Page 1: Digital Video Camera
Owner’s Record The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. DCR-PC9 Model No. AC- Serial No.
Page 2: Declaration Of Conformity
Welcome! Congratulations on your purchase of this Sony Digital Handycam camcorder. With your Digital Handycam, you can capture life’s precious moments with superior picture and sound quality. Your Digital Handycam is loaded with advanced features, but at the same time it is very easy to use. You will soon be producing home video that you can enjoy for years to come.
Page 3 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,...
Page 4: Main Features
Main Features Taking moving or still images, and playing them back • Recording a picture on a tape (p. 22) • Recording a still image on a tape (p. 41) • Playing back a tape (p. 34) • Recording still images on “Memory Stick”s (p. 122) •...
Page 5: Checking Supplied Accessories
Checking supplied accessories Make sure that the following accessories are supplied with your camcorder. 1 Wireless Remote Commander (1) 6 “Memory Stick” (1) (p. 112) (p. 188) 7 A/V connecting cable (1) (p. 40) 2 AC-L10A/L10B/L10C AC power 8 Lens cap (1) (p. 22) adaptor (1), the power cord (1) (p.
Page 6: Table Of Contents
Table of contents Main Features ..........4 Advanced Playback Checking supplied accessories ....5 Operations Quick Start Guide ........ 8 Playing back a tape with picture effects .. 65 Playing back a tape with digital effects ... 66 Enlarging images recorded on tapes Getting started –...
Page 7 Table of contents Viewing a still image – Memory photo playback ....142 Viewing a moving picture – MPEG movie playback ....145 Viewing images using your computer .. 147 Enlarging still images recorded on “Memory Stick”s – Memory PB ZOOM ......153 Playing back images in a continuous loop –...
Page 8: Quick Start Guide
Quick Start Guide This chapter introduces you to the basic features of your camcorder. See the page in parentheses “( )” for more information. Pull down the Holding Grip to hold your camcorder as illustrated. Holding Grip Connecting the power cord (p.
Page 9 Recording a picture (p. 22) Remove the lens cap. Set the POWER switch to CAMERA while pressing the small green button. Press OPEN to open the LCD POWER LOCK panel. Viewfinder When the LCD panel is closed, pull out the viewfinder untill its Press START/STOP.
Page 10: Getting Started
— Getting started — Using this manual As you read through this manual, buttons and settings on your camcorder are shown in capital letters. e.g. Set the POWER switch to CAMERA. When you carry out an operation, you can hear a beep sound to indicate that the operation is being carried out.
Page 11: Precautions On Camcorder Care
Using this manual Precautions on camcorder care Lens and LCD screen/finder (on mounted models only) •The LCD screen and the finder are manufactured using extremely high-precision technology, so over 99.99 % of the pixels are operational for effective use. However, there may be some tiny black points and/or bright points (white, red, blue or green in color) that constantly appear on the LCD screen and the finder.
Page 12: Step 1 Preparing The Power Supply
Step 1 Preparing the power supply Installing the battery pack We recommend that you use the battery pack when you use your camcorder outdoors. (1) While sliding BATT (battery) release lever in the direction of the arrow 1, slide the battery terminal cover in the direction of the arrow 2. (2) Insert the battery pack in the direction of the arrow until it clicks.
Page 13: Charging The Battery Pack
Step 1 Preparing the power supply Charging the battery pack Use the battery pack after charging it for your camcorder. Your camcorder operates only with the “InfoLITHIUM” battery pack (M series). See page 171 for details of “InfoLITHIUM” battery pack. (1) Open the DC IN jack cover and connect the AC power adaptor supplied with your camcorder to the DC IN jack with the plug’s v mark facing the Holding Grip.
Page 14: Charging Time
Step 1 Preparing the power supply Charging time Battery pack Full charge NP-FM30 (supplied) NP-FM50 NP-FM70 NP-FM90 NP-FM91 The charging time may increase if the battery’s temperature is extremely high or low because of the ambient temperature. Approximate minutes at 25 °C (77 °F) to charge an empty battery pack Recording time Recording with Recording with...
Page 15 This unit is compatible with the “InfoLITHIUM” battery pack (M series). Your camcorder operates only with the “InfoLITHIUM” battery. “InfoLITHIUM” M series battery packs have the mark. SERIES “InfoLITHIUM” is a trademark of Sony Corporation.
Page 16: Connecting To A Wall Outlet
• The DC IN jack has “source priority.” This means that the battery pack cannot supply any power if the power cord is connected to the DC IN jack, even when the power cord is not plugged into a wall outlet. Using a car battery Use Sony DC Adaptor/Charger (optional).
Page 17: Step 2 Setting The Date And Time
Step 2 Setting the date and time Set the date and time settings when you use your camcorder for the first time. “CLOCK SET” will be displayed each time that you set the POWER switch to CAMERA or MEMORY unless you set the date and time settings. If you do not use your camcorder for about three months, the date and time settings may be released (bars may appear) because the built-in rechargeable battery installed in your camcorder will have been discharged (p.
Page 18 Step 2 Setting the date and time The year changes as follows: 1995 y 2001 T · · · · t 2079 To return to FN Press EXIT. If you do not set the date and time “– – – – – – – – –” and “– –:– –:– –” are recorded on the data code of the tape and the “Memory Stick”.
Page 19: Step 3 Inserting A Cassette
Step 3 Inserting a cassette (1) Install the battery pack, or connect the AC power adaptor for the power supply (p. 12 to 16). (2) Slide OPEN/ZEJECT in the direction of the arrow and open the lid. The cassette compartment automatically lifts up and opens. (3) Push the middle portion of the back of the cassette to insert.
Page 20: Step 4 Using The Touch Panel
Step 4 Using the touch panel Your camcorder has operation buttons on the LCD screen. Touch the LCD panel directly to operate each function. In CAMERA or VCR mode (1) Install the battery pack, or connect the AC power adaptor for the power supply (p.
Page 21 Step 4 Using the touch panel Notes • When using the touch panel, press operation buttons with your thumb supporting the LCD screen from the back side of it or press those buttons lightly with your index finger. Do not press them with sharp-pointed objects such as pens. •...
Page 22: Recording - Basics
— Recording – Basics — Recording a picture Your camcorder automatically focuses for you. (1) Remove the lens cap and pull the lens cap string to fix it. (2) Install the power source and insert a cassette. See “Step 1” and “Step 3” for more information (p.
Page 23 Recording a picture Notes •Fasten the grip strap firmly. •Do not touch the built-in microphone during recording. Note on Recording mode Your camcorder records and plays back in the SP (standard play) mode and in the LP (long play) mode. Select SP or LP in the menu settings (p. 105). In the LP mode, you can record 1.5 times as long as in the SP mode.
Page 24: Adjusting The Lcd Screen
Recording a picture Adjusting the LCD screen The LCD panel moves about 90 degrees to the viewfinder side and about 180 degrees to the lens side. OPEN When closing the LCD panel, set it vertically, and swing it into the camcorder body. Note When using the LCD screen except in the mirror mode, the viewfinder automatically turns off.
