MATSONIC MS8137C User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Copyright
This publication, including all photographs, illustrations and software,
is protected under international copyright laws, with all rights re-
served. Neither this manual, nor any of the material contained herein,
may be reproduced without written consent of the author.
Version 1.0
Disclaimer
The information in this document is subject to change without notice.
The manufacturer makes no representations or warranties with re-
spect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose.
The manufacturer reserves the right to revise this publication and to
make changes from time to time in the content hereof without obliga-
tion of the manufacturer to notify any person of such revision or
changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Mi-
crosoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered
trademarks of Intel Corporation.
Other product names used in this manual are the properties of their
respective owners and are acknowledged.
Preface
Copyright © 2001
All Rights Reserved
MS8137C, V1.0
VT8366/Aug 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS8137C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MATSONIC MS8137C

Summary of Contents for MATSONIC MS8137C

  • Page 1 Corp. MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel Corporation. Other product names used in this manual are the properties of their respective owners and are acknowledged. Copyright © 2001 All Rights Reserved MS8137C, V1.0 VT8366/Aug 2001...
  • Page 2 Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gen- erates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 3: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: This device may not cause harmful interference, and This device must accept any interference received, in- cluding interference that may cause undesired operation. Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadi- an Interference-causing Equipment Regulations.

  • Page 4: About The Manual

    About the Manual The manual consists of the following: Chapter 1 Describes features of the main- board, and provides a shipping Introducing the Mainboard checklist. Go to page 1 Chapter 2 Describes installation of main- board components. Installing the Mainboard Go to page 7 Chapter 3...

  • Page 5: Table Of Contents

    Preface CHAPTER 1 Introducing the Mainboard Introduction ..................1 Checklist..................1 Standard Items ..................1 Features ..................2 Mainboard Components..............4 Choosing a Computer Case............6 CHAPTER 2 Installing the Mainboard Safety Precautions ................7 Quick Guide ..................8 Checking Jumper Settings .............. 9 Setting Jumpers..................
  • Page 6 About the Software CD-ROM............65 Folders for this Mainboard ............65 Utility Folder..................65 MS8137C Folder................66 Running the Support CD-ROM ............. 66 Utility Folder Installation Notes ............. 66 Mainboard (MS8137C) Installation Notes ........68 APPENDIX A Setting Jumpers The Panel Connector................71...

  • Page 7: Introducing The Mainboard

    Introducing the Mainboard Congratulations on purchasing the MS8137C mainboard. The MS8137C mainboard is an ATX mainboard that uses a 4-layer printed circuit board and measures 240 mm x 304 mm. The mainboard features a Socket 462 that accommodates AMD Athlon processors supporting frontside bus (FSB) speeds up to 133 MHz.

  • Page 8: Features

    USB ports, an AC 97 link for audio and modem, hardware monitoring, and ACPI/OnNow power management. The MS8137C includes a 4xAGP slot that provides four times the bandwidth of the original AGP specifi- cation. AGP technology provides a direct connection...
  • Page 9 A Communications Network Riser (CNR) slot Two IDE channels and a floppy disk drive in- terface The MS8137C supports Ultra DMA bus mastering with transfer rates of 33/66/100 MB/sec. Integrated I/O The mainboard has a full set of I/O ports and con-...

  • Page 10: Mainboard Components

    CPUFAN1 DDR1 DDR2 DIMM1 DIMM2 CPUFAN1 DIM M1 DIM M2 DDR1 DDR2 CPU SOCKET LED1 LED1 IDE2 IDE1 ATX1 AGP1 AGP1 PCI1 PCI1 CASFAN1 CASFAN1 PCI2 PCI2 1 1 1 1 PCI3 1 1 1 1 PCI3 PCI4 SPKR1 PCI4 1 1 1 1 PANEL1 PCI5...
  • Page 11 Table of Mainboard Components Label Component AGP1 Accelerated Graphics Port ATX1 Power connector Three volt realtime clock battery CASFAN1 Auxiliary case cooling fan Small (For Panasonic) Big (For SONY) CNR1 Communications Networking Riser slot CPUFAN1 Cooling fan for CPU DDR1~DDR2 Two 168 pin DDR SDRAM DIMM1 ~ DIMM2 Two 184-pin DIMM sockets...

