MATSONIC MS8318E Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Mainboard User's Manual
This publication, photographs, illustrations and software are under
the protection of international copyright laws and all rights
reserved. It does not allow any reproduction of this manual, content
and any materials contained herein without the written consent of
the authentic manufacturer.
The information in this manual is subject to change without notice.
The manufacturer does neither represent nor warrant the contents
hereof; and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Furthermore,
the manufacturer reserves the right to revise and change this
publication from time to time, without the obligation of notifying
any person of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International
Business Machines.
AMD is registered trademark of Advanced Micro Devices Inc.
Intel, Pentium/II/III/IV, Celeron and MMX are registered
trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows NT/95/98/ME/2000 are
registered trademarks of Microsoft Corporation.
PC-cillin is a registered trademark of Trend Micro Inc.
AMI is a registered trademark of American Megatrends Inc.
A3D is a registered trademark of Aureal Inc.
MediaRing Talk is a registered trademark of MediaRing Inc.
3Deep is a registered trademark of E-Color Inc.
SiS is a trademark of Silicon Integrated System Corporation.
Other names used in this publication may be trademarks and are
acknowledged.
Copyright © 2001
All Rights Reserved
MS8318E Series, V1.0
S740/December 2001

Advertisement

Table of Contents
loading

Related Manuals for MATSONIC MS8318E Series

Summary of Contents for MATSONIC MS8318E Series

  • Page 1 3Deep is a registered trademark of E-Color Inc. SiS is a trademark of Silicon Integrated System Corporation. Other names used in this publication may be trademarks and are acknowledged. Copyright © 2001 All Rights Reserved MS8318E Series, V1.0 S740/December 2001...
  • Page 2 Mainboard User’s Manual Notice: Owing to Microsoft’s certifying schedule is various to every supplier, we might have some drivers not certified yet by Microsoft. Therefore, it might happen under Windows XP that a dialogue box (shown as below) pop out warning you this software has not passed Windows Logo testing to verify its compatibility with Windows XP.

  • Page 3: Table Of Contents

    Mainboard User’s Manual Table of Contents Trademarks ................I Chapter 1..................1 Introduction ................. 1 Key Features ................2 Package Contents ..............5 Static Electricity Precautions ..........6 Pre-Installation Inspection ............6 Chapter 2..................7 Mainboard Installation ..............7 Mainboard Components............8 I/O Ports..................
  • Page 4 Mainboard User’s Manual...

  • Page 5: Chapter 1

    1: Introduction Chapter 1 Introduction This mainboard has a Socket-462 processor socket for the AMD K7 type of processors. You can install any of these processors on this mainboard. This mainboard supports front-side bus speed of 200/266MHz. This mainboard uses SiS 740 chipset that supports a DDR interface, Ultra DMA 33/66/100 function and remarkably high system performance under all types of system operations.

  • Page 6: Key Features

    Mainboard User’s Manual Key Features The key features of this mainboard include: Socket-462 Processor Support Supports AMD Athlon XP/Athlon/Duron processors Supports 200/266 MHz Front-Side Bus Processors are automatically configured using firmware and a synchronous Host/DRAM Clock Scheme. Memory Support Three 184-pin DIMM slots for DDR memory modules Supports 100/133 MHz SDRAM, up to 200/266 MHz DDR memory bus Maximum installed memory is 1.5GB...
  • Page 7 1: Introduction Meets ACPI 1.0b and APM 1.2 requirements, keyboard power on/off Supports Suspend, Shutdown, Wake on LAN, Wake on Modem, Wake on Alarm, Interrupt Wake-up from Keyboard/Mouse AC97 Codec Compliant AC97 2.1 specification Supports 18-bit ADC (Analog Digital Converter) and DAC (Digital Analog Converter) as well as 18-bit stereo full- duplex codec Built-in Ethernet LAN...
  • Page 8 Mainboard User’s Manual Onboard Flash ROM Supports 2MB Flash Rom on board, provides complete Advance Configuration Power Interface(ACPI) and Legacy Supports Ultra DMA 66/100 and fully compliant with PC’97 and PC 98 Spec. Bundled Software PC-Cillin2000 provides automatic virus protection under Windows 95/98/NT/2000 MediaRing Talk provides PC to PC or PC to Phone internet phone communication...

  • Page 9: Package Contents

    1: Introduction Package Contents Your mainboard package ships with the following items: The mainboard This User’s Guide 1 UDMA/66 IDE cable 1 Floppy disk drive cable Support software on CD-ROM disk Optional Accessories You can purchase the following optional accessories for this mainboard.