Page 25: Adjusting The Brightness Of The Lcd Screen
Recording a picture Picture in the mirror mode The picture on the LCD screen is a mirror-image. However, the picture will be normal when recorded. During recording in the mirror mode •ZERO SET MEMORY on the Remote Commander does not work. •FN appears mirror-reversed in the viewfinder.
Page 26: Adjusting The Viewfinder
Recording a picture Adjusting the viewfinder If you record pictures with the LCD panel closed, check the picture with the viewfinder. Adjust the viewfinder lens to your eyesight so that the indicators in the viewfinder come into sharp focus. Pull out the viewfinder and move the viewfinder lens adjustment lever. You turn the LCD panel over and move it back to your camcorder body with the LCD screen facing out.
Page 27: Using The Zoom Feature
Recording a picture Using the zoom feature Move the power zoom lever a little for a slower zoom. Move it further for a faster zoom. Using the zoom function sparingly results in better-looking recordings. “T” side: for telephoto (subject appears closer) “W”...
Page 28 Recording a picture Indicators displayed in the recording mode The indicators are not recorded on tape. Remaining battery time indicator Cassette memory indicator This appears when using a tape with cassette memory. Recording mode indicator STBY/REC indicator Time code/Tape counter indicator 0:00:01 45min Remaining tape indicator...
Page 29: Shooting Backlit Subjects - Back Light
Recording a picture Shooting backlit subjects – BACK LIGHT When you shoot a subject with the light source behind the subject or a subject with a light background, use the backlight function. Press BACK LIGHT in CAMERA or MEMORY mode. The .
Page 30: Using The Nightshot Light
Recording a picture Using Super NightShot The Super NightShot mode makes subjects more than 16 times brighter than those recorded in the NightShot mode. (1) Slide NIGHTSHOT to ON in CAMERA mode. and “NIGHTSHOT” indicators flash on the screen. (2) Press SUPER NIGHTSHOT. The and “SUPER NIGHTSHOT“...
Page 31: Self-Timer Recording
Recording a picture Self-timer recording Recording with the self-timer starts in 10 seconds automatically. You can also use the Remote Commander for this operation. (1) In the standby mode, press FN and select PAGE3 (p. 20). (2) Press SELFTIMER. (self-timer) indicator appears on the screen. (3) Press START/STOP.
Page 32: Checking The Recording - End Search / Editsearch / Rec Review
Checking the recording – END SEARCH / EDITSEARCH / Rec Review You can use these buttons to check the recorded picture or shoot so that the transition between the last recorded scene and the next scene you record is smooth. EDIT END SEARCH You can go to the end of the recorded section after you record.
Page 33: Rec Review
Checking the recording – END SEARCH / EDITSEARCH / Rec Review Rec Review You can check the last recorded section. In the standby mode, press the 7/– side of EDIT momentarily . The section you have stopped most recently will be played back for a few seconds, and then your camcorder will return to the standby mode.
Page 34: Playback - Basics
— Playback – Basics — Playing back a tape You can monitor the playback picture on the LCD screen. If you close the LCD panel, you can monitor the playback picture in the viewfinder. You can also control playback using the Remote Commander supplied with your camcorder. (1) Install the power source and insert the recorded tape.
Page 35 Playing back a tape When monitoring on the LCD screen You can turn the LCD panel over and move it back to the camcorder body with the LCD screen facing out. If you leave the power on for a long time Your camcorder gets warm.
Page 36 Playing back a tape To display the screen indicators – Display function Press DISPLAY/TOUCH PANEL on your camcorder or DISPLAY on the Remote Commander supplied with your camcorder. The indicators disappear on the screen. To make the indicators appear, press DISPLAY/TOUCH PANEL or DISPLAY again. Using the data code function Your camcorder automatically records not only images on the tape but also the recording data (date/time or various settings when recorded) (Data code).
Page 37 Playing back a tape Various settings Various settings is your camcorder’s information when you have recorded. In the recording mode, the various settings will not be displayed. When you use the data code function, bars (-- -- --) appear if: –...
Page 38: Various Playback Modes
Playing back a tape Various playback modes To operate video control buttons, set the POWER switch to VCR. When using the touch panel (1) Press FN and select PAGE3. (2) Press V SPD PLAY to display video control buttons. To view a still image (playback pause) Press /X during playback.
Page 39 Playing back a tape Video control buttons Marks on your camcorder are different from those on the Remote Commander supplied with your camcorder. Your camcorder: To play back or pause a tape To stop a tape To rewind a tape To fastforward a tape To play back a tape slowly To forward one frame at a time...
Page 40: Viewing The Recording On Tv
Viewing the recording on TV Connect your camcorder to your TV with the A/V connecting cable supplied with your camcorder to watch the playback picture on the TV screen. You can operate the playback control buttons in the same way as when you monitor playback pictures on the LCD screen.
Page 41: Advanced Recording Operations
— Advanced Recording Operations — Recording a still image on a tape – Tape Photo recording You can record a still image. This mode is useful when you want to print a image using a video printer (optional). You can record about 510 images in the SP mode and about 765 images in the LP mode on a 60-minute tape.
Page 42 Recording a still image on a tape – Tape Photo recording Self-timer recording You can record still images on tapes with the self-timer. You can also use the Remote Commander for this operation. (1) In the standby mode, press FN and select PAGE3. (2) Press SELFTIMER.
Page 43: Printing The Still Image
Recording a still image on a tape – Tape Photo recording Printing the still image You can print a still image by using the video printer (optional). Connect the video printer using the A/V connecting cable supplied with your camcorder. Connect it to the A/V jack and connect the yellow plug of the cable to the video input of the video printer.
Page 44: Using The Wide Mode
Using the wide mode You can record a 16:9 wide picture to watch on the 16:9 wide-screen TV (16:9WIDE). Black bands appear on the screen during recording in 16:9WIDE mode [a]. The picture during playing back on a normal TV [b] or a wide -screen TV [c] are compressed in the widthwise direction.
Page 45: Using The Fader Function
Using the fader function You can fade in or out to give your recording a professional appearance. STBY NORM. FADER (fader) MOSC. FADER (mosaic) BOUNCE 1)2) OVERLAP WIPE STBY MONOTONE When fading in, the picture gradually changes from black-and-white to color. When fading out the picture gradually changes from color to black-and-white.
Page 46 Using the fader function (1) When fading in [a] In the standby mode, press FN to display PAGE1. When fading out [b] In the recording mode, press FN to display PAGE1. (2) Press FADER. The screen to select the fader mode appears. (3) Select a desired fader mode.
Page 47 Using the fader function While using the bounce function, you cannot use the following functions: – Exposure – Flexible Spot Meter – Focus – Zoom – Picture effect Note on the bounce function You cannot select the bounce function in the following mode or functions: –...
