10
BATTERY CHARGING
D Rapid charging with the BC-119N+AD-106
The optional BC-119N provides rapid charging of the Li-ion
battery pack.
Charging period: Approximately 3.5 hours.
The following items are additionally required.
• AD-106
charger adapter
• An AC adapter or the DC power cable (OPC-515L/CP-23L).
AC adapter
*
Optional OPC-515L
(for 13.8 V power
source) or CP-23L
(for 12 V cigarette
lighter socket) can
be used instead of
the AC adapter.
34
(purchase separately)
Transceiver
Turn power OFF
Battery
pack
AD-106 charger
adapter is installed
in BC-119N.
CAUTION: NEVER connect the OPC-
*
515L to a power source using reverse
polarity. This will ruin the battery charger.
White line: Black line :
D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously.
Charging period: Approximately 3.5 hours.
The following items are additionally required.
• Six AD-106 charger adapters
• An AC adapter (BC-157S) or the DC power cable (OPC-
656)
Battery
pack
AC adapter
(Purchased
separately)
DC power cable (OPC-656)
(Connect with the DC power supply; 13.8 V/at least 7 A)
*About the OPC-656
Red line :
Transceiver
Turn power OFF
AD-106 charger
adapters are installed
in each slot.
Black line :