  • Page 12: Choosing A Computer Case

    There are many types of computer cases on the market. The mainboard complies with the specifications for the ATX sys- tem case. Some features on the mainboard are implemented by cabling connectors on the mainboard to indicators and switches on the system case. Ensure that your case supports all the features required.

  • Page 13: Installing The Mainboard

    Installing the Mainboard Follow these safety precautions when installing the mainboard: Wear a grounding strap attached to a grounded device to avoid damage from static electricity. Discharge static electricity by touching the metal case of a safely grounded object before working on the mainboard.

  • Page 14: Quick Guide

    This Quick Guide suggests the steps you can take to assem- ble your system with the mainboard. The following table provides a reference for installing specific components: Locating Mainboard Components Go to page 4 Setting Jumpers Go to page 9 Installing the Mainboard in a Case Go to page 13 Installing Case Components...

  • Page 15: Checking Jumper Settings

    This section explains how to set jumpers for correct configu- ration of the mainboard. Setting Jumpers Use the mainboard jumpers to set system configuration op- tions. Jumpers with more than one pin are numbered. When setting the jumpers, ensure that the jumper caps are placed on the correct pins.

  • Page 16: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the mainboard jumpers. Pin 1 is labeled. 1 1 1 1 C P U FA N 1 D IM M 1 D IM M 2 J P 2 D D R 1 D D R 2 L E D 1 C D 2...

  • Page 17: Jumper Settings

    Jumper Settings Jumper Type Description Setting (default) 1-2: Normal 3-pin Clear CMOS 2-3: Clear 3-pin KB Wake-Up 1-2: Enable 2-3: Disable 3-pin BIOS protec- 1-2: Disable tion 2-3: Enable 1-2: 100 MHz 3-pin CPU fre- quency select 2-3: 133 MHz...
  • Page 18 Jumper 1 – enables you to clear the BIOS. Follow these in- structions: 1. Turn the system off. 2. Short pins 2 and 3 on JP1. 3. Return the jumper to the normal setting. 4. Turn the system on. The BIOS is returned to the de- fault settings.

  • Page 19: Installing The Mainboard In A Case

    Refer to the following illustration and instructions for installing the mainboard in a case: 2. Secure the mainboard with This illustration shows screws where appropriate. an example of a main- board being installed in a tower-type case: Note: Do not over- tighten the screws as this can stress the...

  • Page 20: Connecting Case Components

    After you have installed the mainboard into a case, you can begin connecting the mainboard components. Refer to the following: CPU FAN 1 C P U FA N 1 D IM M 1 D IM M 2 J P2 D D R 1 D D R 2 L ED 1 ATX1 CA SFAN 1...

  • Page 21: The Panel Connector

    The Panel Connector The panel connector provides a standard set of switch and LED connectors commonly found on ATX or micro-ATX cases. Refer to the table below for information: Device Pins Empty Empty (Pin 10) (Pin 9) Power 6, 8 ON/OFF Reset Switch Power Switch...

  • Page 22: Installing Hardware

    Installing the Processor Caution: When installing a CPU heatsink and cooling fan make sure that you DO NOT scratch the mainboard or any of the surface-mount resistors with the clip of the cooling fan. If the clip of the cooling fan scrapes across the main- board, you may cause serious damage to the mainboard or its components.
  • Page 23 CPU Installation Procedure The following illustration shows CPU installation components: Socket 426 CPU fan Pin A -1 corner Locking lever Follow these instructions to install the CPU: 1. Pull the CPU socket locking lever away from the sock- et to unhook it and raise the locking lever to the upright position.
  • Page 24 CPU fan and heatsink assem bly C PU fan con nector Lo ckin g lever C PU FA N 1 Pin A -1 co rner 6. Lower the CPU fan/heatsink unit onto the CPU and CPU socket and then snap the fan/heatsink into place. 7.