Page 48: Using Special Effects - Picture Effect
Using special effects – Picture effect You can digitally process images to obtain special effects like those in films or on the NEG. ART [a] : The color and brightness of the picture are reversed. SEPIA : The picture is sepia. B&W : The picture is monochrome (black-and-white).
Page 49: Using Special Effects - Digital Effect
Using special effects – Digital effect You can add special effects to recorded pictures using the various digital functions. The sound is recorded normally. STILL You can record a still image so that it is superimposed on a moving picture. FLASH (FLASH MOTION) You can record still image successively at constant intervals.
Page 50 Using special effects – Digital effect (1) In CAMERA mode, press FN to display PAGE1. (2) Press DIG EFFT. The screen to select a desired digital effect mode appears. (3) Select a desired digital effect mode. In the STILL and LUMI. modes, the still image is stored in memory.
Page 51 Using special effects – Digital effect Notes •The following functions do not work during digital effect: – Fader – Low lux mode of PROGRAM AE (The indicator flashes) – Tape Photo recording – Super NightShot •The PROGRAM AE function does not work in the slow shutter mode. •The following functions do not work in the old movie mode: –...
Page 52: Using The Program Ae Function
Using the PROGRAM AE function You can select PROGRAM AE (Auto Exposure) mode to suit your specific shooting requirements. Spotlight This mode prevents people’s faces, for example, from appearing excessively white when shooting subjects lit by strong light in the theater. Soft portrait This mode brings out the subject while creating a soft background for subjects such as people or flowers.
Page 53 Using the PROGRAM AE function (1) In CAMERA or MEMORY mode, press FN to display PAGE1. (2) Press MENU, then select PROGRAM AE in in the menu settings to select a desired PROGRAM AE mode (p. 105). EXIT MANUAL SET PROGRAM AE AUTO SPOTLIGHT...
Page 54 Using the PROGRAM AE function •The following functions do not work in the low lux mode: – Digital effect – Overlap – Wipe – Dot •The PROGRAM AE function does not work in the following cases. (The indicator flashes.) – To set the NIGHTSHOT to ON –...
Page 55: Adjusting The White Balance Manually
Adjusting the white balance manually You can manually adjust and set the white balance. This adjustment makes white subjects look white and allows more natural color balance. Normally white balance is automatically adjusted. (1) In CAMERA or MEMORY mode, press FN to display PAGE1. (2) Press MENU, then select WHT BAL in in the menu settings to select a desired white balance mode (p.
Page 56 Adjusting the white balance manually In the automatic white balance mode Point your camcorder at the white subject for about 10 seconds after setting the POWER switch to CAMERA to get better adjustment when: – You detach the battery for replacement. –...
Page 57: Adjusting The Exposure Manually
Adjusting the exposure manually You can adjust and set the exposure. Normally exposure is automatically adjusted. Adjust the exposure manually in the following cases: – The subject is backlit – To shoot the bright subject and dark background – To record dark pictures (e.g. night scenes) faithfully (1) In CAMERA or MEMORY mode, press FN to display PAGE1.
Page 58: Using The Spot Light-Metering Mode - Flexible Spot Meter
Using the spot light-metering mode – Flexible Spot Meter You can take a picture with the appropriate exposure automatically for just the point you want to focus on and with its exposure fixed. Use the Flexible Spot Meter mode in the following cases: –...
Page 59: Focusing Manually
Focusing manually You can gain better results by manually adjusting the focus in the following cases. Normally, focus is automatically adjusted. •The autofocus mode is not effective when shooting – subjects through glass coated with water droplets – horizontal stripes –...
Page 60: Interval Recording
Interval recording You can make a time-lapse recording by setting the camcorder to automatically record and standby sequentially. You can achieve an excellent recording for flowering, emergence, etc., with this function. Example 9 min 59 s 9 min 59 s 10 min 10 min [a] Recording time...
Page 61 Interval recording (4) Set INT. REC to ON, then press EXEC. (5) Press EXIT to return to FN. The INTERVAL indicator flashes on the screen (6) Press START/STOP to start interval recording. The interval recording indicator lights up. CAMERA SET EXIT D ZOOM 16 : 9W I DE...
Page 62: Frame By Frame Recording - Cut Recording
Frame by frame recording – Cut recording You can make a recording with a stop-motion animated effect using cut recording. To create this effect, alternately move the subject a little and make a cut recording. We recommend that you use a tripod, and operate the camcorder using the Remote Commander after step 4.
Page 63: Using The Viewfinder
Using the viewfinder You can pull out the viewfinder until it clicks, and then turn the LCD panel over and move it back to your camcorder body with the LCD screen facing out. You can operate with the touch panel using the viewfinder. Use the viewfinder in the following case: When operating camera brightness and the fader (only in CAMERA mode) on the touchpanel using the viewfinder...
Page 64 Using the viewfinder Notes •Do not touch the LCD screen with wet hands. •Do not press the LCD screen with sharp objects such as pens. •In VCR or memory playback mode, you cannot operate with the touch panel using the viewfinder.
Page 65: Advanced Playback Operations
— Advanced Playback Operations — Playing back a tape with picture effects During playback, you can process a scene using the picture effect functions: NEG.ART, SEPIA, B&W and SOLARIZE. (1) In VCR mode, press FN to display PAGE1. (2) Press MENU, then select P EFFECT in in the menu settings to select a desired picture effect mode (p.
Page 66: Playing Back A Tape With Digital Effects
Playing back a tape with digital effects During playback, you can process a scene using the digital effect functions: STILL, FLASH, LUMI. and TRAIL. (1) In VCR mode, press FN and select PAGE2. (2) Press DIG EFFT. The screen to select a desired digital effect mode appears. (3) Select a desired digital effect mode.
Page 67: Enlarging Images Recorded On Tapes - Tape Pb Zoom
Enlarging images recorded on tapes – Tape PB ZOOM You can enlarge playback images recorded on tapes. Besides the operation described here, your camcorder can enlarge still images recorded on “Memory Stick”s (p. 153). (1) In the playback or playback pause mode, press FN and select PAGE2. (2) Press PB ZOOM.
Page 68: Quickly Locating A Scene Using The Zero Set Memory Function
Quickly locating a scene using the zero set memory function Your camcorder goes forward or backward to automatically stop at a desired scene having a tape counter value of “0:00:00”. Use the Remote Commander for this operation. (1) In the playback mode, press DISPLAY on the Remote Commander if the counter is not on the screen.
Page 69: Searching The Boundaries Of Recorded Tape By Title - Title Search
Searching the boundaries of recorded tape by title – Title search If you use a tape with cassette memory, you can search for the boundaries of recorded tape by title. Use the Remote Commander for this operation. Before operation Set CM SEARCH in to ON in the menu settings (p.
Page 70: Searching A Recording By Date - Date Search
