sys admin>>TERMINALS 1
Enter accepts present value
T1: 0=9600, 1=19200, 2=38400, 3=57600 | BAUD RATE: 38400>
T1: 0=1, 1=2
T1: 0=None, 1=Odd, 2=Even
T1: 0=8, 1=7, 2=6
T1: 0=DCE, 1=DTE
T1: 0=XON/OFF, 1=DTR/DSR, 2=RTS/CTS
Card installed, settings updated
sys admin>>
Terminal port connection location reference template:
B

Network Command

Network
Network Network
6.5
The NETWORK command will define a primary and secondary configuration for each card
slot. The primary configuration will define the network card's IP address, local subnet
mask, and default gateway. The secondary configuration allows the sys admin to define
a routing path to reach a specific destination network via an alternate gateway that has
a better route to that destination network. The network administrator for the
ConsoleServer 3200 will determine if it is necessary to use this feature. If the
secondary configuration will not be used, all fields for the secondary configuration
should be set to 255.255.255.255 (which is the default setting).
| STOP BITS: 1>
| PARITY: None>
| DATA BITS: 8>
| EQUIP PORT TYPE: DTE>
| FLOW CONTROL: XON/XOFF>
C D
28
E
