are logged in, which devices they have currently selected, and which mode they are in.
Users may also view this information by selecting DISPLAY CONNECTED LIST from
the pull-down menu when logged in.
7.8

Selecting a Device Port

F2 PULL-DOWN MENU TO SELECT A DEVICE PORT, PART 1
F2 PULL-DOWN MENU TO SELECT A DEVICE PORT, PART 2
┌───────────────────────────────────────────────────┐
├───────────────────────────────────────────────────┤
│01 – DEVICE_1
│03 - DEVICE_3
│05 -
│07 -
│09 -
│11 -
│13 -
│15 -
│17 -
│19 -
│21 -
│23 -
│25 -
│27 -
│29 -
│31 -
└───────────────────────────────────────────────────┘
To select a device port, the user must type SELECT along with a device port name or
number, or select CONNECT TO SERVER from the pull down menu, and then select the
device port to be connected. The user must also have permission to connect to a device
port as defined by the system administrator in their user profile. For example, to
connect to a server named Alpha on device port 23, the user may either type SELECT
Alpha, SELECT 23, or select CONNECT TO SERVER and then select Alpha from the
next menu that appears. If the system administrator has determined that the user does
┌──────────────────────────┐
LOGGED IN MENU
├──────────────────────────┤
CONNECT TO SERVER
DIR CONNECT TO SERVER
LISTEN TO SERVER
DISPLAY CONNECTED LIST
DISPLAY SERVER NAMES
DISPLAY ACTIVE DEVICES
LOGOUT
CHANGE PASSWORD
CHANGE DIRECT MODE ESC
CHANGE BREAK MODE ESC
DISPLAY HELP
└──────────────────────────┘
SELECT SERVER
02 - DEVICE_2
04 - DEVICE_4
06 -
08 -
10 -
12 -
14 -
16 -
18 -
20 -
22 -
24 -
26 -
28 -
30 -
32 -
49
