Pro-Form 600 Zlt Treadmill Manual page 11

9
116
104
111
10
‫ﺳﻠﻚ ﺍﻟﻮﺣﺪﺓ‬
108
73
‫ﺍﻟﻔﺘﺤﺔ‬
‫ﻣﺠﻤﻮﻋﺔ ﺍﻟﻮﺣﺪﺓ‬
107
116
‫ﺑﺈﺩﺍﺭﺓ ﻫﻴﻜﻞ ﺍﻟﻮﺣﺪﺓ ﺑﻌﻴ ﺪ ﹰ ﺍ ﻟﻠﻐﺎﻳﺔ، ﻭﺇﻻ ﺳﺘﻘﻄﻊ ﺍﻟﺴﻠﻚ‬
106
107
‫ﻗﻢ ﺑﺤﺬﺭ ﺑﺈﺩﺍﺭﺓ ﻫﻴﻜﻞ ﺍﻟﻮﺣﺪﺓ )111( ﻟﻸﺳﻔﻞ ﻣﺮﺓ ﺃﺧﺮﻯ ﺇﻟﻰ‬
‫ﻣﺠﻤﻮﻋﺔ ﺍﻟﻮﺣﺪﺓ‬
‫ )ﺍﻷﻳﻤﻦ(. ﺍﻧﺰﻉ ﺍﻟﺮﺑﻄﺔ ﻣﻦ ﻣﻘﺒﺾ ﺍﻟﻴﺪ ﺍﻷﻳﻤﻦ. ﻋﻨﺪ‬R ‫ﻳﺴﻤﻰ‬
34
5
‫ﺍﻟﺮﺑﻄﺔ‬
10
101
‫ﻋﻨﺪ ﺍﻟﻀﺮﻭﺭﺓ، ﺍﺿﺒﻂ ﻫﻴﻜﻞ ﺍﻟﻮﺣﺪﺓ )111( ﻟﺘﻜﻮﻥ ﺍﻟﻔﺘﺤﺎﺕ‬
111
‫ﺗﺄﻛﺪ ﻣﻦ ﻋﺪﻡ ﺿﻐﻂ ﺳﻠﻚ ﺍﻟﻮﺣﺪﺓ. ﺍﺑﺪﺃ ﺑﺮﺑﻂ ﺍﻟﻤﺴﺎﻣﻴﺮ‬
11
‫9. ﺿﻊ ﻣﺠﻤﻮﻋﺔ ﺍﻟﻮﺣﺪﺓ ﻣﻮﺍﺟﻬﺔ ﻷﺳﻔﻞ ﻋﻠﻰ ﺳﻄﺢ ﻧﺎﻋﻢ‬
‫ 1 ﺑﻮﺻﺔ )701(. ﻗﻢ ﺑﺤﺬﺭ‬x 8 ‫ﺣﺮﺭ ﺍﻟﺒﺮﺍﻏﻲ ﺍﻷﺭﺑﻌﺔ ﺭﻗﻢ‬
‫ﺑﺈﺩﺍﺭﺓ ﻫﻴﻜﻞ ﺍﻟﻮﺣﺪﺓ )111( ﺇﻟﻰ ﺍﻟﻮﺿﻊ ﺍﻟﻤﺒﻴﻦ. ﻻ ﺗﻘﻢ‬
‫ﺣﺪﺩ ﺩﺭﺟﻲ ﺍﻟﻤﻠﺤﻘﺎﺕ ﺍﻷﻳﺴﺮ ﻭﺍﻷﻳﻤﻦ )401، 601(. ﺭ ﻛ ﹼ ﺐ‬
‫ﺩﺭﺟﻲ ﺍﻟﻤﻠﺤﻘﺎﺕ ﺑﻤﺠﻤﻮﻋﺔ ﺍﻟﻮﺣﺪﺓ ﺑﺎﺳﺘﺨﺪﺍﻡ ﺛﻤﺎﻧﻴﺔ‬
.(116) ‫ 31 ﻣﻢ‬x M4 ‫ﺑﺮﺍﻏﻲ‬
‫01. ﺣﺪﺩ ﻣﻘﺒﺾ ﺍﻟﻴﺪ ﺍﻷﻳﻤﻦ )101(، ﺍﻟﻤﻤﻴﺰ ﺑﻮﺍﺳﻄﺔ ﻣﻠﺼﻖ‬
