4 Connecting up the DVB receiver

a. Connect the aerial to the Aerial input on the DVB receiver.
b. Connect the HDMI connection on the DVB receiver to the TV.
c. Connect the Scart connection on the DVB receiver to the TV.
d. Connect the Aerial output to the TV.
e. Connect the Audio output to your HiFi system.
f. Power supply connection
a
e
10
d
c
b
f
