6.6 RS-232 Pin Assignment

PU-8H8HBTE
PIN
Assignment
1
NC
2
Tx
3
Rx
4
NC
5
GND
6
NC
7
NC
8
NC
9
NC
Baud Rate: 19200 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None
7
Remote Control Console
PIN
Assignment
1
NC
2
Rx
3
Tx
4
NC
5
GND
6
NC
7
NC
8
NC
9
NC