  • Page 25: Installing Memory Modules

    Installing Memory Modules This mainboard accommodates 184-pin 2.5V unbuffered Double Data Rate (DDR) or 168-pin 3.3V unbuffered Single Data Rate (SDR) SDRAM memory modules. The memory chips must be standard or registered SDRAM (Synchronous Dynamic Random Access Memory). The memory bus can run at 100 MHz or 133 MHz. If your processor operates over a 100 MHz system bus, you can in- stall PC100 or PC133 memory modules that operate over a 100 MHz or 133 MHz memory bus.
  • Page 26 The mainboard accommodates two SDR SDRAM and two DDR SDRAM modules. You must install at least one module in any of the four slots. Each module can be installed with up to 1 GB of memory; total memory capacity is 4 GB. Refer to the following to install the memory modules.

  • Page 27: Installing A Hard Disk Drive/Cd-Rom

    Installing a Hard Disk Drive/CD-ROM This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your mainboard has a primary and secondary IDE channel in- terface (IDE1 and IDE2). An IDE ribbon cable supporting two IDE devices is bundled with the mainboard.

  • Page 28: Installing A Hard Disk Drive

    Installing a Hard Disk Drive 1. Install the hard disk drive into the drive cage in your ATX system case. 2. Plug the IDE cable into IDE1. Colored stripe Pin 1 Note: Ribbon cable connectors are usually keyed so that they can only be installed correctly on the device connector.
  • Page 29 Installing a CD-ROM/DVD Drive 1. Install the CD-ROM/DVD drive into the drive cage in your ATX system case. 2. Plug the IDE cable into IDE1 (A). If you have already installed an HDD, use the other connector on the IDE cable.

  • Page 30: Installing A Floppy Diskette Drive

    5. Plug a power cable from the case power supply into the power connector on the CD-ROM/DVD drive. When you first start up your system, the BIOS should auto- matically detect your CD-ROM/DVD drive. If it doesn’t, enter the Setup Utility and configure the CD-ROM/DVD drive that you have installed.

  • Page 31: Installing Add-On Cards

    3. Plug the correct connector on the FDD cable for the 5.25-inch or 3.5-inch drive into the FDD connector (B). 4. Plug a power cable from the case power supply into the power connector on the FDD. When you first start up your system, go immediately to the Setup Utility to configure the floppy diskette drives that you have installed.
  • Page 32 1. Remove a blanking plate from the system case corre- sponding to the slot you are going to use. 2. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge connector is cor- rectly seated in the slot. Add-on card Edge connector 3.

  • Page 33: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the main- board’s optional devices: CPUFAN1 DIMM1 DIMM2 DDR1 DDR2 LED1 SPEAKER AGP1 1 1 1 1 PCI1 CASFAN1 PCI2 1 1 1 1 1 1 1 1 PCI3 1 1 1 1 PCI4 1 1 1 1...
  • Page 34 J1: Case open This jumper prevents unauthorized access to your computer by enabling an alarm that alerts you when your computer case has been opened. Sleep button connector J5: G-LED2 Editor’s Note: Please supply the information for the items above. USB2/USB3: USB port 3, 4 and 5, 6 The mainboard has two USB ports installed on the rear edge I/O port array.
  • Page 35 the modem to plug into the mainboard WOM1 connector. This enables the Wake On Modem (WOM) feature. When your system is in a power-saving mode, any modem signal auto- matically resumes the system. You must enable this item using the Power Management page of the Setup Utility. See Chapter 3 for more information.

  • Page 36: Connecting I/O Devices

    The backplane of the mainboard has the following I/O ports: Parallel port (LPT1) G am e port PS/2 m ouse PS/2 Serial port Serial port M icrophone keyboard ports CO M 1 CO M 2 Line-in Line-out PS/2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device.