Searching a recording by date – Date search You can automatically search for the point where the recording date changes and start playback from that point (Date search). Use a tape with cassette memory for convenience. Use the Remote Commander for this operation. Use this function to check where recording dates change or to edit the tape at each recording date.
Page 71: Searching For The Date Without Using Cassette Memory
Searching a recording by date – Date search Note If one day’s recording is less than 2 minutes, your camcorder may not accurately find the point where the recording date changes. If a tape has a blank portion between recorded portions The date search function may not work correctly.
Page 72: Searching For A Photo - Photo Search/Photo Scan
Searching for a photo – Photo search/Photo scan You can search for a still image you have recorded on a tape (photo search). You can also search for still images one after another and display each image for 5 seconds automatically regardless of cassette memory (photo scan). Use the Remote Commander for these operations.
Page 73 Searching for a photo – Photo search/Photo scan Searching for a photo without using cassette memory (1) Set the POWER switch to VCR. (2) Press FN to display PAGE1. (3) Press MENU, then set CM SEARCH to OFF in in the menu settings (p. 105). (4) Press SEARCH MODE on the Remote Commander repeatedly, until the photo search indicator appears.
Page 74: Scanning Photo
Searching for a photo – Photo search/Photo scan Scanning photo (1) Set the POWER switch to VCR. (2) Press SEARCH MODE on the Remote Commander repeatedly, until the PHOTO SCAN indicator appears. The indicator changes as follows: DATE SEARCH t PHOTO SEARCH t PHOTO SCAN t (no indicator) (3) Press .
Page 75: Editing
— Editing — Dubbing a tape Using the A/V connecting cable You can dub or edit on the VCR connected to your camcorder using your camcorder as a player. Connect your camcorder to the VCR using the A/V connecting cable supplied with your camcorder.
Page 76 Dubbing a tape Using the i.LINK cable (DV connecting cable) Simply connect the i.LINK cable (DV connecting cable) (optional) to DV of your camcorder and to DV IN of the DV products. With digital-to-digital connection, video and audio signals are transmitted in digital form for high-quality editing. You cannot dub the titles, display indicators or the contents of cassette memory or letters on the “Memory Stick”...
Page 77: Dubbing Only Desired Scenes - Digital Program Editing
Dubbing only desired scenes – Digital program editing You can duplicate selected scenes (programs) for editing onto a tape without operating the VCR. Scenes can be selected by frame. You can set up to 20 programs. Unwanted scene Unwanted scene Switch the order Before operating the Digital program editing Step 1 Connecting the VCR (p.
Page 78 Dubbing only desired scenes – Digital program editing Step 2: Setting the VCR to operate with the A/V connecting cable To edit using the VCR, send the control signal by infrared rays to the remote sensor on the VCR. When you connect using the A/V connecting cable, follow the procedures below, (1) to (4), to send the control signal correctly.
Page 79 The IR SETUP code is stored in the memory of your camcorder. Be sure to set the correct code, depending on your VCR. Default setting is code number 3. Brand IR SETUP code Brand IR SETUP code Sony 1, 2, 3, 4, 5, 6 Multitech 23, 32, 80 Admiral (M. Wards) 89 21, 33, 35...
Page 80 Dubbing only desired scenes – Digital program editing (2) Setting the modes to cancel the recording pause on the 1 Select PAUSEMODE, then press EXEC. 2 Select the mode to cancel recording pause on the VCR, then press EXEC. The correct button depends on your VCR. Refer to the operating instructions of your VCR.
Page 81 Dubbing only desired scenes – Digital program editing (3) Locate the infrared rays emitter of your camcorder and face it towards the remote sensor of the VCR Set the devices about 30 cm (11 7/8 in.) apart, and remove any obstacles between the devices.
Page 82: Dv Connecting Cable
Dubbing only desired scenes – Digital program editing Step 2: Setting the VCR to operate with the i.LINK cable (DV connecting cable) When you connect using the i.LINK cable (DV connecting cable) (optional), follow the procedures below. (1) Set the POWER switch to VCR on your camcorder. (2) Turn the power of the connected VCR on, then set the input selector to DV input.
Page 83 Dubbing only desired scenes – Digital program editing Step 3: Adjusting the synchronicity of the VCR You can adjust the synchronicity of your camcorder and the VCR. Prepare a pen and paper for notes. Before operation, eject a cassette from your camcorder. (1) Set the POWER swtich to VCR on your camcorder.
Page 84 To return to FN Press EXIT. Notes •When you complete step 3, the image to adjust the syncronicity is recorded for about 50 seconds. •If you start recording from the very beginning of the tape, the first few seconds of the tape may not be recorded properly.
Page 85 Dubbing only desired scenes – Digital program editing Operation 1: Making the Program (1) Insert the tape for playback into your camcorder, and insert a tape for recording into the VCR. (2) Press FN to display PAGE1. (3) Select VIDEO EDIT in in the menu settings (p.
Page 86 Dubbing only desired scenes – Digital program editing Erasing the program you have set Erase OUT mark first, and then IN mark of the last program. (1) Press UNDO. The last program mark flashes on the LCD screen. (2) Press EXEC. The setting is cancelled. To cancel erasing Press CANCEL in step 2.
Page 87 Dubbing only desired scenes – Digital program editing Operation 2: Performing a Digital program editing (Dubbing a tape) Make sure your camcorder and the VCR are connected, and that the VCR is set to recording pause. When you use an i.LINK cable (DV connecting cable) the following procedure is not necessary.
Page 88: Using With An Analog Video Unit And Your Computer - Signal Convert Function
Using with an analog video unit and your computer – Signal convert function You can capture images and sound from an analog video unit connected to your computer which has the i.LINK jack (DV jack) to your camcorder. Before operation Set DISPLAY to LCD in the menu settings.
Page 89: Recording Video Or Tv Programs
Recording video or TV programs Using the A/V connecting cable You can record a tape from another VCR or a TV program from a TV that has video/ audio outputs. Use your camcorder as a recorder. Before operation Set DISPLAY to LCD in the menu settings. (The defalt setting is LCD.) (1) Insert a blank tape (or a tape you want to record over) into your camcorder.
Page 90: Using The I.link Cable (Dv Connecting Cable)
Recording video or TV programs If your TV or VCR has an S video jack Connect using an S video cable (optional) to obtain high-quality pictures. With this connection, you do not need to connect the yellow (video) plug of the A/V connecting cable.
Page 91 Recording video or TV programs When you have finished dubbing a tape Press x on both your camcorder and the VCR. You can connect one VCR only using the i.LINK cable (DV connecting cable). When you dub a picture in digital form The color of the display may be uneven.
Page 92: Inserting A Scene From A Vcr - Insert Editing
Inserting a scene from a VCR – Insert editing You can insert a new scene from a VCR onto your originally recorded tape by specifying the insert start and end points. Use the Remote Commander for this operation. Connections are the same as on page 89 or 90. Insert a cassette containing the desired scene to insert into the VCR.
Page 93: Inserting A Scene From A Vcr – Insert Editing
