud (Optional) ..................3-2 Where to get Replacement Components ............3-2 Chapter 4 System Interface Overview ......................4-1 Control Panel Buttons ..................4-2 Control Panel LEDs ..................4-3 Drive Carrier LEDs ..................4-5 SAS/SATA Drives ....................
- Page 7 Preface Optional Inner Rail Extensions ............... 6-5 Appendix A Chassis Cables Appendix B SC819 Power Supply Specifications Appendix C SAS-815TQ Backplane Specifications...
- Page 8 SC819 Chassis Manual Notes viii...
-
Page 9: Chapter 1 Introduction
SC819 Chassis Power Model I/O Slots Supply 4x SAS / SATA 2x FH + 1x LP 700W SC819TQ-R700UB (Gold Level) 4x SAS / SATA 2x FH + 1x LP 700W SC819TQ-R700WB (Gold Level) Legend FH = Full-height, full-length... -
Page 10: Chassis Features
SC819 Chassis Manual Chassis Features The SC819 1U high-performance chassis includes the following features: Motherboards The SC819 chassis supports a single or dual processor motherboard. Please refer to the motherboard specifications pages on our website for updates on supported motherboards. Hard Drives The SC819 chassis features four bays for SAS/SATA drives. -
Page 11: Contacting Supermicro
Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:... -
Page 12: Returning Merchandise For Service
SC819 Chassis Manual Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required be- fore any warranty service will be rendered. You can obtain service by calling your vendor for a Returned Merchandise Authorization (RMA) number. When returning to the manufacturer, the RMA number should be prominently displayed on the outside of the shipping carton, and mailed prepaid or hand-carried. -
Page 13: Chapter 2 Tandardized Warning Statements For Ac Systems
Chapter 2: Warning Statements for AC Systems Chapter 2 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance. - Page 14 SC819 Chassis Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
- Page 15 Warning Statements for AC Systems جسذٌة اصابة ًتتسبب ف حالة ٌوكي أى ًاًك ف خطز ًٌٌع هذا الزهز !تحذٌز الذوائز بالوخاطز الٌاجوة عي ي على علن ، ك هعذات تعول على أي قبل أى الكهزبائٍة حىادث أي وقىع وٌع ل الىقائٍة...
-
Page 16: Installation Instructions
SC819 Chassis Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. -
Page 17: Circuit Breaker
Chapter 2: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、... -
Page 18: Power Disconnection Warning
SC819 Chassis Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A. - Page 19 Chapter 2: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...
-
Page 20: Equipment Installation
SC819 Chassis Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden. -
Page 21: Restricted Area
Chapter 2: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. -
Page 22: Battery Handling
SC819 Chassis Manual אזור עם גישה מוגבלת !אזהרה יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת .)'כלי אבטחה בלבד (מפתח, מנעול וכד محظورة مناطق ٍنتركُبها ف هذه انىحذة تخصيص تم ،أداة خاصت من خالل استخذاو فقط محظورة... - Page 23 Chapter 2: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.
-
Page 24: Redundant Power Supplies
SC819 Chassis Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden. -
Page 25: Backplane Voltage
Chapter 2: Warning Statements for AC Systems امداد الطاقة بوحدات عدة اتصاالت جهاز ال يكون لهذا قد الكهرباء عن وحدة ال لعسل كافة االتصاالت يجب إزالة 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을... -
Page 26: Comply With Local And National Electrical Codes
SC819 Chassis Manual מתח בפנל האחורי !הרה אז קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך .העבודה اللىحة أوالطاقة المىجىدة على التيار الكهزبائي مه خطز هناك هذا الجهاس خدمة كه حذرا عند يعمل النظام عندما يكىن 경고! 시스템이... -
Page 27: Product Disposal
Chapter 2: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. תיאום חוקי החשמל הארצי !אזהרה הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים התקנת المتعلقة المحلية والىطىية قىاويه يجب أن يمتثل لل الكهربائية... -
Page 28: Hot Swap Fan Warning
SC819 Chassis Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. - Page 29 Chapter 2: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.
-
Page 30: Power Cable And Ac Adapter
SC819 Chassis Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. - Page 31 Chapter 2: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
- Page 32 SC819 Chassis Manual Notes 2-20...
