HP STORAGEWORKS ALL-IN-ONE STORAGE SYSTEM User Manual page 116

Object Alert text
Health: Failing
but still
working
Health: Failing
redundancy
but one mirror
still working
Health: Failed
redundancy
but one mirror
still working
Health: Failed
redundancy,
the last mirror
is failing
Health: Failed
Transition
state:
Extending
Transition
state:
Reconfiguring
116 Troubleshooting, servicing, and maintenance
Description Possible cause
A hard drive is failing
Hard drive is failing.
but still working.
Logical disk is
configured as RAID 1
or RAID 1+0(10).
One of the pair of
Hard drive is failing.
mirrored hard drives
is failing but the other
hard drive is still
working.
Logical disk is
configured as RAID 1
or RAID 1+0(10).
One of the pair of
Hard drive has failed.
mirrored hard drives
has failed but the
other hard drive is still
working.
Logical disk is
configured as RAID 1
or RAID 1+0(10).
Hard drive has failed
One of the pair of
and another hard
mirrored hard drives
drive is failing.
has failed and the
other hard drive is
failing.
Hard drive(s) with
storage allocated to
the logical disk have
Logical disk has failed. The logical disk
failed. cannot be rebuilt. The
logical disk and data
on the logical disk are
lost.
ASM is growing a
logical disk (LUN) to
The logical disk is
allocate new or more
growing. Performance
storage to an
is degraded. Reads
application
and writes can still be
component,
performed to logical
user-defined
disk.
application, or shared
folder.
Configuration changes
are being made to the
The logical disk is
logical disk by an
being reconfigured.
application other than
ASM.
Solution
Replace failing hard drive
now (optional) or replace
hard drive after it fails.
Replace failing hard drive
now (optional) or replace
hard drive after it fails.
Replace failed hard drive
immediately to restore
redundancy.
Replace failed hard drive
immediately to restore
redundancy. If second
hard drive fails before first
is replaced, the logical
disk and data on the
logical disk will be lost.
Replace the failed hard
drives. Allocate new
storage to replace lost
storage. Restore data to
allocated space using
backups if available.
No action is required.
No action is required.
