Rimage DLN5200

Before you begin:

This document is intended for people who are familiar with hardware setup, software installation, and Windows operating systems.
If you do not understand the procedures in this document, ask your computer technician for help.
1
Set up your DLN5200.
a. Remove the tape
from the front cover.
Tape
Tape
1

Setup and Installation

™
b. Remove the front
c. Remove the tape from
cover.
Tape
d. Remove the tape
the transfer slides inside
the autoloader.
Tape
e. Remove the tape
from the supply bin.
from the printer
mounting plate.
Tape
110769_H

Advertisement

loading
Need help?

Need help?

Do you have a question about the DLN5200 and is the answer not in the manual?

Questions and answers

Related Manuals for Rimage DLN5200

Summary of Contents for Rimage DLN5200

  • Page 1: Setup And Installation

    This document is intended for people who are familiar with hardware setup, software installation, and Windows operating systems. If you do not understand the procedures in this document, ask your computer technician for help. Set up your DLN5200. a. Remove the tape from the front cover.
  • Page 2 DLN5200 to the printer. b. Place the printer on the DLN5200 so that the plastic feet slide into the slots on the printer plate. c. Connect the D-shaped cable from the autoloader to the printer as indicated by the D-shaped label.

  • Page 3: Connect The Cables

    Connect the cables. a. Be sure that the power switch is in the off position. b. Connect the power cord from the DLN5200 to a power outlet.  Connect a monitor, mouse, and keyboard (optional). a. Connect the mouse to the embedded PC.

  • Page 4: Learn More

    For information about submitting orders to the DLN5200 across a network, refer to the Advanced Setup (Network) Guide. For information about operating and maintaining the DLN5200, refer to the DLN5200 User Guide included with your product. For additional support and product information, go to www.rimage.com/support.html.
