Operate Gemini Utilities

The Rimage Producer Software Suite includes an application called Gemini Utilities, which is
used to update the autoloader firmware. It may also be used to change the display name of the
Rimage DLN5200/DL5200 and to enable the beeper. The Rimage DLN5200 displays the
computer name on the operator panel, which is helpful to identify the computer on the network.
Tip: To access Gemini Utilities, use the remote desktop connection from a networked PC, or
connect a monitor, keyboard, and mouse to the DLN5200.

Starting Gemini Utilities

1. Close all open applications and stop all Rimage
Services.
Note: Refer to your Rimage Software online
help for additional information.
2. Navigate: Start > Programs > Rimage > Utilities
> Gemini Utilities. Gemini Utilities opens.
Note: When the desired tasks
restart the Rimage Services.

Changing the autoloader display name

Use Gemini Utilities to enter the name displayed on the operator panel.
1. Select the Override Name checkbox.
2. Clear the Use Computer Name checkbox.
3. In the Display Name field, enter the new name.
4. To update the firmware with the new name, select Set DiscLab Params.

Enabling the beeper

You can change the number of beeps that occur when there is an error.
1. From the # of Beeps on Fault dropdown list, select the number of beeps you wish to hear
when there is an error.
Tip: To disable the beeper, set the number to zero.
2. Select Set DiscLab Params to update the firmware.
110768_D
are complete,
Operate Gemini Utilities
15
