WOOD OVERLAY INSTALLATION
Before beginning installation, check all components for proper t and nish.
WARNING
• All overlay doors require a trim panel at least ¾" thick.
• The solid wood overlay panel should not weigh more than 20 pounds.
• The glass wood overlay panel should not weigh more than 10 pounds.
The following instructions cover installing a solid wood overlay or glass overlay panel and handle to a door
or drawer.
IMPORTANT NOTE: Contact the factory or visit www.perlick.com for full-size wood overlay panel lay-
outs.
See Figure 8 for details for the design of a solid wood overlay panel.
* Figure 8-A for details of door lock installation on a solid wood overlay panel.
See Figure 9 for details for the design of a glass wood overlay panel.
* Figure 9-A for details of door lock installaion on a glass wood overlay panel.
See Figure 10 for details for the design of a solid wood drawer overlay panel.
*Figure 10-A for details of door lock installation on a solid wood drawer overlay panel.
16 © 2011 24", 48" & 72" Cabinet Installation / Operation Manual Document No. Z2305