  • Page 37: External Connector Color Coding

    External Connector Color Coding Many connectors now use standard colors as shown in the table below. Connector Color Analog VGA Blue Audio line-in Light blue Audio line-out Lime Digital monitor/flat panel White IEEE 1394 Grey Microphone Pink MIDI/game Gold Parallel Burgundy PS/2-compatible keyboard Purple...
  • Page 38     Notes   ...

  • Page 39: Using Bios

    Using BIOS The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the mainboard contains the ROM setup instructions for configuring the main- board BIOS. The BIOS (Basic Input and Output System) Setup Utility dis- plays the system's configuration status and provides you with options to set system parameters.

  • Page 40: The Standard Configuration

    The Standard Configuration A standard configuration has already been set in the Setup Utility. However, we recommend that you read this chapter in case you need to make any changes in the future. This Setup Utility should be used: when changing the system configuration when a configuration error is detected and you are prompted to make changes to the Setup Utility when trying to resolve IRQ conflicts...

  • Page 41: Entering The Setup Utility

    Entering the Setup Utility When you power on the system, BIOS enters the Power-On Self Test (POST) routines. POST is a series of built-in diag- nostics performed by the BIOS. After the POST routines are completed, the following message appears: Press DEL to enter SETUP Pressing the delete key accesses the Award BIOS Setup...

  • Page 42: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this main- board from the manufacturer's Web site. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows: 1. If your mainboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 43: Using Bios

    When you start the Setup Utility, the main menu appears. The main menu of the Setup Utility displays a list of the options that are available. A highlight indicates which option is cur- rently selected. Use the cursor arrow keys to move the highlight to other options.

  • Page 44: Date And Time

    Date and Time The Date and Time items show the current date and time on the computer. If you are running a Windows OS, these items are automatically updated whenever you make changes to the Windows Date and Time Properties utility. IDE Devices (None) Your computer has two IDE channels (Primary and Secondary) and each channel can be installed with one or two devices...
  • Page 45 Refer to your drive's documentation or look on the drive casing if you need to obtain this information. If no device is installed, change the value to None. Note: Before attempting to configure a hard disk drive, ensure that you have the configuration information supplied by the manufacturer of your hard drive.

  • Page 46: Advanced Bios Setup Option

    Advanced BIOS Setup Option This option displays advanced information about your system. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Advanced BIOS Features Anti-Virus Protection [Disabled] Item Help Y2K Monitor [Disabled] CPU Internal Cache [Enabled] Menu Level External Cache [Enabled] Allows you to choose...
  • Page 47 External Cache (Enabled) Most processors that can be installed in this system use ex- ternal level 2 (L2) cache memory to improve performance. Leave this item at the default value for better performance. CPU L2 Cache ECC Checking (Enabled) This item enables or disables ECC (Error Correction Code) er- ror checking on the CPU cache memory.
  • Page 48 Boot Up Floppy Seek (Enabled) If this item is enabled, it checks the size of the floppy disk drives at start-up time. You don't need to enable this item un- less you have a legacy diskette drive with 360K capacity. Boot Up NumLock Status (On) This item defines if the keyboard Num Lock key is active when your system is started.

  • Page 49: Advanced Chipset Features Option

    The disk drive software monitors the internal performance of the motors, media, heads, and electronics of the drive. The host software monitors the overall reliability status of the drive. If a device failure is predicted, the host software, through the Client WORKS S.M.A.R.T applet, warns the user of the im- pending condition and advises appropriate action to protect the data.
  • Page 50 DRAM Clock/Drive Control Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software DRAM Clock/Drive Control Current FSB Frequency Item Help Current DRAM Frequency DRAM Clock [100 MHz] Menu Level DRAM Timing [By SPD]...
  • Page 51 cycles of CAS latency depends on the DRAM timing. We re- commend that you leave this item at the default value. Bank Interleave (Disabled) Enable this item to increase memory speed. When enabled, separate memory banks are set for odd and even addresses and the next byte of memory can be accessed while the cur- rent byte is being refreshed.
  • Page 52 Mode can greatly improve the display speed. Disable this item if your graphics display card does not support this feature. AGP Driving Control (Auto) This item is used to signal driving current on AGP cards to auto or manual. Some AGP cards need stronger than normal driving current in order to operate.
  • Page 53 CPU & PCI Bus Control Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software AGP & P2P Bridge Control PCI1 Master 0 WS Write [Enabled] Item Help PCI2 Master 0 WS Write [Enabled] PCI1 Post Write...

