Pro-Form 720 Zle Elliptical Manual page 12

12
102 91
‫ﺍﻟﺸﺤﻢ‬
115
51
13
14
12
12
91
102
12
112
‫21. ﺣﺪﺩ ﻣﺤﺎﻭﺭ ﺫﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ ﺍﻟﻘﺼﻴﺮﺓ )511( ﻭﻣﺤﺎﻭﺭ ﺍﻟﺪﻭﺍﺳﺔ‬
‫ﺿﻊ ﻛﻤﻴﺔ ﺻﻐﻴﺮﺓ ﻣﻦ ﺍﻟﺸﺤﻢ ﻋﻠﻰ ﻣﺤﻮﺭ ﺫﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ‬
.(91) ‫ × 32 ﻣﻢ × 5.1 ﻣﻢ‬M8 ‫ﺍﻟﻘﺼﻴﺮ )511( ﻭﻋﻠﻰ ﻓﻠﻜﺔ‬
‫ × 61 ﻣﻢ )201( ﻭﺍﻟﻔﻠﻜﺔ‬M8 ‫ﺑﻌﺪ ﺫﻟﻚ، ﺍﺭﺑﻂ ﺍﻟﺒﺮﻏﻲ‬
‫ × 32 ﻣﻢ × 5.1 ﻣﻢ )19( ﻋﺪﺓ ﺩﻭﺭﺍﺕ ﺑﻄﺮﻑ ﻭﺍﺣﺪ‬M8
‫ﻭ ﺟ ﹼ ﻪ ﺫﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ )21( ﻋﻠﻰ ﺍﻟﻨﺤﻮ ﺍﻟﻤﻮﺿﺢ. ﻭﻣﻊ ﻗﻴﺎﻡ‬
‫ﺷﺨﺺ ﺁﺧﺮ ﺑﺈﻣﺴﺎﻙ ﺍﻟﻄﺮﻑ ﺍﻷﻣﺎﻣﻲ ﻟﺬﺭﺍﻉ ﻣﺤﻮﺭ ﺍﻻﺭﺗﻜﺎﺯ‬
‫ﺍﻷﻳﻤﻦ )15( ﺩﺍﺧﻞ ﺍﻟﻜﺘﻴﻔﺔ ﺑﺬﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ، ﺃﺩﺧﻞ ﻣﺤﻮﺭ ﺫﺭﺍﻉ‬
.‫ﺍﻟﺪﻭﺍﺳﺔ ﺍﻟﻘﺼﻴﺮ )511( ﻣﻦ ﺧﻼﻝ ﺍﻟﺠﺰﺋﻴﻦ‬
‫ × 61 ﻣﻢ )201( ﻭﺍﻟﻔﻠﻜﺔ‬M8 ‫ﺍﺭﺑﻂ ﺍﻟﺒﺮﻏﻲ‬
‫ × 32 ﻣﻢ × 5.1 ﻣﻢ )19( ﻋﺪﺓ ﺩﻭﺭﺍﺕ ﻟﻤﺤﻮﺭ ﺫﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ‬M8
.‫ﺍﻟﻘﺼﻴﺮ )511(. ﺛﻢ ﺃﺣﻜﻢ ﺭﺑﻂ ﺍﻟﺒﺮﻏﻴﻴﻦ ﻓﻲ ﻧﻔﺲ ﺍﻟﻮﻗﺖ‬
.‫ﻛﺮﺭ ﻫﺬﻩ ﺍﻟﺨﻄﻮﺓ ﻣﻊ ﺍﻟﺠﺎﻧﺐ ﺍﻵﺧﺮ ﻣﻦ ﺍﻟﺠﻬﺎﺯ ﺍﻟﺒﻴﻀﺎﻭﻱ‬
.‫31. ﺣﺪﺩ ﺍﻟﺪﻭﺍﺳﺔ ﺍﻟﻴﻤﻨﻰ )41( ﻭﻭ ﺟ ﹼ ﻬﺎ ﻋﻠﻰ ﺍﻟﻨﺤﻮ ﺍﻟﻤﻮﺿﺢ‬
(12) ‫ﺭ ﻛ ﹼ ﺐ ﺍﻟﺪﻭﺍﺳﺔ ﺍﻟﻴﻤﻨﻰ )41( ﺑﺬﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ ﺍﻟﻴﻤﻨﻰ‬
.(112) ‫ × 05 ﻣﻢ‬M8 ‫ﺑﺎﺳﺘﺨﺪﺍﻡ ﺛﻼﺛﺔ ﺑﺮﺍﻏﻲ ﺗﺮﻛﻴﺐ ﺳﺮﻳﻊ‬
‫ﺭ ﻛ ﹼ ﺐ ﺍﻟﺪﻭﺍﺳﺔ ﺍﻟﻴﺴﺮﻯ )ﻏﻴﺮ ﻣﻮﺿﺤﺔ( ﺑﺬﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ‬
.‫ﺍﻟﻴﺴﺮﻯ )21( )ﻏﻴﺮ ﻣﻮﺿﺢ( ﺑﻨﻔﺲ ﺍﻟﻄﺮﻳﻘﺔ‬
12
.(‫ﺍﻟﻄﻮﻳﻠﺔ )ﻏﻴﺮ ﻣﻮﺿﺢ‬
.(115) ‫ﻟﻤﺤﻮﺭ ﺫﺭﺍﻉ ﺍﻟﺪﻭﺍﺳﺔ ﺍﻟﻘﺼﻴﺮ‬