-
Page 33: Chapter 3 Chassis Components
Chapter 3: Chassis Components Chapter 3 Chassis Components Overview This chapter describes the most common components included with your chassis. Some components listed may not be included or compatible with your particular chassis model. For more information, see the installation instructions detailed later in this manual. -
Page 34: Air Shroud (Optional)
SC819 Chassis Manual Each SC819 chassis model includes a high-efficiency, hot-swappable power supply rated at 700 Watts. In the unlikely event that your power supply fails, replacement is simple and can be done without tools. Air Shroud (Optional) The SC819 chassis supports an optional air shroud. An air shroud is a shield, usually made of plastic, which funnels air directly to where cooling is needed. -
Page 35: Chapter 4 System Interface
Chapter 4: System Interface Chapter 4 System Interface Overview There are several LEDs on the control panel and on the drive carriers that provide system and component status. This chapter explains the meanings of all LED indi- cators and the appropriate responses that may need to be taken. Figure 4-1. -
Page 36: Control Panel Buttons
SC819 Chassis Manual Control Panel Buttons The SC819 chassis includes two or three push-buttons located on the front panel: a reset button, a power on/off button, and a UID button Reset: The reset button is used to reboot the system. Power: The main power switch is used to apply or remove power from the power supply to the server system. -
Page 37: Control Panel Leds
Chapter 4: System Interface Control Panel LEDs The control panel located on the front of the SC819 chassis has up to five LEDs. These LEDs provide critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any action that may be required. - Page 38 SC819 Chassis Manual NIC2: Indicates network activity on GLAN2 when flashing. NIC1: Indicates network activity on GLAN1 when flashing. HDD: Indicates IDE channel activity. SAS/SATA drive and/or DVD-ROM drive activ- ity when flashing. Power: Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.
-
Page 39: Drive Carrier Leds
Chapter 4: System Interface Drive Carrier LEDs Your chassis uses SAS/SATA drives. SAS/SATA Drives Each SAS/SATA drive carrier has two LEDs. Green: Each Serial ATA drive carrier has a green LED. When illuminated, this green LED (on the front of the SATA drive carrier) indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed. -
Page 40: Overheating
SC819 Chassis Manual Overheating The section lists actions that should be taken in the unlikely event the server overheats. Overheat Temperature Setting Some backplanes allow the overheat temperature to be set at 45, 50, or 55 degrees Farenheit by changing a jumper setting. For more backplane information, see the appendix at the back of this manual or download the backplane user manual at www.supermicro.com. -
Page 41: Chapter 5 Chassis Setup And Maintenance
Chapter 5: Chassis Setup and Maintenance Chapter 5 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform main- tenance on the chassis. The only tool needed to install components and perform maintenance is a Phillips screwdriver. Print this page to use as a reference while setting up your chassis. -
Page 42: Removing The Chassis Cover
SC819 Chassis Manual Removing the Chassis Cover Remove this screw Figure 5-1: Removing the Chassis Cover Removing the Chassis Cover 1. Power down the system and unplug the power cords from the rear of the power supplies. 2. Remove the screw at the rear of the cover. 3. -
Page 43: Installing Hard Drives
Chapter 5: Chassis Setup and Maintenance Installing Hard Drives Figure 5-2: Removing Hard Drive Carriers The SC819 chassis includes hot-swappable hard drives that can be removed from the chassis and reinstalled without powering down the server. Removing Hard Drive Carriers from the Chassis 1. - Page 44 SC819 Chassis Manual Dummy Drive Drive Carrier Figure 5-3: Chassis Drive Carrier The drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow for the drive bays. Warning: Except for short periods of time while swapping hard drives, do not oper- ate the chassis without the drive carriers.
- Page 45 Chapter 5: Chassis Setup and Maintenance SAS/SATA Hard Drive Drive Carrier Figure 5-5: Removing the Hard Drive From the Carrier 3. Install a new drive into the carrier with the printed circuit board side facing down so that the mounting holes in the drive align with those in the carrier. 4.
-
Page 46: Dvd And Usb Com Tray Installation
SC819 Chassis Manual DVD and USB COM Tray Installation SC819 chassis models support an optional DVD-ROM or USB COM tray. Installing or Replacing a DVD-ROM or USB COM Tray 1. Power down the system, remove the power cords from the rear of the power supplies and remove the chassis cover as described in Section 5-3. -
Page 47: Installing The Motherboard
Chapter 5: Chassis Setup and Maintenance Installing the Motherboard Permanent Standoffs Optional Standoffs Figure 5-7: Chassis Standoffs Permanent and Optional Standoffs Standoffs prevent short circuits by securing space between the motherboard and the chassis surface. The SC819 chassis includes permanent standoffs in locations used by most motherboards. - Page 48 SC819 Chassis Manual Motherboard Standoffs Figure 5-8: Installing the Motherboard Installing the Motherboard 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, and precautions. 1. Power down the system, remove the power cords from the rear of the power supplies and remove the chassis cover as described in Section 5-3.