If you insert scenes on the tape recorded with other camcorder (including other DCR-PC9) The picture and sound may be distorted. We recommend that you insert scenes on a tape recorded with your camcorder.
Page 94: Audio Dubbing
Audio dubbing You can record an audio sound to add to the original sound on a tape by connecting audio equipment or a microphone. If you connect the audio equipment, you can add sound to your recorded tape by specifying starting and ending points. The original sound will not be erased.
Page 95 Audio dubbing Dubbing with the built-in microphones No connection is necessary. Notes •When dubbing with A/V jack or the built-in microphone, pictures are not output through S VIDEO jack or the A/V jack. Check the recorded picture on the screen. You can check the recorded sound by using head phones.
Page 96 Audio dubbing Adding an audio sound on a recorded tape (1) Insert your recorded tape into your camcorder. (2) Set the POWER switch to VCR. (3) Locate the recording start point. Press the /N to start playing back. To pause playing back, press the /X at the recording start point.
Page 97 We recommend that you add new sound on a tape recorded with your camcorder If you add new sound on a tape recorded with another camcorder (including other DCR-PC9), the sound quality may become worse. If you set the write-protect tab of the tape to lock You cannot record on a tape.
Page 98: Superimposing A Title
Superimposing a title If you use a tape with cassette memory, you can superimpose the title. When you play back the tape, the title is displayed for about 5 seconds from the point where you superimposed it. You can select one of eight preset titles and 2 custom titles (p. 101). You can also select the color, size and position of titles.
Page 99 Superimposing a title If you set the write-protect tab to lock You cannot superimpose or erase the title. Slide the write-protect tab to release the write protection. To use the custom title If you want to use the custom title, select in step 3.
Page 100: Erasing A Title
Superimposing a title Erasing a title (1) Set the POWER switch to CAMERA or VCR. (2) Press FN to display PAGE1. (3) Press MENU, then select TITLEERASE in in the menu setting, then press EXEC. (4) Select the title you want to erase with r/R, and then press EXEC. “ERASE OK?”...
Page 101: Making Your Own Titles
Making your own titles You can make up to 2 titles and store them in the memory of your camcorder. Each title can have up to 20 characters. (1) Set the POWER switch to CAMERA or VCR. (2) Press FN and select PAGE2. (3) Press TITLE.
Page 102 Making your own titles If you take 5 minutes or longer to enter characters in the standby mode while a cassette is in your camcorder The power automatically goes off. The characters you have entered remain stored in memory. Set the POWER switch to OFF (CHARGE) once and then to CAMERA again, then complete your title.
Page 103: Labeling A Cassette
Labeling a cassette If you use a tape with cassette memory, you can label a cassette. The label can consist of up to 10 characters and is stored in cassette memory. When you insert the labeled cassette and set the POWER switch to CAMERA or VCR, the label is displayed for about 5 seconds.
Page 104 Labeling a cassette If you set the write-protect tab of the tape to lock You cannot label the tape. Slide the write-protect tab to release the write protection. If the tape has too many index signals You may not be able to label a cassette because the memory is full. In this case, delete data you do not need.
Page 105: Customizing Your Camcorder
— Customizing Your Camcorder — Changing the menu settings To change the mode settings in the menu settings, select the menu items with r/R dial. The default settings can be partially changed. First, select the icon, then the menu item and then the mode.
Page 106: White Balance (P
Changing the menu settings Menu items are displayed as the following icons: MANUAL SET CAMERA SET VCR SET LCD/VF SET MEMORY SET CM SET TAPE SET SETUP MENU OTHERS Selecting the mode setting of each item z is the default setting. Menu items differ depending on the position of the POWER switch.
Page 107 Changing the menu settings POWER Icon/item Mode Meaning switch FRAME REC z OFF To deactivate cut recording function. CAMERA To activate cut recording function (p. 62). INT. REC To activate interval recording function (p. 60). CAMERA z OFF To deactivate interval recording function. To set waiting time and recording time for interval recording function.
Page 108 Changing the menu settings POWER Icon/item Mode Meaning switch STILL SET PIC MODE z SINGLE Not to record continuously. MEMORY MULTI SCRN To record 9 images continuously (p. 124). QUALITY z FINE To record still images in the fine image quality mode.
Page 109 Changing the menu settings POWER Icon/item Mode Meaning switch SLIDE SHOW —— To play back images in a continuous loop MEMORY (p. 154). DELETE ALL —— To delete all the unprotected images (p. 158). MEMORY FORMAT z RETURN To cancel formatting. MEMORY To format an inserted “Memory Stick.”...
Page 110 When you play back the tape on other camcorders or VCRs, noise may occur in pictures or sound. •When you record in the LP mode, we recommend using a Sony Excellence/Master mini DV cassette so that you can get the most out of your camcorder.
Page 111: Digital Program Editing (P
Changing the menu settings POWER Icon/item Mode Meaning switch DATA CODE* z DATE/CAM To display date, time and various settings during playback MEMORY DATE To display date and time during playback WORLD TIME —— To set the clock to the local time. Press r/R to set CAMERA a time difference.
Page 112: Memory Stick" Operations
— “Memory Stick” Operations — Using a “Memory Stick” – introduction You can record and play back images on a “Memory Stick” supplied with your camcorder. You can easily play back, record or delete images. You can exchange image data with other equipment such as your computer etc., using the USB cable for “Memory Stick”...
Page 113 (p. 109). However, formatting erases all information on the “Memory Stick”. “Memory Stick” and are trademarks of Sony Corporation. •Windows and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Page 114 Using a “Memory Stick” – introduction Inserting a “Memory Stick” Insert a “Memory Stick” in the “Memory Stick” slot as far as it can go with the v mark facing up as illustrated. Access lamp “Memory Stick” slot Ejecting a “Memory Stick” Slide MEMORY EJECT in the direction of the arrow.
Page 115: Using A Touch Panel
Using a “Memory Stick” – introduction Using a touch panel Your camcorder has operation buttons on the LCD screen. Press the LCD panel directly to operate each function. (1) Set the POWER switch to MEMORY. Make sure that the LOCK is set to the right (unlock) position.
Page 116 Using a “Memory Stick” – introduction To return to FN Press EXIT. To execute settings Press EXEC or To cancel settings Press OFF to return to PAGE1/PAGE2/PAGE3. Notes •When using the touch panel, press operation buttons with your thumb supporting the LCD screen from the back side of it or press those buttons lightly with your index finger.
Page 117: Image Quality Settings
Using a “Memory Stick” – introduction Selecting still image quality mode You can select image quality mode in still image recording. The default setting is FINE. (1) Set the POWER switch to MEMORY or VCR. Make sure that the LOCK is set to the right (unlock) position.
Page 118 Using a “Memory Stick” – introduction Note In some cases, changing the image quality mode may not affect the image quality, depending on the types of images you are shooting. Differences in image quality mode Recorded images are compressed in JPEG format before being stored in memory. The memory capacity allotted to each image varies depending on the selected image quality mode.
