8. SPECIFICATIONS

Video Bandwidth
Input Ports
Output Ports
ESD Protection
Power Supply
Dimensions
Weight
Chassis Material
Silkscreen Color
Operating Temperature
Storage Temperature
Relative Humidity
Power Consumption
15
255 MHz/6.75 Gbps
8×HDMI , 9×IR Extender, 1×RS-232,
1×LAN, 1×Mini USB-B type(for firmware
update only)
8×CAT5e/6/7, 9×IR Blaster
Human-body Model:
± 8kV (Air-gap discharge)
± 4kV (Contact discharge)
24 V/6.25 A DC (US/EU standards, CE/
FCC/UL certified)
438 mm (W)×255 mm (D)×93 mm (H)
4238g (4H4CV), 4458g (8H8CV)
Metal
Black
0 ºC~40 ºC/32 ºF~104 ºF
−20 ºC~60 ºC/−4 ºF~140 ºF
20~90 % RH (non-condensing)
64 W Tx (Main), 56 W Rx (PoE)