  • Page 10: Static Electricity Precautions

    Mainboard User’s Manual Static Electricity Precautions Static electricity could damage components on this mainboard. Take the following precautions while unpacking this mainboard and installing it in a system. 1. Don’t take this mainboard and components out of their original static-proof package until you are ready to install them. 2.

  • Page 11: Chapter 2

    2: Mainboard Installation Chapter 2 Mainboard Installation To install this mainboard in a system, please follow the instructions in this chapter: Identify the mainboard components Install a CPU Install one or more system memory modules Verify that all jumpers or switches are set correctly Install the mainboard in a system chassis (case) Connect any extension brackets or cables to connecting headers on the mainboard...

  • Page 12: Mainboard Components

    Mainboard User’s Manual Mainboard Components Use the diagram below to identify the major components on the mainboard. Note: Any jumpers on your mainboard that do not appear in the illustration above are for testing only.

  • Page 13: I/O Ports

    2: Mainboard Installation I/O Ports The illustration below shows a side view of the built-in I/O ports on the mainboard. Parallel Port PS/2 Mouse LAN Port Game/MIDI Port Serial COM1 Line-Out PS/2 Keyboard Microphone VGA Port Line-In USB Ports Install A CPU This mainboard has a Socket-462 that supports AMD K7 processors.

  • Page 14: Install Memory

    Mainboard User’s Manual Installing a Socket-462 Processor Install a processor into the ZIF (Zero Insertion Force) Socket-462 on the mainboard. 1. Locate the Socket-462 and CPUFAN. Pull the locking lever out slightly from the socket and raise it to the upright position. Socket-462 CPUFAN Pin-1 Corner...
  • Page 15 2: Mainboard Installation It doubles the rate to 1.6 GBps and 2.1 GBps by transferring data on both the rising and falling edges of the clock. DDR SDRAM uses additional power and ground lines and requires 184-pin 2.5V unbuffered DIMM module rather than the 168-pin 3.3V unbuffered DIMMs used by SDRAM.

  • Page 16: Setting Jumper Switches

    Mainboard User’s Manual Setting Jumper Switches Jumpers are sets of pins which can be connected together with jumper caps. The jumper caps change the way the mainboard operates by changing the electronic circuits on the mainboard. If a jumper cap connects two pins, we say the pins are SHORT. If a jumper cap is removed from two pins, the pins are OPEN.

  • Page 17: Install The Mainboard

    2: Mainboard Installation Install the Mainboard Install the mainboard in a system chassis (case). The board is an ATX size mainboard with a twin-tier of I/O ports. You can install this mainboard in an ATX case. Ensure that your case has an I/O cover plate that matches the ports on this mainboard.

  • Page 18: Optional Extension Brackets

    Mainboard User’s Manual Optional Extension Brackets For this mainboard, you can also obtain a USB module extension bracket for more USB ports. Install them by following the steps below. Note: All the ribbon cables used on the extension brackets have a red stripe on the Pin-1 side of the cable.
  • Page 19 2: Mainboard Installation Serial Port Extension Bracket This bracket has one serial port – COM2 (9-pins). COM2 Serial Port COM2 Seria Port Extension Bracket 1. On the mainboard, locate the header COM2 for this bracket. 2. Plug the serial cable into COM2. 3.

  • Page 20: Install Other Devices

    Mainboard User’s Manual Install Other Devices Install and connect any other devices in the system following the steps below. IDE2 IDE1 Floppy Disk Drive The mainboard ships with a floppy disk drive cable that can support one or two drives. Drives can be 3.5” or 5.25” wide, with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB.
  • Page 21 2: Mainboard Installation Install the device(s) and connect power from the system power supply. Use the cable provided to connect the device(s) to the Primary IDE channel connector IDE1 on the mainboard. If you want to install more IDE devices, you can purchase a second IDE cable and connect one or two devices to the Secondary IDE channel connector IDE2 on the mainboard.

  • Page 22: Expansion Slots

    Mainboard User’s Manual Onboard LAN LED Connections If you have a set indicator LEDs for the onboard LAN communication, you can connect the LED cable to the header PLED, the onboard LAN run in 100 Mbps mode when the LED lit Expansion Slots This mainboard has three 32-bit PCI slots and one AMR slot.

  • Page 23: Chapter 3

    3: BIOS Setup Utility Chapter 3 BIOS Setup Utility Introduction The BIOS Setup Utility records computer’s settings and information, such as date and time, type of installed hardware, and various configuration settings. Your computer applies the information to initialize all the components when booting up, and basic functions of overall coordination between system components.

