INSTALLATION

WARNING:
Inspect the Oven:
• Check the oven carefully for damage
before and regularly after installation.
• Make sure the door closes properly,
that it is not misaligned or warped.
• C h e c k t h e h i n g e s a n d d o o r s a f e t y
latches are not broken or loose.
• E n s u r e t h e d o o r s e a l a n d s e a l i n g
surfaces are not damaged.
• Inspect the oven interior and door for
dents.
IMPORTANT:
If any damage is apparent, do not operate
the oven in any way. Contact your dealer
or an authorised Service Technician
appointed by SHARP. (see p. 40)
1. Remove all packing materials including the
feature sticker (if applicable). Do not remove the
plastic film from the inside of the oven window as
this protects it from dirt. The waveguide cover
prevents food and grease from entering the
waveguide area where it could cause damage.
DO NOT REMOVE.
2. Place oven on a secure, level surface, strong
enough to take the oven weight, plus the heaviest
item likely to be cooked in the oven.
3. The minimum
height of free
space necessar y
above the top
surface of the oven
is 15cm.
4. Do not place the oven where heat, moisture or
high humidity are generated, (for example, near
or above a conventional oven) or near
combustible materials (for example, curtains). Do
not block or obstruct air vent openings. Do not
place objects on top of the oven.
5. Make sure the power supply cord is undamaged
(See Installation opposite) and that it does not run
under the oven or over any hot or sharp surfaces.
6. The socket must be readily accessible so that it
can be easily unplugged in an emergency.
7. Do not use the oven outdoors.
4:22 pm Page 4
15cm
4
Help Line: 08705 274277 (office hours)
BUILDING-IN-KIT.
This oven is not designed to be built into a kitchen
unit.
IMPORTANT! ELECTRICAL CONNECTION.
• Do not allow water to come into contact with the
power supply cord or plug.
• Insert the plug properly into the socket.
• Do not connect other appliances to the same
socket using an adaptor plug.
• If the plug or socket is loose or the power supply
cord is damaged, it must be replaced with a
special cord. The exchange must be made by an
authorised SHARP service agent.
• When removing the plug from the socket always
grip the plug, never the cord as this may damage
the power supply cord and the connections inside
the plug.
• If the fitted mains plug to your oven is a rewireable
type and in the unlikely event of the socket outlet in
your home not being compatible with the plug
supplied, remove the plug and fit an appropriate
type, observing the wiring code given in `To replace
the mains plug' on page 39.
If you wish to remove or replace the plug supplied,
ensure the plug is removed properly and not cut off.
• If the plug fitted to your oven is a non-rewirable
plug and in the unlikely event of the socket outlet
in your home not being compatible with the plug
supplied, cut-off the mains plug and fit an
appropriate type, observing the wiring code given
in `To replace the mains plug' on page 39.
Danger:
The fuse from the cut-off plug should be removed and
the plug disposed of in a safe manner.
Under no circumstances should the cut-off plug be
inserted into a socket outlet as a serious electric
shock may occur.
The plug must not be used without the fuse cover fitted.
If you have any doubt about your microwave oven
obtain the help of a qualified electrician.
If you wish to remove or replace the plug supplied,
ensure the plug is removed properly and not cut off.
When replacing the plug please ensure that you use
a BSI or ASTA approved plug to BS1363, this should
be fitted with a brown coloured 13 amp fuse
approved by BSI or ASTA to BS1362. If you have
any doubt about electrical connection seek the help
of a qualified electrician.
WARNING: THIS APPLIANCE MUST BE
EARTHED
To wire an appropriate plug, follow the wiring code
given in `To replace the mains plug' on page 39.
