When at the monitor mode prompt, the user may view the contents of the buffer using
the commands TOP, BOTTOM, NEXT, PREVIOUS, FORWARD, and REVERSE, or by
selecting the commands DISPLAY NEXT PAGE, DISPLAY PREVIOUS PAGE, GOTO
BEGINNING OF BUFFER, GOTO END OF BUFFER, FORWARD N LINES, and
REVERSE N LINES from the pull down menu. The monitor mode prompt will appear at
the bottom of the displayed buffer data, and the user may enter commands normally at
this prompt. The prompt is prefixed with the position of the currently displayed screen in
the buffer; the top of the buffer is indicated by TOP>, the bottom of the buffer is indicated
as BOTTOM>, and any other position is indicated as a percentage of the total buffer
(e.g., 51%>).
Connecting...
W.O.P.R.
LOGIN:GUEST
PASSWORD:*****
LOGIN FAILED
LOGIN:SFALKEN
PASSWORD:********
LOGIN FAILED
LOGIN:JOSHUA
Greetings Professor Falken
How are you today?
>
TOP>usr1-DEVICE_1>
The following table outlines the functions of the individual commands and pull down
menu items.
COMMAND
TOP
BOTTOM
NEXT
PREVIOUS
MENU ITEM
GOTO BEGINNING OF BUFFER
GOTO END OF BUFFER
DISPLAY NEXT PAGE
DISPLAY PREVIOUS PAGE
54
FUNCTION
displays first 24 lines of
buffer data
displays last 24 lines of
buffer data
displays next 24 lines of
buffer data
displays previous 24
lines of buffer data
