ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the
included hex keys and a phillips screwdriver
rubber mallet
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parentheses
below each drawing is the key number of the part, from the PART LIST on pages 24 and 25. The number follow-
ing the parentheses is the quantity needed for assembly. Note: Some small parts may have been preassem-
bled. If a part is not in the parts bag, check to see if it has been preassembled.
M4 x 16mm
M4 x 22mm
Screw (66)–4
Screw (76)–2
M8 Jamnut
(104)–4
Locknut (46)–6
M8 x 25mm Patch
Screw (22)–2
M10 x 75mm Carriage
Bolt (34)–2
M8 x 53mm Button
Screw (84)–4
.
M8 Split Washer
(83)–6
M8 Nylon
M10 Nylon
Locknut (29)–2
M8 x 45mm Button
Bolt (50)–4
, an adjustable spanner
M10 Split Washer
M8 Washer
(94)–2
(53)–2
M8 x 16mm Button
Screw (91)–4
M8 x 70mm Button
M10 x 59mm Bolt
Set (27)–2
M10 x 83mm Button
Screw (63)–2
5
, and a
M10 Washer
(98)–4
Cover Screw
(82)–4
Bolt (67)–2