Page 119 Using a “Memory Stick” – introduction Selecting the size of a moving picture You can select 320 240 or 160 112 of the moving picture size. The default setting is 240. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the right (unlock) position.
Page 120 Using a “Memory Stick” – introduction Image size settings Indicator Setting Meaning Recording Playback 640 480 Records 640 480 still images. ———— ———— 320 240 Records 320 240 moving pictures. 160 112 Records 160 112 moving pictures. Maximum recording time of moving pictures Image size Maximum recording time 320 240...
Page 121 Using a “Memory Stick” – introduction Approximate time of moving pictures you can record on a “Memory Stick” The time of moving pictures you can record varies depending on which image size you select and the complexity of the subject. 4MB type (supplied): Picture size 320 240...
Page 122: Recording Still Images On "Memory Stick" - Memory Photo Recording
Recording still images on “Memory Stick” – Memory Photo recording You can record still images on the “Memory Stick”. You can also record nine still images continuously. (MULTI SCRN) Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the right (unlock) position.
Page 123 Recording still images on “Memory Stick” – Memory Photo recording When the POWER switch is set to MEMORY The following functions do not work: – Wide mode – Digital zoom – SteadyShot function – SUPER NIGHTSHOT – Fader – Picture effect –...
Page 124: Recording Images Continuously
Recording still images on “Memory Stick” – Memory Photo recording Recording images continuously You can record still images continuously. Select the multi screen mode described below before recording. Multi screen mode Your camcorder shoots 9 still images at about 0.5 sec intervals and displays the images on a single page divided into 9 boxes.
Page 125: Self-Timer Memory Photo Recording
Recording still images on “Memory Stick” – Memory Photo recording Self-timer memory photo recording You can record images on “Memory Stick”s with the self-timer. You can also use the Remote Commander for this operation. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the right (unlock) position.
Page 126: Recording An Image From A Tape As A Still Image
Recording an image from a tape as a still image Your camcorder can read moving picture data recorded on a tape and record it as a still image on a “Memory Stick”. Your camcorder can also take in moving picture data through the input connector and record it as a still image on a “Memory Stick”.
Page 127: Recording A Still Image From Other Equipment
Recording an image from a tape as a still image Sound recorded on a tape You cannot record the audio from a tape. Titles which have already been recorded on tapes You cannot record the titles on “Memory Stick”s. The title does not appear while you are recording a still image with PHOTO.
Page 128 Recording an image from a tape as a still image If your TV or VCR has an S VIDEO jack Connect using an S video cable (optional) to obtain high-quality pictures. With this connection, you do not need to connect the yellow (video) plug of the A/V connecting cable.
Page 129: Recording Moving Pictures On "Memory Stick"S - Mpeg Movie Recording
Recording moving pictures on “Memory Stick”s – MPEG movie recording You can record moving pictures with sound on “Memory Stick”s. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the right (unlock) position.
Page 130 Recording moving pictures on “Memory Stick”s – MPEG movie recording Note Sound is recorded in monaural. When the POWER switch is set to MEMORY The following functions do not work: – Wide mode – Digital zoom – SteadyShot function – SUPER NIGHTSHOT –...
Page 131: Recording A Picture From A Tape As A Moving Picture
Recording a picture from a tape as a moving picture Your camcorder can read moving picture data recorded on a tape and record it as a moving picture on a “Memory Stick.” Your camcorder can also take in moving picture data through the input connector and record it as a moving picture on a “Memory Stick.”...
Page 132 Recording a picture from a tape as a moving picture Notes • Sound recorded in 48 kHz is converted to one in 32 kHz when recording images from a tape to “Memory Stick”s. • Sound recorded in stereo is converted to monaural sound when recording from tapes. When the access lamp is lit or flashing Do not shake or strike the unit.
Page 133: Recording A Moving Picture From Other Equipment
Recording a picture from a tape as a moving picture Recording a moving picture from other equipment Before operation •Set DISPLAY to LCD in the menu settings. (The default setting is LCD.) •Select A/V t DV OUT to OFF in the menu setting (p. 105). (The default setting is OFF.) (1) Set the POWER switch to VCR.
Page 134 Recording a picture from a tape as a moving picture Using the i.LINK cable (DV connecting cable) DV OUT (optional) : Signal flow Note The “ ” flashes in the following instances. If this happens, eject and insert “Memory Stick“ again, and record distortion-free images. –...
Page 135: Superimposing A Still Image In A "Memory Stick" On A Moving Picture - Memory Mix
Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX You can superimpose a still image you have recorded on a “Memory Stick” on top of the moving picture you are recording. You can record the superimposed images on a tape or a “Memory Stick”. (However, you can record only superimposed still images on the “Memory Stick”.) M.
Page 136 Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Recording a superimposed image to tape Before operation • Insert a tape for recording into your camcorder. • Insert a “Memory Stick” recorded with still images into your camcorder. (1) Set the POWER switch to CAMERA.
Page 137 Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Items to adjust M. CHROM The color (blue) scheme of the area in the still image which is to be swapped with a moving picture M.
Page 138 Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Recording a superimposed image to “Memory Stick” as a still image Before operation Insert a recorded “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the right (unlock) position.
Page 139 Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Items to adjust M. CHROM The color (blue) scheme of the area in the still image which is to be swapped with a moving picture M.
Page 140: Copying Still Images From A Tape - Photo Save
Copying still images from a tape – Photo save Using the search function, you can automatically take in only still images from tapes and record them on a “Memory Stick” in sequence. Before operation • Insert a recorded tape into your camcorder and rewind the tape. •...
Page 141 Copying still images from a tape – Photo save When the access lamp is lit or flashing Do not shake or strike your camcorder. As well do not turn the power off, eject a “Memory Stick” or remove the battery pack. Otherwise, the image data breakdown may occur.
Page 142: Viewing A Still Image - Memory Photo Playback
Viewing a still image – Memory photo playback You can play back still images recorded on a “Memory Stick”. You can also play back 6 images including moving pictures in order at a time by selecting the index screen. Before operation Insert a “Memory Stick”...
