18" SHALLOW-DEPTH SERIES
Operation/Installation Manual
SHELVING
IMPORTANT: To achieve maximum performance,
interior louver openings and fan guard should
never be obstructed.
Refrigerator
The single door unit comes standard with black
vinyl coated adjustable full extension pullout
shelves.
Wine Reserve
The single door unit comes standard with four full
extension black vinyl coated wine racks capable
of storing 20 standard wine bottles. Shelves are
removable and/or adjustable. At the bottom, up to
2 1.5L bottles can be stored.
ADJUSTING FULL EXTENSION SHELVING
1. Pull the shelf out to its farthest position. Locate
the tabs in the middle of both extends (Figure
5). Press tabs and pull shelf out.
2. Reposition each bracket separately. Grasp the
middle of the bracket, pull the front end up and
out, then forward to remove (Figure 5).
3. Place bracket at the desired position. Push
the rear hook into the rear key slot. Set front of
bracket on the wall hook.
4. Repeat for other bracket(s).
5. Push extenders completely into the unit. Align
the shelf grooves with the extenders and slide
completely into the unit.
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
Form No. Z2325
DOOR PANEL OPTIONS
Perlick units offer a variety of door panel design
alternatives; solid stainless steel, stainless steel
glass, black vinyl (glass or solid door) or laminate.
Solid stainless steel and stainless steel glass
doors are shipped from the factory with decorative
stainless steel panels and handles in place on the
appliance.If optional door lock is ordered, the unit
comes pre-assembled from the factory. Laminate
is also available in a variety of colors and patterns,
and is installed at the factory.
If ordered with the optional door lock, see Figure 6.
Door Lock Installation on page 9.
IMPORTANT: Glass doors may sweat in conditions
with relative humidity over 75%.
Lift this end up
8
Press tabs and pull shelf out
Figure 5. Adjusting the Shelving
