Side Panel; Remote Control - CYP PU-8H8HBTE Operation Manual

10
DC 24V MAIN POWER: Plug the 24 V DC power supply into the unit and
connect the adaptor to an AC outlet.
11
PoE 24V: Plug the 24 V PoE power supply into the unit and connect the
adaptor to an AC outlet. This unit will mainly power PoE (Power over
Ethernet) capaable receiver units.
Warning: Please do not connect the CAT5e/6/7 cable into the
receiver's LAN port.

6.3 Side Panel

1
Fan Ventilator: These are air ventilation areas, DO NOT block these
areas or cover it with any object. Please allow adequate space around
the unit for air circulation.

6.4 Remote Control

1
2
5
1
1
POWER: Press this button to
switch on the device or set it to
standby mode.
2
IN: Input ports selection 1~8.
3
OUT: Output ports selection A~H.
3