-
Page 49: Expansion Card Setup
Chapter 5: Chassis Setup and Maintenance Expansion Card Setup The SC819 chassis features two full-height/full-length PCI slots and one low-profile PCI slot. Note: You must use a riser card to install expansion cards to any SC819 chassis. Riser cards are sold separately. For the latest compatibility and performance information visit our website at: http://www.supermicro.com. - Page 50 SC819 Chassis Manual Riser Card Riser Card Figure 5-11: Installing a Riser Card Installing an Expansion Card 1. Power down the system, remove the power cords from the rear of the power supplies and remove the chassis cover as described in Section 5-3. Con- firm that you have the correct riser card for your chassis model and that the expansion card includes a standard PCI slot bracket.
-
Page 51: Installing The Air Shroud (Optional)
Chapter 5: Chassis Setup and Maintenance Installing the Air Shroud (Optional) The SC819 chassis supports an optional air shroud. Air shrouds concentrate airflow to maximize fan efficiency. The air shroud does not require screws to set up. Figure 5-12: Installing the Air Shroud Installing the Air Shroud (Optional) 1. -
Page 52: System Fans
SC819 Chassis Manual System Fans Figure 5-13: System Fan Five heavy-duty fans with an optional sixth fan provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the chassis internal temperature. In models with counter-rotating fans, each fan unit is actually made up of two fans joined back-to-back, which rotate in opposite directions. - Page 53 Chapter 5: Chassis Setup and Maintenance Figure 5-14: Chassis Fans (Illustration Shows Optional Sixth Fan) The SC819 chassis includes five pre-installed fans. One extra slot is available so that an additional sixth fan may be added. Replacing a System Fan 1.
-
Page 54: Power Supply
SC819 Chassis Manual Power Supply The SC819 chassis includes a 700 Watt redundant power supply. This power sup- ply is auto-switching capable. The power supply automatically senses and operates at a 100V to 240V input voltage. An amber light will be illuminated on the power supply when the power is off. -
Page 55: Routing The I C Cables
Chapter 5: Chassis Setup and Maintenance Routing the I C Cables It is necessary to correctly route the I C cables to avoid interference due to noise on the I C lines. Using tie wraps, secure the I C cables to the large black power switch- ing cable to keep it close to the power supply and away from the motherboard. - Page 56 SC819 Chassis Manual Notes 5-16...
-
Page 57: Chapter 6 Rack Installation
Chapter 6: Rack Installation Chapter 6 Rack Installation Overview This chapter provides a quick rack setup. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. Unpacking the System You should inspect the box the chassis was shipped in and note if it was damaged in any way. -
Page 58: Rack Precautions
SC819 Chassis Manual Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installations, stabilizers should be attached to the rack. •... -
Page 59: Rack Mounting Considerations
Chapter 6: Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra). -
Page 60: Rack Mounting Instructions
SC819 Chassis Manual Rack Mounting Instructions This section provides information on installing the SC819 chassis into a rack unit. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using. - Page 61 Chapter 6: Rack Installation Optional Inner Rail Extensions Front Inner Rails (Pre-installed on the Chassis) Figure 6-2: Installing the Optional Inner Rail Extensions Optional Inner Rail Extensions The SC819 chassis includes a set of inner rails which are in two sections, front inner rails and optional inner rail extensions.
- Page 62 SC819 Chassis Manual Secure to the Front of the Rack Secure to the Rear of the Rack Attach the Two Sections of the Outer Rail Together Figure 6-3: Assembling the Outer Rails Installing the Outer Rails to the Rack 1. Attach the shorter section of the outer rail to the outside of the longer section of the outer rail.
- Page 63 Chapter 6: Rack Installation Outer Rails Inner Rail Extensions Inner Rails Figure 6-4: Installing the Chassis into a Rack Installing the Chassis into a Rack 1. Confirm that the inner rails and rail extensions have been attached to the chassis. Confirm that the outer rails are installed on the rack. 2.
- Page 64 SC819 Chassis Manual Figure 6-5: Installing the Chassis into the Rack Note: figures are for illustrative purposes only. Servers should always be installed in racks from the bottom up.
