5.7

Checking Connections

CONNECTION INFO SCREEN
┌───────────────────────────────────────────────────────────────────────────┐
│
├───────────────────────────────────────────────────────────────────────────┤
│T - TEST
│M -
│N1 -
│N2 -
│N3 -
│N4 -
│N5 -
│N6 -
│N7 -
│N8 -
└───────────────────────────────────────────────────────────────────────────┘
Press Any Key To Continue ....
Only one user at a time may connect to a device on the ConsoleServer 800,
except when using listen mode (see Section 5.9, Listening to a Server Session
for more details). Before attempting to select a device port, the user may desire
to check if the device port is free. The CONNECTIONS command allows the user
to list the users that are logged in, which devices they have currently selected,
and which mode they are in. Users may also view this information by selecting
DISPLAY CONNECTED LIST from the pull-down menu when logged in.
5.8 Selecting a Device Port (F2 or CTL D activates the pull down menu)
F2 PULL-DOWN MENU TO SELECT A DEVICE PORT, PART 1
CONNECTION INFO
00 -
00 -
00 -
00 -
00 -
00 -
00 -
00 -
00 -
00 -
┌──────────────────────────┐
│ LOGGED IN MENU
├──────────────────────────┤
│ CONNECT TO SERVER
│ DIR CONNECT TO SERVER
│ DISPLAY CONNECTED LIST
│ DISPLAY SERVER NAMES
│ DISPLAY ACTIVE DEVICES
│ LOGOUT
│ CHANGE PASSWORD
│ CHANGE DIRECT MODE ESC
│ CHANGE BREAK MODE ESC
│ DISPLAY HELP
└──────────────────────────┘
39
│
User logged-in │
Channel present │
Channel present │
Channel present │
Channel present │
Channel present │
Channel present │
Channel present │
Channel present │
Channel present │
│
│
│
│
│
│
│
│
│
│
│
