INSTALLATION

IMPORTANT NOTE: If installing on a concrete
oor, concrete fasteners are required and not
included with the anti-tip kit.
CAUTION
Any nished ooring should be protected with
appropriate material to avoid damage from mov-
ing the unit.
If unit has been laid on its back or sides, place unit
upright and allow minimum of 24 hours before con-
necting power.
Re-install the doors by removing the upper pivot pin
completely, sliding the door onto the lower pivot pin
and re-installing the upper pivot pin and fastening
tightly. Before moving the unit, make sure the door is
secured to the cabinet (tape may be required to hold
the doors closed).
1.
Plug the unit into the 15 amp grounded out-
let located in the installation opening. With power
applied to the unit, check that the lighting and cool-
ing function operate properly, then turn o power to
the wall outlet at the circuit breaker.
WARNING
Shut o power to the wall outlet before installing
into the opening.
2.
Check that the following are level and square:
Front face and interior opening
Installation opening and oor surface
Countertop bottom front edge
IMPORTANT NOTE: Leveling legs should not be
extend more than ¾" from bottom of the cabinet.
IMPORTANT NOTE: The oor under the unit must
be at the same level as the surrounding nished
oor.
3.
If all surfaces are level:
a.
Measure from the oor to the bottom of the
front edge of the countertop
b.
Measure the rear of the unit cabinet from the
oor to top of cabinet, at back corners
c.
Adjust rear legs so B measurement equals A
12
© 2011 24", 48" & 72" Cabinet Installation / Operation Manual
measurement. Using an adjustable wrench or pliers,
turn legs counterclockwise to raise the unit or clock-
wise to lower the unit
4.
Slide the cabinet into position, making sure
the rear cabinet leveling legs slide under the anti-tip
devices. Push the cabinet into the opening until the
bottom front edge of the cabinet is ush with the
surrounding cabinetry or the leveling legs are tight
with the anti-tip devices.
IMPORTANT NOTE: The rear cabinet leveling legs
must be engaged under the anti-tip brackets.
5.
Shim the front of the unit so the front face is
ush with surrounding cabinetry. Adjust the front
legs to support the countertop at the shimmed
height. Using an adjustable wrench or pliers, turn
legs counterclockwise to raise the unit or clockwise
to lower the unit. Countertop should be resting on
top of the unit.
IMPORTANT NOTE: If countertop is not resting en-
tirely on unit top, shim the countertop to prevent
damage to the countertop.
CAUTION
To prevent damage to the countertop and unit
underneath, do not place heavy objects on coun-
tertop directly above the unit.
6.
Check interior door openings inside the cabi-
net to ensure the cabinet is level. Re-install all shelv-
ing and drawers. Take extreme care to insert sliding
shelving and sliding drawers squarely into slide
brackets and proper slide bracket grooves. When
sliding shelving and drawers are installed properly a
click should be heard from both slide bracket retain-
ing clips and should slide smoothly in the tracks.
When sliding shelving or drawers are pulled out to
full extension a stop is activated to prevent addition-
al pull-out.
CAUTION
Improper shelving or drawer installation may not
actuate slide stop mechanism.
Document No. Z2305
