Loading discs

The supply bin can be loaded with 50
discs. Use thermal printable discs
compatible with the Everest printer.
1. Open the supply door.
2. Remove the supply bin.
3. Place the discs in the supply bin with
the recording side facing down.
Important! Hold the discs by the
edge. Fingerprints affect print
quality.
4. Place the supply bin on the base
plate.
5. Rotate the supply bin until it drops
into the notches.
6. Close the supply door.

Removing or installing the front panel

Removing the front panel
Grasp the sides of the front panel and pull out.
Note: The front panel has four pins that
are held in with retaining clips.
Installing the front panel
Align the pins to the retaining clips and press
in the front panel.
110768_D
Operate the Rimage DLN5200/DL5200
Supply Bin
Base Plate
Notch
Front Panel
Supply
Door
11
