DOOR OPTIONS
Perlick units o er a variety of door panel design
alternatives; solid stainless steel, solid wood overlay,
stainless steel glass, wood overlay glass, solid stain-
less steel drawers and solid wood overlay drawers.
This, together with door swing choices, result in a
variety of possible combinations.
Solid stainless steel, stainless steel glass doors and
solid stainless steel drawers are shipped from the
factory with decorative stainless steel panels and
handles in place on the appliance, ready for use.
Solid wood overlay, glass wood overlay doors and
solid wood overlay drawers are designed to accept a
decorative front panel to match surrounding cabi-
netry and door handles. This panel and door handle
will be provided by the customer.
All Perlick units accept any of the above door con-
gurations and are fully hinge reversible and inter-
changeable. See page 15 for Door Reversing Instruc-
tions.
IMPORTANT NOTE: Units with a freezer can only
utilize a solid stainless steel door, solid wood
overlay door, solid stainless drawers or solid
wood overlay drawers (stainless steel glass or
wood overlay glass doors will sweat if installed
on a freezer section).
IMPORTANT NOTE: Stainless steel glass or wood
overlay glass doors may sweat in conditions with
relative humidity over 75 percent.
14
© 2011 24", 48" & 72" Cabinet Installation / Operation Manual
HANDLE INSTALLATION
CAUTION: Handle mounting on wood overlay
door should be mounted on overlay panel only
(not the door) to avoid damage to the factory
door.
1.
Handle must be attached to overlay before
mounting overlay onto door. Mark rear of wood
overlay panel with handle fastening locations.
2.
Drill through wood overlay panel at marked
locations taking care not to damage the wood over-
lay panel.
3.
Countersink screw heads so screw heads are
ush with backside of panel. Attach handle to over-
lay panel.
CAUTION
Proper wood working materials and equipment
should be used to avoid damage or errors in
workmanship.
1.
With the unit secured in position, open the
door and make sure panel pre-drilled holes align
with door frame holes.
2.
Loosely attach four corners of the overlay
panel to the door using #10 x 1" wood screws, in-
stalled through the door frame from the rear.
3.
Check for overall wood overlay panel t,
position and function. Make minor adjustments as
necessary. When panel
tighten mounting
screws securely. Install the rest
of the mounting screws and tighten securely.
CAUTION: Do not over-tighten wood overlay
attachment screws as this may damage factory
supplied doorframe.
is properly aligned,
Document No. Z2305
