7-24 Physical and Operating Specifications
Resolutions
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 1024
1600 x 1200
1920 x 1080
1920 x 1200
1800 x 1440

Network Controller

Physical connector
Operating environment
Temperature
Humidity
Electrical bus

RJ-45 Network Cable Specifications

The RJ-45 connections use an unshielded twisted pair (UTP) cable of 22-, 24-, or 26-gauge. The
cable must comply with the IEEE 802.3 10BASE-T standard. The maximum distance between
the computer and the hub is 100 meters.
Matrox Millennium G200 AGP Graphics Controller
Maximum Color Support
Maximum Colors Maximum Refresh
Supported/8 MB Rate/8 MB
16.7M
16.7M
16.7M
16.7M
16.7M
16.7M
16.7M
16.7M
65,536
Table 7-22
Ethernet Network Interface Controller (NIC)
RJ-45
50 to 95 F
10% to 90%, noncondensing
32-bit PCI bus
Table 7-21
Maximum Colors
Supported/16 MB
200Hz 16.7M
180Hz 16.7M
140Hz 16.7M
120Hz 16.7M
100Hz 16.7M
75Hz 16.7M
70Hz 16.7M
65Hz 16.7M
70Hz 65,536
10 to 35 C
Maximum Refresh
Rate/16 MB (Hz)
200
180
140
120
100
75
70
65
70
