6.4 IR Cable Pin Assignment

IR Blaster
IR Extender

6.5 RS-232 Pin Assignment

MATRIX
Pin
1
2
3
4
5
6
7
8
9
Baud Rate: 19200 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None
1
2
3
1
2
3
Assignment
NC
Tx
Rx
►
NC
◄
GND
NC
NC
NC
NC
Power
IR Signal
NC
IR Signal
Power
Grounding
REMOTE CONTROL CONSOLE
Pin
1
2
3
4
5
6
7
8
9
Assignment
NC
Rx
Tx
NC
GND
NC
NC
NC
NC
6