Page 143 Viewing a still image – Memory photo playback Screen indicators during still image playback Image number/Total number of recorded images 6 / 40 100–0006 MEMORY PLAY Print mark Protect indicator JUL 4 2001 Recording data 12:05:56 AM – INDEX Data Directory Number/File Number Recording data To display the recording data (date/time or various settings when recorded), press DATA CODE during playback.
Page 144 Viewing a still image – Memory photo playback Playing back 6 recorded images at a time (index screen) You can play back 6 recorded images at a time. This function is especially useful when searching for a particular image. (1) Set the POWER switch to MEMORY. Make sure that the LOCK is set to the right (unlock) position.
Page 145: Viewing A Moving Picture - Mpeg Movie Playback
Viewing a moving picture – MPEG movie playback You can play back moving pictures recorded on a “Memory Stick.” You can also play back 6 images including still images in order at a time by selecting the index screen. Before operation Insert a “Memory Stick”...
Page 146 Viewing a moving picture – MPEG movie playback Screen indicators during moving picture playback Image size Picture number/Total number of recorded pictures 1 / 2 0 MO V 0 0 0 0 1 MEMOR Y P L A Y 0 : 1 2 MPEG Memory playback indicator –...
Page 147: Viewing Images Using Your Computer
Viewing images using your computer You can view data recorded on the “Memory Stick” using your computer. Notes •Data recorded on the “Memory Stick” is stored in the following formats. Make sure that applications that support these file formats are installed on your computer. –...
Page 148: Installing The Usb Driver
Viewing images using your computer Installing the USB driver Before connecting your camcorder to your computer, install the USB driver to the computer. The USB driver is contained together with application software for viewing images on a CD-ROM which is supplied with your camcorder. Do not connect the USB cable to your computer before installation of the USB driver is completed.
Page 149 (5) Move the following 2 files from the window opened in step 3 to the System Folder icon in the window opened in step 4 (drag and drop). •Sony Camcorder USB Driver •Sony Camcorder USB Shim (6) When “Put these items into the Extensions folder?” appears, click OK.
Page 150: Viewing Images
Viewing images using your computer Viewing images For Windows users (1) Turn on the power of your computer and allow Windows to load. (2) Connect one end of the USB cable to the USB jack on the camcorder and the other end to the USB connector on your computer.
Page 151: For Macintosh Users
Viewing images using your computer Unplug the USB cable/Eject the “Memory Stick” For Windows 2000/Me users To unplug the USB cable or eject the “Memory Stick”, follow the procedure below. (1) Move the cursor to the “Unplug or Eject Hardware” icon on the Task Tray and click to cancel the applicable drive.
Page 152 Viewing images using your computer Image file storage destinations and image files Image files recorded with your camcorder are grouped in folders by recording mode. The meanings of the file names are as follows. ssss stands for any number within the range from 0001 to 9999.
Page 153: Enlarging Still Images Recorded On "Memory Stick"S - Memory Pb Zoom
Enlarging still images recorded on “Memory Stick”s – Memory PB ZOOM You can enlarge still images recorded on a “Memory Stick.” Before operation Insert a “Memory Stick” into your camcorder. (1) In the memory playback mode, press FN and select PAGE2. (2) Press PB ZOOM.
Page 154: Playing Back Images In A Continuous Loop - Slide Show
Playing back images in a continuous loop – SLIDE SHOW You can automatically play back images in sequence. This function is useful especially when checking recorded images or during a presentation. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY.
Page 155: Preventing Accidental Erasure - Image Protection
Preventing accidental erasure – Image protection To prevent accidental erasure of important images, you can protect selected images. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK swich is set to the right (unlock) position.
Page 156: Deleting Images
Deleting images You can delete images stored in a “Memory Stick”. You can delete all images or selected images. Deleting selected images Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK is set to the right (unlock) position.
Page 157: Deleting Selected Images On The Index Screen
Deleting images Deleting selected images on the index screen Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK is set to the right (unlock) position. (2) Press INDEX on your camcorder to display the index. (3) Press DEL.
Page 158: Deleting All The Images
Deleting images Deleting all the images You can delete all the unprotected images in a “Memory Stick”. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK is set to the right (unlock) position.
Page 159: Writing A Print Mark - Print Mark
Writing a print mark – PRINT MARK You can specify the recorded still image to print out by putting marks. This function is useful for printing out still images later. Your camcorder conforms with the DPOF (Digital Print Order Format) standard for specifying the still images to print out.
Page 160: Troubleshooting
If you run into any problem using your camcorder, use the following table to troubleshoot the problem. If the problem persists, disconnect the power source and contact your Sony dealer. If “C:ss:ss” appears on the screen, the self-diagnosis display function has worked. See page 166.
Page 161 Types of trouble and their solutions Symptom Cause and/or Corrective Actions The picture is recorded in incorrect or • NIGHTSHOT is set to ON. unnatural colors. c Set it to OFF (p. 29). Picture appears too bright, and the • NIGHTSHOT is set to ON in a bright place. subject does not appear on the c Set it to OFF (p.
Page 162 Types of trouble and their solutions In the recording and playback modes Symptom Cause and/or Corrective Actions • The battery pack is not installed, or is dead or nearly dead. The power does not turn on. c Install a charged battery pack (p. 12, 13). •...
Page 163 Types of trouble and their solutions When operating using the “Memory Stick” Symptom Cause and/or Corrective Actions The “Memory Stick” does not • The POWER switch is not set to MEMORY. c Set it to MEMORY (p. 122). function. • The “Memory Stick” is not inserted. c Insert a “Memory Stick”...
Page 164 VCR and your camcorder (p. 75, 76). • The camcorder is connected to DV equipment of other than Sony using the i.LINK cable (DV connecting cable). c Set it to IR (p. 78). • Setting program on a blank portion of the tape is attempted.
Page 165 CHARGE lamp flashes. c Install it properly (p. 12). • Something is wrong with the battery pack. c Please contact your Sony dealer or local authorized Sony service facility. The buttons do not appear on the • The DISPLAY/TOUCH PANEL button is pressed.
Page 166: Self-Diagnosis Display
Contact your Sony dealer or local authorized Sony E:62:ss service facility and inform them of the 5-digit code. (example: E:61:10) If you are unable to rectify the problem even if you try corrective actions a few times, contact your Sony dealer or local authorized Sony service facility.
Page 167: Warning Indicators And Messages
Warning indicators and messages If indicators and messages appear on the screen, check the following: See the page in parentheses “( )” for more information. Warning indicators 100–0001 C:21:00 100-0001 Warning indicator as to file Warning indicator as to “Memory Stick” Slow flashing: formatting* •The file is corrupted.
Page 168: Warning Messages
