،8. ﻭﺑﺎﺳﺘﺨﺪﺍﻡ ﺣﻘﻴﺒﺔ ﺑﻼﺳﺘﻴﻜﻴﺔ ﻟﻠﺤﻔﺎﻅ ﻋﻠﻰ ﻧﻈﺎﻓﺔ ﻳﺪﻳﻚ
8
ﺿﻊ ﻛﻤﻴﺔ ﻛﺒﻴﺮﺓ ﻣﻦ ﺍﻟﺸﺤﻢ ﺍﻟﻤﺰ ﻭ ﹼ ﺩ ﻋﻠﻰ ﻣﺤﻮﺭ ﺍﻟﻌﻤﻮﺩ
.(118) ﺍﻟﻘﺎﺋﻢ )84( ﻭﻋﻠﻰ ﺣﻠﻘﺎﺕ ﺗﺜﺒﻴﺖ ﺍﻟﻌﺠﻠﺔ
ﺃﺩﺧﻞ ﻣﺤﻮﺭ ﺍﻟﻌﻤﻮﺩ ﺍﻟﻘﺎﺋﻢ )84( ﺑﺎﻟﻌﻤﻮﺩ ﺍﻟﻘﺎﺋﻢ )5( ﻭﻗﻢ
5
ﺑﺘﻮﺳﻴﻄﻪ. ﺣﺮ ﹼ ﻙ ﺣﻠﻘﺔ ﺗﺜﺒﻴﺖ ﺍﻟﻌﺠﻠﺔ )811( ﻟﻜﻞ ﻃﺮﻑ ﻣﻦ
9
.ﻣﺤﻮﺭ ﺍﻟﻌﻤﻮﺩ ﺍﻟﻘﺎﺋﻢ
ﺍﻟﺸﺤﻢ
118
ﺣﺮ ﹼ ﻙ ﺫﺭﺍﻋﻲ ﺍﻟﻬﻴﻜﻞ ﺍﻷﻳﻤﻦ ﻭﺍﻷﻳﺴﺮ )8، 9( ﻧﺤﻮ ﻣﺤﻮﺭ ﺍﻟﻌﻤﻮﺩ
.(48) ﺍﻟﻘﺎﺋﻢ
8
48
118
(102) × 61 ﻣﻢM8 9 . ﻓﻲ ﻧﻔﺲ ﺍﻟﻮﻗﺖ، ﺃﺣﻜﻢ ﺭﺑﻂ ﺍﻟﺒﺮﻏﻲ
9
× 32 ﻣﻢ × 5.1 ﻣﻢ )19( ﺑﻜﻞ ﻃﺮﻑ ﻣﻦ ﻣﺤﻮﺭM8 ﻭﺍﻟﻔﻠﻜﺔ
.ﺍﻟﻌﻤﻮﺩ ﺍﻟﻘﺎﺋﻢ )84(. ﺃﺣﻜﻢ ﺑﺸﻜﻞ ﺗﺎﻡ ﺭﺑﻂ ﺍﻟﺒﺮﺍﻏﻲ
102
91
48
91
102
10
