Accessing storage area properties

When Storage View is selected in the Actions pane, you can view the storage status, alerts, and
properties for the following storage areas on your HP All-in-One Storage System:
• Volumes
• Logical disks
Do one of the following:
• Select the item in the content pane and then click Properties in the Actions pane.
• Right-click the item in the content pane and select Properties.
Accessing properties for HP All-in-One Storage System volumes
ASM provides properties information for any volume on a logical disk on your HP All-in-One Storage
System.
1. In the Actions pane, select Storage View.
2.
Do one of the following:
• Select any Volume (Vol) area in the content pane and then click Properties in the Actions
pane.
• Right-click any Volume (Vol) area in the content pane and select Properties.
Accessing properties for HP All-in-One Storage System logical disks
ASM provides properties information for the logical disks created on your HP All-in-One Storage
System by ASM.
1. In the Actions pane, select Storage View.
2. Do one of the following:
• Select any logical disk in the content pane and then click Properties in the Actions pane.
• Right-click any logical disk in the content pane and select Properties.
Properties window
ASM provides properties information for any logical disks and for any logical disk created on your
HP All-in-One Storage System.
General tab—Based on the application opened, logical disks or volumes, it will list the operating
status for that application only.
Table 39 Operating status: General tab
Status indicator
OK
Warning
Critical
106 Monitoring storage
Value
The storage is online. No alerts.
See the Alerts list for more information. See
descriptions.
See the Alerts list for more information. See
descriptions.
Table 45 on page 113 for alert
Table 45 on page 113 for alert
