System board

The system board is located on the right side of the computer (viewed from the rear). It is secured
with eight Torx screws.
To remove the system board:
1. Prepare the computer for disassembly (see
2. Remove the access panel (see
3. Remove the stand (see
4. Remove the lower panel (see
5. Remove the memory modules (see
6. Remove the graphics heat sink (see
7. Remove the processor heat sink (see
8. Remove the processor (see
9. Remove the WLAN module (see
10. Disconnect all cables from the system board, noting their location for reinstallation.
Preparing to disassemble the computer on page
Access panel on page
Stand on page 38).
Lower panel on page
Memory on page
Graphics heat sink on page
Processor heat sink – model 6300 on page
Processor on page
mSATA Solid-State Drive on page
36).
40).
50).
65).
69).
70).
32).
66).
System board 83