- Page 65 This appendix lists supported cables for your chassis system. It only includes the most commonly used components and configurations. For more compatible cables, refer to the manufacturer of the motherboard you are using and our web site at www.supermicro.com. A-2 Cables Included with SC819 Chassis Models SC819TQ-R700UB Part # Type Length Description...
- Page 66 SC819 Chassis Manual A-4 Compatible Cables These cables are compatible with the SC819 chassis. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables.
-
Page 67: Extending Power Cables
SC819 Chassis Manual Extending Power Cables Although Supermicro chassis are designed with to be efficient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the mother boards. - Page 68 SC819 Chassis Manual A-5 Chassis Screws The accessory box includes all the screws needed to set up the chassis. This section lists and describes the most common screws used. Your chassis may not require all the parts listed. HARD DRIVE Flat head Pan head 6-32 x 5 mm...
- Page 69 SC819 Chassis Manual Appendix B SC819 Power Supply Specifications This appendix lists power supply specifications for your chassis system. Power Supply Specifications 700W MFR Part # PWS-703P-1R 700W: 100-140 V, 50-60 Hz, 8.5-6 Amp AC Input 750W: 180-240 V, 60-50 Hz, 5-3.8 Amp DC Output 3 Amp +5V standby...
- Page 70 SC819 Chassis Manual Notes...
- Page 71 Appendix C: SAS-815TQ Backplane Specifications Appendix C SAS-815TQ Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam- age to your system, it is important to handle it very carefully.
- Page 72 SC819 Chassis Manual C-3 An Important Note to Users All images and layouts shown in this user's guide are based upon the latest PCB Revision available at the time of publishing. The card you have received may or may not look exactly the same as the graphics shown in this manual. C-4 Introduction to the SAS-815TQ Backplane The SAS-815TQ backplane has been designed to utilize the most up-to-date tech- nology available, providing your system with reliable, high-quality performance.
- Page 73 Appendix C: SAS-815TQ Backplane Specifications C-5 Front Connectors JP29:9071 RST JP18:BUZZER RESET JP40 JP42 JP51 SAS815TQ JTAG UPGRADE UPER JP29 JP18 JP33 JP34 REV 1.00 M9 M15 SIDEBAND +12V JP47 JP10 +12V +12V JP26 JP44 ACT IN ACT0 ACT1 ACT2 ACT3 Figure C-1: Front Connectors Front Connectors and Components 1.
- Page 74 SC819 Chassis Manual C-6 Front Connector and Pin Definitions 1. Backplane Main Power Connectors Backplane Main Power The 4-pin connectors, designated JP10 provide 4-Pin Connector power to the backplane. See the table on the Pin# Definition right for pin definitions. +12V 2 and 3 Ground...
- Page 75 Appendix C: SAS-815TQ Backplane Specifications 6. Sideband Headers Sideband Headers The sideband headers are designated JP51. Pin # Definition Pin # Definition For SES-2 to work properly, you must connect Backplane Controller an 8-pin sideband cable. See the table to the Addressing ID (SB6) (SB5)
-
Page 76: Explanation Of Jumpers
SC819 Chassis Manual C-7 Front Jumper Locations and Pin Definitions JP29 JP18 JTAG UPGRADE JP29:9071 RST JP18:BUZZER RESET JP40 JP42 JP51 UPER SAS815TQ JP29 JP18 JP33 REV 1.00 JP34 M9 M15 SIDEBAND +12V JP47 JP10 +12V +12V JP26 JP44 ACT IN ACT0 ACT1 ACT2 ACT3... - Page 77 Appendix C: SAS-815TQ Backplane Specifications C and SGPIO Modes and Jumper Settings This backplane can utilize I C or SGPIO. I C is the default mode and can be used without making changes to your jumpers. The following information details which jumpers must be configured to use SGPIO mode or restore your backplane to I2C mode.
- Page 78 SC819 Chassis Manual C-8 Rear Connectors and LED Indicators H 2 M 4 M 9 M 1 Figure C-5: Rear Connectors and LED Indicators Rear SAS/SATA Connectors Rear Connector SAS Drive Connector Number Number SAS #0 SAS/SATA HDD #0 SAS #1 SAS/SATA HDD #1 SAS #2 SAS/SATA HDD #2...
- Page 79 Appendix C: SAS-815TQ Backplane Specifications Notes...
- Page 80 SC819 Chassis Manual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life sup- port systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to per- form be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
