Standard DB9 or DB25 installation:
Materials:
ConsoleServer 3200 device port
device with RS-232-C serial console port
RJ45-terminated Cat 5 cable (standard LAN cable)
Lightwave adapter for serial console port
1. Attach the Lightwave adapter to the serial console port.
2. Connect the Cat 5 cable to the adapter. Connect the other end to the
ConsoleServer 3200 device port.
3. Check that the device port and serial console port communications parameters
match, and synchronize them if they do not match. See sections 6.3 and 6.7.4
for more information regarding the device port parameters.
Sun® Netra t1 installation:
Materials:
1. Connect a Cat 5 cable to the console port of the Netra. Connect the other end to
the end of the ConsoleServer/Netra adapter (P/N 200.0225) marked "to Netra".
2. Connect another Cat 5 cable between the adapter end marked "ConsoleServer"
and the ConsoleServer device port.
3. Check that the device port and serial console port communications parameters
match, and synchronize them if they do not match. See sections 6.3 and 6.7.4
for more information regarding the device port parameters.