Warning indicators and messages Warning messages • CLOCK SET Set the date and time (p. 17). • FOR “InfoLITHIUM” Use an “InfoLIHIUM” battery pack (p. 15). BATTERY ONLY • CLEANING CASSETTE The video heads are dirty (p. 176). • COPY INHIBIT You tried to record a picture that has a copyright control signal (p.
Page 169: Additional Information
— Additional Information — Usable cassettes Selecting cassette types You can use the mini DV cassette only*. You cannot use any other 8 mm, Hi8, Digital8, VHS, VHSC, S-VHS, S-VHSC, Betamax, ED Betamax or DV cassette. * There are two types of mini DV cassettes: with cassette memory and without cassette memory.
Page 170: Audio Mode
Usable cassettes Audio mode 12-bit mode: The original sound can be recorded in stereo 1, and the new sound in stereo 2 in 32 kHz. The balance between stereo 1 and stereo 2 can be adjusted by selecting AUDIO MIX in the menu settings during playback. Both sounds can be played back.
Page 171: About The "Infolithium" Battery Pack
About the “InfoLITHIUM” battery pack What is the “InfoLITHIUM” battery pack? The “InfoLITHIUM” battery pack is a lithium-ion battery pack that has functions for communicating information related to operating conditions between your camcorder and an optional AC adaptor/charger. The “InfoLITHIUM” battery pack calculates the power consumption according to the operating conditions of your camcorder, and displays the remaining battery time in minutes.
Page 172: About I.link
About the Name “i.LINK” i.LINK is a more familiar term for IEEE 1394 data transport bus proposed by SONY, and is a trademark approved by many corporations. IEEE 1394 is an international standard standardized by the Institute of Electrical and Electronics Engineers.
Page 173 DV jacks, see page 76. This unit can also be connected to other i.LINK (DV) compatible equipment made by SONY (e.g. VAIO series personal computer) other than video equipment. Before connecting this unit to your computer, make sure that application software supported by this unit is already installed on your computer.
Page 174: Using Your Camcorder Abroad
Using your camcorder abroad Using your camcorder abroad You can use your camcorder in any country or area with the AC adaptor supplied with your camcorder within 100 V to 240 V AC, 50/60 Hz. When charging the battery pack, use a commercially available AC plug adaptor [a], if necessary, depending on the design of the wall outlet [b].
Page 175: Maintenance Information And Precautions
Maintenance information and precautions Moisture condensation If your camcorder is brought directly from a cold place to a warm place, moisture may condense inside your camcorder, on the surface of the tape, or on the lens. In this condition, the tape may stick to the head drum and be damaged or your camcorder may not operate correctly.
Page 176 If the above problem, [a], [b] or [c] occurs, clean the video heads for 10 seconds with the Sony DVM-12CLD cleaning cassette (optional). Check the picture and if the above problem persists, repeat cleaning.
Page 177 Maintenance information and precautions Charging the built-in rechargeable battery Your camcorder is supplied with a built-in rechargeable battery installed so as to retain the date and time, etc., regardless of the setting of the POWER switch. The built-in rechargeable battery is always charged as long as you are using your camcorder. The battery, however, will get discharged gradually if you do not use your camcorder.
Page 178 • If any solid object or liquid get inside the casing, unplug your camcorder and have it checked by a Sony dealer before operating it any further. • Avoid rough handling or mechanical shock. Be particularly careful of the lens.
Page 179 Maintenance information and precautions AC power adaptor •Unplug the unit from a wall outlet when you are not using the unit for a long time. To disconnect the power cord, pull it out by the plug. Never pull the power cord itself. •Do not operate the unit with a damaged cord or if the unit has been dropped or damaged.
Page 180: About Care And Storage Of The Lens
• If you touch the liquid, wash it off with water. • If the liquid get into your eyes, wash your eyes with a lot of water and then consult a doctor. If any problem occurs, unplug your camcorder and contact your nearest Sony dealer.
Page 181: Specifications
Specifications Video camera Input/Output connectors General recorder S video input/output Power requirements 4-pin mini DIN 7.2 V (battery pack) Luminance signal: 1 Vp-p, 8.4 V (AC power adaptor) System Average power consumption (ohms), unbalanced, sync Video recording system negative (when using the battery pack) 2 rotary heads Chrominance signal: 0.286 Vp-p, During camera recording using...
Page 182: Battery Pack
Specifications Battery pack NP-FM30 Maximum output voltage DC 8.4 V Output voltage DC 7.2 V Capacity 5.0 Wh (700 mAh) Operating temperature 0°C to 40°C (32°F to 104°F) Dimensions (approx.) 38.2 20.5 55.6 mm (1 9/16 13/16 2 1/4 in.) (w/h/d) Mass (approx.) 65 g (2.3 oz)
Page 183: Quick Reference
5 Battery/Battery terminal cover (p. 12) qa BATT (battery) release lever (p. 12) 6 Eyecup This mark indicates that this product is a genuine accessory for Sony video products. When purchasing Sony video products, Sony recommends that you purchase accessories with this “GENUINE VIDEO ACCESSORIES”...
Page 184 Identifying the parts and controls qs MIC (PLUG IN POWER) jack qg FOCUS button (p. 59) qd A/V jack qh S VIDEO jack (p. 40, 75, 89) (LANC) jack qj Holding Grip LANC stands for Local Application Control Bus System. The control jack is used for controlling the tape transport of video equipment and other...
Page 185 Your camcorder is equipped with a Carl Zeiss lens which can reproduce a fine image. The lens for your camcorder was developed jointly by Carl Zeiss, in Germany, and Sony Corporation. It adopts the MTF* measurement system for video camera and offers a quality as the Carl Zeiss lens.
Page 186 Identifying the parts and controls wk NIGHTSHOT switch (p. 29) ed PHOTO button (p. 41, 122) wl SUPER NIGHTSHOT button (p. 29) ef Power zoom lever (p. 27) e; BACK LIGHT button (p. 29) eg DISPLAY/TOUCH PANEL button (p. 36) ea Speaker eh RESET button (p.
Page 187 Identifying the parts and controls el “Memory Stick” slot (p. 114) rd OPEN/ZEJECT lever (p. 19) r; Viewfinder lens adjustment lever rf Tripod receptacle (p. 26) Make sure that the length of the tripod screw is less than 5.5 mm (7/32 inch). ra Cassette lid (p.
Page 188: Remote Commander
•Your camcorder works in the commander mode VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the Commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.
Page 189: Operation Indicators
Identifying the parts and controls Operation indicators LCD screen and viewfinder 1 2 0 min S T B Y 0 : 1 2 : 3 4 – 1 2 min S T I L L Z E R O S E T 1 6 : 9 W I D E M E M O R Y N E G .
Page 190: Index
Index A, B I, J, K, L AC power adaptor ....13 i.LINK ........172 Recording time ......14 Adjusting viewfinder ..... 26 Image protection ....155 Rec Review ......33 Audio dubbing ......94 Image quality mode ..... 117 Remaining battery time AUDIO MIX ......
Page 192 Sony Corporation Printed in Japan...

Sony Handycam DCR-PC9 Operating Instructions Manual

Quick Start Guide

Getting Started

Recording - Basics

Playback - Basics

Advanced Recording Operations

Advanced Playback Operations

Editing

Customizing Your Camcorder

?Memory Stick” Operations

Table of Contents

Troubleshooting

Additional Information

Quick Reference

Quick Links

Operating Instructions

Related Manuals for Sony Handycam DCR-PC9

Summary of Contents for Sony Handycam DCR-PC9

Table of Contents
