9. Connect the pulse wires from the Left and Right
Handrail Assemblies (112, 113) to the pulse wires from
the Console (103). Insert the included ties through the
tie blocks attached to the back of the Console Base
(109). Loop the ties around the pulse wires, Upright
Wire (116), and TV Cable (130) and tighten the ties
around the wires.
Insert all wires and cables into the top of the Upright
(93).
10. Attach the Console Base Back (107) with nine #8 x 1/2"
Screws (88) and two #8 x 3/4" Screws (86) as shown.
Be careful not to overtighten the Screws.
11. After the incline trainer is placed in the location where
it will be used (see HOW TO MOVE THE INCLINE
TRAINER on page 13), make sure that both Rear
Leveling Feet (38) and the Base Pads (not shown)
rest firmly on the floor. If the incline trainer rocks even
slightly, turn one of the Rear Leveling Feet clockwise or
counterclockwise until the rocking motion is eliminated.
Plug the Power Cord (118) into the Frame (22) and at-
tach the Power Cord Bracket (64) with two #10 x 1/2"
Screws (34).
9
113
Tie
116
93
10
88
88
86
11
11
112
103
109
Pulse 130
Ties
Wires
93
88
88
107
86
64
34
34
22
38
118
