Do not rest your head or chest on the steer-
ing wheel or dashboard when operating the
adjustment buttons.
You will find page references for further in-
formation in the index under "Airbag".

Speedometer

i
In some countries, a warning sounds when
the vehicle reaches the maximum speed limit,
e.g. at 120 km/h.

Rev counter

The red band in the rev counter indicates
the engine's overrevving range.
To protect the engine, the fuel supply is in-
terrupted when the red band is reached.
!
Do not drive in the overrevving range.
Doing so will damage the engine.
H
Environmental note
Avoid driving at high engine speeds, as this
increases your vehicle's consumption un-
necessarily and pollutes the environment
through increased emissions.
Fuel gauge
The fuel gauge is located to the right of
the speedometer in vehicles that have a
version A instrument cluster (
Instrument cluster version B
Fuel gauge
1 Vehicles without steering wheel
buttons
2 Vehicles with steering wheel but-
tons
3 Fuel filler flap location indicator
Ö: the fuel filler cap is on the
left
4 Reserve fuel warning lamp
Nur fuer internen Gebrauch
Trip meter
Instrument cluster version A
e E
page 22).
Resetting: Make sure that the display
is showing the trip meter (
Press and hold reset button 4 until
E
the trip meter is reset to
Instrument cluster version B
E
Resetting: Make sure that the display
is showing the trip meter if you have a
vehicle with steering wheel buttons
( e page 124).
E
Press and hold reset button 0 until the
trip meter is reset to

Instrument lighting

With the lights switched on, you can adjust
the brightness of the instrument lighting
using the , and . buttons.
Brighter: press the , button.
E
Dimmer: press the . button.
E
i
Vehicles with automatic headlamp mode:
the instrument lighting also adapts to auto-
matic headlamp mode.
Controls
Instrument cluster
e page 108).
000.0 .
3
0.0 .
101