  • Page 24: Running The Setup Utility

    Mainboard User’s Manual Running the Setup Utility Each time your computer starts, before the operating system loads, a message appears on the screen that prompts you to “Hit <DEL> if you want to run SETUP”. When you see this message, press the Delete key and the Main menu page of the Setup Utility appears on your monitor.

  • Page 25: Standard Cmos Setup Page

    3: BIOS Setup Utility Standard CMOS Setup Page Use this page to set basic information such as the date, the time, the IDE devices, and the diskette drives. If you press the F3 key, the system will automatically detect and configure the hard disks on the IDE channels.

  • Page 26: Advanced Setup Page

    Mainboard User’s Manual Advanced Setup Page Use this page to set more advanced information about your system. Take some care with this page. Making changes can affect the operation of your computer. AMIBIOS SETUP – ADVANCED SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved Shared Memory Size 32 MB AGP Comp.
  • Page 27 3: BIOS Setup Utility Password Check If you have entered a password for the system, use this item to determine if the password is required to enter the Setup Utility (Setup) or required both at start-up and to enter the Setup Utility (Always). Boot to OS/2 Enable this item if you are booting the OS/2 operating system and you have more than 64MB of...

  • Page 28: Power Management Setup Page

    Mainboard User’s Manual Power Management Setup Page This page sets some of the parameters for system power management operation. AMIBIOS SETUP – POWER MANAGEMENT SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved ACPI Aware O/S Power Management Enabled Suspend Time Out Disabled Hard Disk Time Out Disabled...

  • Page 29: Pci / Plug And Play Setup Page

    3: BIOS Setup Utility LAN/Ring Power Your system can enter a software power down. If you enable this item, the system can automatically resume if there is traffic on the network adapter. Keyboard If you enable this item, you can turn the system on PowerOn Function and off by pressing hot keys on the keyboard.

  • Page 30: Load Optimal Settings

    Mainboard User’s Manual Load Optimal Settings If you select this item and press Enter a dialog box appears. If you press Y, and then Enter, the Setup Utility loads a set of fail-safe default values. These default values are not very demanding and they should allow your system to function with most kinds of hardware and memory chips.
  • Page 31 3: BIOS Setup Utility OnBoard FDC Use this item to enable or disable the onboard floppy disk drive interface. OnBoard Serial Use these items to enable or disable the onboard PortA COM1/2 serial port, and to assign a port address. OnBoard Ir Port Use this item to define the protocol for an infrared port if you have installed an optional IR port.

  • Page 32: Cpu Pnp Setup Page

    Mainboard User’s Manual CPU PnP Setup Page This page lets you manually configure the mainboard for the CPU. The system will automatically detect the kind of CPU that you have installed and make the appropriate adjustments to the items on this page. AMIBIOS SETUP –...

  • Page 33: Hardware Monitor Page

    3: BIOS Setup Utility Hardware Monitor Page This page sets some of the parameters for the hardware monitoring function of this mainboard. AMIBIOS SETUP – HARDWARE MONITOR (C) 2000 American Megatrends, Inc. All Rights Reserved *** System Hardware *** Vcore 1.720V Vcc 2.5V 2.496V...

  • Page 34: Exit

    Mainboard User’s Manual Change or Remove the Password Highlight this item, press Enter and type in the current password. At the next dialog box, type in the new password, or just press Enter to disable password protection. Exit Highlight this item and press Enter to save the changes that you have made in the Setup Utility configuration and exit the program.

  • Page 35: Using The Mainboard Software

    4: Software & Applications Using the Mainboard Software About the Software CD-ROM The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your mainboard version.

  • Page 36: Utility Software Reference

    Mainboard User’s Manual Utility Software Reference All the utility software available on the CD-ROM is Windows compliant. It is provided only for the convenience of customers. The following software is furnished under license and may only be used or copied in accordance with the terms of the license. Note: The software in these folders is subject to change at anytime without prior notice.
  • Page 37 4: Software & Applications MediaRing Talk – Telephony Software To install the MediaRing Talk voice modem software for the built- in modem, run MRTALK-SETUP72.EXE from the following directory: \UTILITY\MEDIARING TALK Super Voice – Fax/Modem Software To install the Super Voice voice, fax, data communication application for use with the built-in fax/modem, run PICSHELL.EXE from the following directory: \UTILITY\SUPER VOICE...
  • Page 38 Mainboard User’s Manual \UTILITY\LANGUAGE GENIUS\ENG\LANGUAGEGENIUS PageABC The PageABC application software enables you to create your own home page. To install the PageABC, run SETUP.EXE from the following directory: \UTILITY\PageABC This concludes Chapter 4.
