1. INTRODUCTION

As the Flagship 8x8 HDBaseT™ Matrix, the PU-8H8HBTE solution offers
complete HDBaseT™ 5-Play convergence. Installers can switch and
distribute up to 8 HDMI sources, LAN (Local Area Network), 2-Way IR, and
PoE (Power over Ethernet) to lengths of up to 100m using CAT5e/6 cable
infrastructure. Control of the matrix is via IP control, RS-232, IR remote, or
manual selection buttons. This single box solution will enable an installer
to confidently integrate an eight zone multi-room AV system. The PU-
8H8HBTE is designed to be used with the PU-507-RX Receiver which can
utilise PoE capabilities of the matrix.
Use the LAN serving capabilities of the matrix to add internet connectivity
to every zone. In addition, this matrix also features IP control allowing
users to access and control the matrix remotely and also allow additional
options for integration of third-party control systems. CYP provide control
drivers for control systems such as Control 4, RTI, Crestron, AMX, Control
FX, and RTI. These are available at no extra cost.

2. APPLICATIONS

• Domestic HDMI Matrix System
• Video/TV wall display and control
• Security surveillance and control
• Commercial advertising, display and control
• University lecture hall, display and control
• Retail sales and demonstration

3. PACKAGE CONTENTS

• HDBaseT ™ 8×8 HDMI Matrix over CAT5e/6/7
• 9×IR Extender
• 9×IR Blaster
• 2×24 V/6.25 A DC Power Adaptor (1 for PoE)
• 1×IR Remote Control
• Operation Manual