  • Page 54: Integrated Peripherals Option

    Integrated Peripherals Option These options define the operation of peripheral components on the system's input/output ports. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Integrated Peripherals OnChip IDE Device [Press Enter] Item Help OnChip PCI Device [Press Enter] Super I/O Device [Press Enter] Menu Level...
  • Page 55 IDE Prefetch Mode (Enabled) The onboard IDE drive interfaces supports IDE prefetching, for faster drive access. If you install a primary and secondary add-in IDE interface, set this field to Disabled if the interface does not support prefetching. IDE Primary/Secondary Master/Slave PIO (Auto) Each IDE channel supports a master device and a slave de- vice.

  • Page 56: Superio Device

    OnChip AC97 Audio (Auto) Enables and disables the onboard audio chip. Disable this item if you are going to install a PCI audio add-in card. VIA-3068 MC97 Modem (Auto) Enables and disables the onboard modem. Disable this item if you are going to install an external modem. Press <Esc>...
  • Page 57 UART Mode Select (Normal) This field is available if the Onboard Serial Port 2 field is set to any option but Disabled. UART Mode Select enables you to select the infrared communication protocol: Normal (default), IrDA, or ASKIR. IrDA is an infrared communication protocol with a maximum baud rate up to 115.2K bps.
  • Page 58 ECP Mode Use DMA (3) When the onboard parallel port is set to ECP mode, the par- allel port can use DMA 3 or DMA 1. Game Port Address (201) This item sets the I/O address for the game port. Midi Port Address (330) This item sets the I/O address for the Midi function.

  • Page 59: Power Management Setup Option

    Power Management Setup Option This option lets you control system power management. The system has various power-saving modes including powering down the hard disk, turning off the video, suspending to RAM, and software power down that allows the system to be auto- matically resumed by certain events.
  • Page 60 ACPI Function (Enabled) This mainboard supports ACPI (Advanced Configuration and Power management Interface). Use this item to enable or dis- able the ACPI feature. Note: ACPI is a power management specification that makes hardware status information available to the operating system. ACPI enables a PC to turn its peripherals on and off for improved power man- agement.
  • Page 61 Video Off Option (Suspend --> Off) This option defines if the video is powered down when the system is put into suspend mode. Video Off Method (DPMS Support) This item defines how the video is powered down to save power. This item is set to DPMS (Display Power Management Software) by default.
  • Page 62 IRQ/Event Activity Detect Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software IRQ/Event Activity Detect USB Resume from S3/S4/S5 [Disabled] Item Help [OFF] LPT & COM [LPT/COM] Menu Level HDD &...
  • Page 63 PowerOn by PCI Card (Enabled) Use this item to enable PCI activity to wakeup the system from a power saving mode. Wake Up On LAN/Ring (Disabled) Use this item to enable LAN or modem activity to wakeup the system from a power saving mode. RTC Alarm Resume (Disabled) When set to Enabled, additional fields become available and you can set the date (day of the month), hour, minute and...

