INTRODUCTION
Congratulations on your purchase of a Perlick
residential refrigeration product. A pioneer in the
commercial refrigeration field for nearly 60
years, Perlick has decided to bring the ultimate
in beauty, high quality and innovative
commercial products to the residential market.
The vast product offering, available in both
indoor and outdoor models, gives you the
opportunity to enjoy the functionality and user
friendliness in just about any setting, including
home hospitality centers, kitchens, bedrooms
and summer rooms in either a built-in or
freestanding model. The all stainless interior and
front face will provide beauty and durability for a
lifetime of use.
This Installation and Use and Care Guide will
answer your questions about the features,
operation and maintenance of your Refrigerated
Cabinet model. If you have questions that are
not addressed here, call 800 558-5592.
IMPORTANT
PLEASE READ all instructions completely
before attempting to install or operate the unit.
First, as you follow these Installation and Use
and Care instructions, take particular note of the
CAUTION! and WARNING! symbols when they
appear. This information is important for the safe
and efficient installation, operation and care of
your Perlick Refrigerated Cabinet.
CAUTION
Signals a hazard where minor injury or
product damage may occur if you do not
follow instructions.
WARNING
States a hazard may cause serious injury or
death if precautions are not followed.
Once the unit is completely installed, we suggest
you keep this manual and purchasing
documentation in a safe place for future
reference. Should problems occur: refer to the
troubleshooting section of this manual. The
information will help you quickly identify a
problem and get it remedied. In the event you
require assistance, please contact the dealer
where you purchased your unit.
PLEASE RECORD YOUR MODEL'S
INFORMATION
Whenever you call to request information or
service, you will need to know your model
number and serial number. You can find this
information on the serial and identification plate
located on the inside ceiling of your unit and on
the warranty registration card.
WARRANTY REGISTRATION CARD
The package containing this manual also
includes your warranty registration information.
Warranty coverage begins on the date your
Perlick Refrigerated Cabinet was originally
purchased.
If you do not complete your Warranty
Registration Card on-line or return via U.S. mail,
Perlick will use the date of sale as the first date
of warranty for your new Refrigerated Cabinet.
Please record the purchase date of your Perlick
product and your dealer‟s name, address and
telephone number.
MODELNUMBER:_______________________
SERIAL NUMBER:_______________________
PURCHASE DATE:______________________
DEALER NAME & ADDRESS:
______________________________________
______________________________________
DEALER TELEPHONE:
______________________________________
www.bringperlickhome.com
IMPORTANT NOTE: Take a moment to
read through the included warranty
statement and complete and mail the
Warranty Registration Card as soon as
possible to validate the registration date.
An alternative method of completing the
Warranty Registration can be
accomplished online at
www.bringperlickhome.com.
1
