www.proform.com
Model No. PFTL79515.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to www.proformservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.proformservice.com.
Or call 1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the performnce 600iPFTL79515.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Form performnce 600iPFTL79515.0

  • Page 1 www.proform.com Model No. PFTL79515.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 20. Keep fingers, hair, and clothing away from 26. Never insert any object into any opening on the moving walking belt. the treadmill. 21. The treadmill is capable of high speeds. 27. Inspect and properly tighten all parts each Adjust the speed in small increments to time the treadmill is used.
  • Page 5 STANDARD SERVICE PLANS...
  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this PROFORM PERFORMANCE 600I treadmill. The manual. To help us assist you, please note the product ® PERFORMANCE 600I treadmill offers an impres- model number and serial number before contacting us.
  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
  • Page 8: Assembly

    ASSEMBLY • To hire an authorized service technician to • Left parts are marked “L” or “Left” and right parts assemble the treadmill, call 1-800-445-2480 are marked “R” or “Right.” • Assembly requires two persons. • To identify small parts, see page 7. •...
  • Page 9 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (94). Next, identify the Right Upright (90). Have a sec- ond person hold the Right Upright near the Base (94).
  • Page 10 4. Hold the Right Upright (90) against the Base (94). Make sure not to pinch the Upright Wire (81). Next, hold a Wheel (97) inside the Base (94), and insert a 3/8" x 1 3/4" Screw (62) with a 3/8" Star Washer (13) through the Base and the Wheel as shown;...
  • Page 11: Two 5/16" Star Washers (11); Firmly Tighten The

    6. Identify the Left Handrail (86). Attach the Left Handrail (86) to the Left Upright (89) with two 5/16" x 2 1/2" Screws (28) and two 5/16" Star Washers (11); firmly tighten the Screws. Next, attach the Right Handrail (87) to the Right Upright (90) with two 5/16"...
  • Page 12 8. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step. Raise the Frame (56) to the upright position. IMPORTANT: Do not raise the Frame past the vertical position. Have a second person hold the Frame until step 10 is completed.
  • Page 13 10. Remove the 5/16" Nut (12) and the 5/16" x 2 1/4" Bolt (3) from the bracket on the Latch Crossbar (38). 12 I Align the upper end of the Storage Latch (53) with the bracket on the Latch Crossbar (38), and insert the 5/16"...
  • Page 14 12. Attach the console assembly (J) to the Left and Right Handrails (86, 87) with four #10 x 3/4" Screws (9) and four #10 Star Washers (5); start all four Screws, and then tighten them. 13. See the inset drawing. Connect the Upright Wire (81) to the console wire (K).
  • Page 15 14. Attach the Left Handrail Cover (79) and the Right Handrail Cover (92) to the Left and Right Handrails (86, 87) with six #8 x 1/2" Screws (1); start all the Screws, and then tighten them. Do not overtighten the Screws. 15.
  • Page 16 16. Firmly tighten the four 3/8" x 2 1/4" Screws (7), the two 3/8" x 1 3/4" Screws (62), and the two 3/8" x 1 1/4" Screws (63). Next, set the Left Inner Base Cover (106) onto the lower end of the Left Upright (89). Slide the Left Base Cover (82) downward and press it onto the Left Inner Base Cover.
  • Page 17: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’s...
  • Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 19. To use the man- ual mode, see page 19. To use an onboard workout, The treadmill console offers an impressive array of see page 21. To use an interval training workout, features designed to make your workouts more effec- see page 22.
  • Page 19: To Turn On The Power

    HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 20 5. Change the incline of the treadmill as desired. 7. Measure your heart rate if desired. To change the incline of the treadmill, press the You can measure your heart rate using either the Incline increase and decrease buttons or one of the handgrip heart rate monitor or a compatible heart Quick incline buttons.
  • Page 21: To Use An Onboard Workout

    9. When you are fi nished exercising, remove the Each workout is divided into segments. One speed key from the console. setting and one incline setting are programmed for each segment. Note: The same speed setting and/ Step onto the foot rails, press the Stop button or incline setting may be programmed for consecu- repeatedly, and adjust the incline of the treadmill tive segments.
  • Page 22: To Connect Smart Device To Console

    HOW TO USE AN INTERVAL TRAINING WORKOUT 6. Follow your progress with the displays. During an interval training workout, you will repeatedly See step 6 on page 20. The display will show the alternate between intervals of low-intensity “recovery” time remaining instad of the elapsed time. exercise and intervals of high-intensity “work”...
  • Page 23 When a connection is established, the LED on the HOW TO CONNECT YOUR HEART RATE MONITOR console will fl ash blue. Press the Bluetooth button TO THE CONSOLE on the console to confi rm the connection; the LED on the console will then turn solid blue. The console is compatible with all BLUETOOTH Smart heart rate monitors.
  • Page 24 THE INFORMATION MODE HOW TO USE THE TABLET HOLDER The console features an information mode that keeps IMPORTANT: The tablet holder is designed for use track of treadmill usage information and allows you to with most full-size tablets. Do not place any other select a unit of measurement for the console.
  • Page 25: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.
  • Page 26: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal perfor- as shown, the switch has tripped. To reset the mance and to reduce wear. Inspect and properly tighten power switch, wait for fi...
  • Page 27 SYMPTOM: The incline of the treadmill does not c. Your treadmill features a walking belt coated with change correctly high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to a. Hold down the Stop button and the Speed increase the walking belt or the walking platform unless button, insert the key into the console, and then instructed to do so by an authorized service...
  • Page 28 b. If the walking belt slips when walked on, fi rst SYMPTOM: The tablet holder does not stay in place remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. Rotate the tablet holder backwards. Then, tighten screws clockwise, 1/4 of a turn.
  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 30: Part List

    PART LIST Model No. PFTL79515.0 R0915A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw #8 x 1" Tek Screw #8 x 3/4" Screw 9/32" Plastic Bushing Storage Latch 5/16" x 2 1/4" Bolt Drive Motor 5/16" x 1/2" Screw #10 Star Washer Motor Belt 5/16"...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Tablet Holder 1/4" x 1 1/4" Screw Left Inner Base Cover – User’s Manual 1/4" Nut M5 Washer Note: Specifi cations are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.
  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL79515.0 R0915A...
  • Page 33 EXPLODED DRAWING B Model No. PFTL79515.0 R0915A...
  • Page 34 EXPLODED DRAWING C Model No. PFTL79515.0 R0915A...
  • Page 35 EXPLODED DRAWING D Model No. PFTL79515.0 R0915A...
  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
