Value
LCR System Folder Copy
Accessing properties for shared folders
ASM provides properties information for shared folders pool and for any shared folder on your HP
All-in-One Storage System. Using properties information, you can determine details about shared-folder
status, including allocated space, and nested shares (if any), whether shared-folder storage is online
or offline, and any warning or critical status indicators.
1. In the Actions pane, select Application View.
2. From the Filters drop-down menu, select Shared Folders or All.
3. Do one of the following:
• Select Shared Folders in the content pane and then click Properties in the Actions pane.
• Right-click Shared Folders in the content pane and select Properties.
General tab— (Shared folders pool, shared folders) Displays the shared folder name, type of
•
shared folder, share path on your HP All-in-One Storage System, share description, and the shared
folder operating status:
Table 27 Operating status: Shared folder properties
Status indicator
OK
Warning
Critical
• Storage tab—(Shared folders) Displays the shared folder storage space, including allocated space,
used space, free space, and the following storage allocation details:
Table 28 Storage tab: Shared folder properties
Property
Storage Server Host Name
Storage Server Volume - Name
Storage Server Volume - Status
Storage Server Volume -
Exclusive Storage
Storage Server Volume - RAID
Level
98 Monitoring storage
Description
Path to LCR system file copies
Value
The storage is online.
The storage has surpassed the percent full warning threshold. See the
Alerts list for more information. See
descriptions.
Shared folder storage has past the allocated storage limit and alerts
are shown. See the Alerts list for more information. See
45 on page 113 for alert descriptions.
Value
Name of your HP All-in-One Storage System.
Name of the volume on your HP All-in-One Storage System where the
shared folder is stored.
Status of the volume that holds the shared folder on your HP All-in-One
Storage System.
Indicates if shared folder's storage is configured with exclusive storage.
See Table 19 on page 72 for more information.
The RAID level to which the shared folder's storage is configured. See
Customizing RAID levels on page 73 for more information.
Table 45 on page 113 for alert
Table
