Item Description
2 Access panel thumbscrew
3 System fan
4 Cable lock provision notch
5 PCI slot cover retainer
6 PCI slot cover retainer thumbscrew
7 PCI slot covers
Lights-Out remote management port
8
(optional)
9 Embedded NIC port (RJ-45)
10 USB 2.0 ports
11 Serial port
12 Video port
13 PS/2 keyboard port
14 PS/2 mouse port
15 Power supply cable socket
16 PSU fan

HP StorageWorks 600 All-in-One Storage System

The following figures show components, controls, and indicators located on the front and rear panels
of the AiO600.
40 Storage system components
Status / Description
N/A
N/A
N/A
N/A
N/A
One slot populated with HP Smart Array E200 controller
Management NIC activity and link
Blinking green = Ongoing network activity
Green = Existing network link
Embedded NIC link and activity
Orange = 10/100 Mbps connection
Green = GbE link connection
Blinking yellow = Ongoing network activity
N/A
N/A
N/A
N/A
N/A
N/A
N/A
