5.4 DMX512 Configuration
* IM-7S without Channel 8 – Focus.

4. How To Set The Unit

4.1 Control Panel

Display
To show the various menus and the selected functions .
LED
DMX On
8D
MASTER On
SLAVE On
SOUND Flashing
Button
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions
Remote controller input
By connect to the 1/4" microphone jack to control the unit for Stand by, Function and Mode
Sensitivity
To adjust the sound sensitivity .
Microphone
To receive audio signal for sound activation .
DMX input/output
For DMX512 link, use 3-pin XLR plug cable to link the unit together.
DMX input present
Master Mode
Slave Mode
Sound activation