  • Page 64: Pnp/Pci Configuration Option

    PNP/PCI Configuration Option These options configure how PnP (Plug and Play) and PCI expansion cards operate in your system. Both the ISA and PCI buses on the Mainboard use system IRQs (Interrupt Re- Quests) and DMAs (Direct Memory Access). You must set up the IRQ and DMA assignments correctly through the PnP/PCI Configurations Setup utility for the mainboard to work properly.
  • Page 65 If you cannot get a legacy ISA (Industry Standard Architecture) expansion card to work properly, you might be able to solve the problem by changing this item to Manual, and then open- ing up the IRQ Resources and Memory Resources submenus. In the IRQ Resources submenu, if you assign an IRQ Legacy ISA, then that Interrupt Request Line is reserved for a legacy ISA expansion card.

  • Page 66: Pci Health Status Option

    PCI Health Status Option On mainboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, critical temperatures, and fan speeds: CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software PC Health Status Shutdown Temperature [Disabled] Item Help Vcore...

  • Page 67: Frequency/Voltage Control

    Frequency/Voltage Control This item enables you to set the clock speed and system bus for your system. The clock speed and system bus are deter- mined by the kind of processor you have installed in your system. CMOS Setup Utility – Copyright (C) 1984 – 2001 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk [Enabled]...

  • Page 68: Load Fail-Safe Defaults Option

    Load Fail-Safe Defaults Option This option opens a dialog box that lets you install fail-safe defaults for all appropriate items in the Setup Utility: Press <Y> and then <Enter> to install the defaults. Press <N> and then <Enter> to not install the defaults. The fail-safe de- faults place no great demands on the system and are generally stable.

  • Page 69: Set Supervisor And User Passwords Options

    Set Supervisor and User Passwords Options These items can be used to install a password. A Supervisor password takes precedence over a User password, and the Supervisor can limit the activities of a User. To install a pass- word, follow these steps: 1.

  • Page 70: Save & Exit Setup Option

    Save & Exit Setup Option Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu: Exit Without Saving Highlight this item and press <Enter>...

  • Page 71: Using The Mainboard Software

    The software for this mainboard is stored in the MS8137C folder. Note: Never try to install software from a folder that is not specified for use with your mainboard.

  • Page 72: Ms8137C Folder

    MS8137C Folder You can use the software in the following sub-folders: AUDIO and IDE: Most of the sub-folders in this folder are empty, with a short README file giving directions to alternate folders for the ap- propriate software. Running the Support CD-ROM 1.
  • Page 73 from a DOS diskette temporarily in order to run the flash memory utility. PC-cillin Software The PC-cillin software program provides anti-virus protection for your system. This program is available for: ! WinNT – \UTILITY\PC-CILLIN\WINNT\SETUP.EXE ! Win9x – \UTILITY\PC-CILLIN\WIN98\SETUP.EXE Anti-virus software is provided for WINNT/2000 and WIN95/98. MediaRing Talk To install the MediaRing Talk voice modem software for the built-in modem, go to the directory \UTILITY\MEDIARING TALK;...

  • Page 74: Mainboard (Ms8137C) Installation Notes

    Mainboard (MS8137C) Installation Notes Most of the sub-folders in this folder are empty, with a short README file giving directions to alternate folders for the appropriate software.

  • Page 75: Setting Jumpers

    Setting Jumpers Jumper Settings Jumper Type Description Setting (default) 3-pin Clear CMOS 1-2: Normal 2-3: Clear 3-pin KB Wake-Up 1-2: Enable 2-3: Disable 3-pin BIOS protec- 1-2: Disable tion 2-3: Enable 3-pin CPU fre- 1-2: 100 MHz quency select 2-3: 133 MHz Jumper 1 –...
  • Page 76 Jumper 4 – Use this jumper to select the CPU frequency. Editor’s Note: Which setting should the user choose for CPU fre- quency. Should they also change the BIOS? The front side bus frequency of AMD K7 series can only be changed (100MHz or 133MHz) by manual.

  • Page 77: The Panel Connector

    The Panel Connector The panel connector provides a standard set of switch and LED connectors usually found on ATX or micro-ATX cases. Refer to the table below for information: Device Pins Empty Empty (Pin 10) (Pin 9) Power 6, 8 ON/OFF Reset Switch Power Switch...
