• General tab—(Exchange, Exchange storage groups, and components) Displays the name of the
application, the total capacity reserved for the application, and its operating status:
Table 21 Operating status: Exchange properties
Status indicator
OK
Warning
Critical
Table 22 Details tab: Exchange storage group properties
Property
Exchange Server
Exchange Version
Days before log file removal
Directory Server
Server Type
Clustered
Replication Type
LCR status
LCR Copy
LCR Log Folder Copy
LCR System Folder Copy
• Data Protection tab—(Exchange storage groups, exchange storage group components) Allows
you to schedule backups or run a backup of the storage group, or restore the storage group from
a backup. It also allows you to schedule snapshots or take a snapshot of the storage group, expose
a snapshot, or revert the storage group to a past snapshot. See
more information.
• Storage tab—(Exchange storage group properties) Displays the storage group component's storage
space, including allocated space, used space, free space, and the following storage allocation
details:
Table 23 Storage tab: Exchange storage group component properties
Property
Application Path
Value
Exchange is running and storage is online. No alerts.
See the Alerts list for more information. See
descriptions.
See the Alerts list for more information. See
descriptions.
Value
Name of server where Exchange storage is being hosted.
Version of Exchange.
The number of days before log files are deleted from the server.
The domain controller used by the server.
The type of Exchange installation: Front-end or Back-end. ASM can only
host storage from Back-end Exchange servers, because Front-end Exchange
installations do not actually store mailboxes and other Exchange data.
Indicates whether the server that hosts SQL Server is part of a cluster.
Type of Exchange replication enabled.
Indicates Exchange status for LCR.
Indicates if Exchange component is the original or a copy.
Path to the LCR log file copies
Path to LCR system file copies
Value
Path to the file directory on the server that hosts Exchange where the
storage group component's data is saved by Exchange. The file
directory is located on the volume created on the iSCSI LUN exported
by ASM to the server that hosts Exchange.
Table 45 on page 113 for alert
Table 45 on page 113 for alert
"Data protection" on page 81 for
All-in-One Storage System 95