‫ )43( ﻟﻠﺨﻠﻒ‬M8 ‫ﺍﻟﻀﺮﻭﺭﺓ، ﺍﺿﻐﻂ ﻋﻠﻰ ﺻﺎﻣﻮﻟﺔ ﻗﻔﺼﻴﺔ‬
.‫ﺃﻣﺴﻚ ﻣﻘﺒﺾ ﺍﻟﻴﺪ ﺍﻷﻳﻤﻦ )101( ﺑﺠﻮﺍﺭ ﻣﺠﻤﻮﻋﺔ ﺍﻟﻮﺣﺪﺓ‬
‫ﻗﻢ ﺑﺘﻮﺟﻴﻪ ﺳﻠﻚ ﺍﻟﻮﺣﺪﺓ ﺣﻮﻝ ﺍﻟﺠﺎﻧﺐ ﺍﻷﻳﻤﻦ ﻣﻦ ﻣﻘﺒﺾ‬
‫ﺍﻟﻴﺪ ﺍﻷﻳﻤﻦ ﻛﻤﺎ ﻫﻮ ﻣﺒﻴﻦ، ﻭﻣﻦ ﺧﻼﻝ ﺍﻟﻔﺘﺤﺔ ﻓﻲ ﻣﻘﺒﺾ‬
‫ﺍﻟﻤﻮﺟﻮﺩﺓ ﺑﻤﻘﺒﺾ ﺍﻟﻴﺪ ﺍﻷﻳﻤﻦ )101( ﻣﺤﺎﺫﻳﺔ ﻟﻠﻔﺘﺤﺎﺕ‬
.‫ﺍﻟﻤﻮﺟﻮﺩﺓ ﺑﻬﻴﻜﻞ ﺍﻟﻮﺣﺪﺓ‬
(111) ‫ﺭ ﻛ ﹼ ﺐ ﻣﻘﺒﺾ ﺍﻟﻴﺪ ﺍﻷﻳﻤﻦ )101( ﺑﻬﻴﻜﻞ ﺍﻟﻮﺣﺪﺓ‬
‫ﻭﻣﺠﻤﻮﻋﺔ ﺍﻟﻮﺣﺪﺓ ﺑﺎﺳﺘﺨﺪﺍﻡ ﻣﺴﻤﺎﺭﻱ ﺗﺮﻛﻴﺐ ﺳﺮﻳﻊ‬
‫ )01(، ﻭﻣﺴﻤﺎﺭ‬M8 ‫ 52 ﻣﻢ )5(، ﻭﺣﻠﻘﺘﻲ ﺗﺜﺒﻴﺖ‬x M8
.(73) ‫ 61 ﻣﻢ )801(، ﻭﺣﻠﻘﺔ ﺗﺜﺒﻴﺖ ﻧﺠﻤﻴﺔ 4/1 ﺑﻮﺻﺔ‬x M5
.‫ﺍﻟﺜﻼﺛﺔ، ﺛﻢ ﺃﺣﻜﻢ ﺭﺑﻄﻬﺎ‬
‫ﺭ ﻛ ﹼ ﺐ ﻣﻘﺒﺾ ﺍﻟﻴﺪ ﺍﻷﻳﺴﺮ )ﻏﻴﺮ ﻣﻮﺿﺢ ﺑﺎﻟﺸﻜﻞ( ﻛﻤﺎ ﻫﻮ‬
‫ﻣﻮﺿﺢ ﺃﻋﻼﻩ. ﻣﻼﺣﻈﺔ: ﻻ ﺗﻮﺟﺪ ﺃﻱ ﺃﺳﻼﻙ ﻋﻠﻰ ﺍﻟﺠﺎﻧﺐ‬
‫ 1 ﺑﻮﺻﺔ )701(. ﺍﺣﺮﺹ ﻋﻠﻰ‬x 8 ‫ﺃﺣﻜﻢ ﺭﺑﻂ ﺍﻟﺒﺮﺍﻏﻲ ﺭﻗﻢ‬
.‫ﻋﺪﻡ ﺇﺣﻜﺎﻡ ﺭﺑﻂ ﺍﻟﺒﺮﺍﻏﻲ ﺑﺸﺪﺓ‬
.‫ﻟﺘﺠﻨﺐ ﺧﺪﺵ ﺍﻟﻮﺣﺪﺓ‬
.‫ﺍﻷﺭﺿﻲ‬
.‫ﻣﺠﻤﻮﻋﺔ ﺍﻟﻮﺣﺪﺓ‬
.‫ﺇﻟﻰ ﻣﻮﺿﻌﻬﺎ‬
.‫ﺍﻟﻴﺪ ﺍﻷﻳﻤﻦ‬
.‫ﺍﻷﻳﺴﺮ‬
