ASSEMBLY

To hire an authorized service technician to assemble the elliptical exerciser, call toll-free 1-800-445-2480.
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the
included hex keys and your own phillips screwdriver
rubber mallet
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parentheses
below each drawing is the key number of the part, from the PART LIST on pages 20 and 21. The number follow-
ing the parentheses is the quantity needed for assembly. Note: Some small parts may have been pre-assem-
bled. If a part is not in the parts bag, check to see if it has been pre-assembled.
M8 Split
Star Washer
(112)–8 Washer (90)–3
M4 x 14mm
Screw (104)–8 Screw (101)–14
Hub Screw (87)–8
M8 x 69mm Button
Bolt (80)–1
.
Wave Washer
(111)–2
M4 x 16mm
Round Head
M8 x 23mm Shoulder
Screw (115)–4
M10 x 127mm Button Screw (83)–2
, adjustable wrench
M8 Washer
(88)–6
M4 x 32mm
Round Head
Screw (105)–6
M8 x 23mm Button
Screw (84)–4
M10 x 82mm Button
5
M8 Jamnut M8 x 15mm Button
(79)–5
Screw (116)–8
M4 x 45mm
Screw (108)–2
M8 x 43mm Button
Bolt (78)–4
Screw (82)–2
, and
