iSolution IM-7S User Manual page 11

Color Mode
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
(split color) mode. Once the mode has been selected, press the ENTER button to
setup or automatically return to the main functions without any change after 8 seconds. To go
back to the functions without any change press the MENU button again.
Pan Inversion
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
(pan inversion) mode. Once the mode has been selected, press the ENTER button
to setup or automatically return to the main functions without any change after 8 seconds. To
go back to the functions without any change press the MENU button again.
Tilt Inversion
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
(tilt inversion) mode. Once the mode has been selected, press the ENTER button to
setup or automatically return to the main functions without any change after 8 seconds. To go
back to the functions without any change press the MENU button again.
Dimmer Inversion
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
(dimmer inversion) mode. Once the mode has been selected, press the ENTER
button to setup or automatically return to the main functions without any change after 8
seconds. To go back to the functions without any change press the MENU button again.
Led Display
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to select the
(Led off) mode. Once the mode has been selected, press the ENTER button to
setup or automatically return to the main functions without any change after 8 seconds. To go
back to the functions without any change press the MENU button again.
is showing on the display. Pressing ENTER
(normal) or
is showing on the display. Pressing ENTER
(normal) or
is showing on the display. Pressing ENTER
(normal) or
is shown on the display. Pressing ENTER
(normal) or
is showing on the display. Pressing ENTER
(Led on) or
Display Inversion
It is good for you to install the unit on the floor or under ceiling. Press the MENU button up to
when the is blinking on the display. Use the ENTER button to change to the mode
(display inversion), It will automatically store after 8 seconds. Or press the ENTER
button again return to the mode
the MENU button.
Display normal mode for the fixture putting on the floor.
Display inversion mode for the fixture fixing under ceiling.
Focus Adjust
Press the MENU button up to when the
button, the unit will focus on tilt 90°, and then the unit will focus on pan 0°, pan 90°, pan 180°,
pan 270° in every pressing ENTER button. Use DOWN and UP button to adjust focus. To go
back to the functions press the MENU button again.
Self-Test
11D
Press the MENU button up to when the
button and the unit will run self-test by built-in program. To go back to the functions press the
MENU button again.
Fixture Hours
Press the MENU button up to when the
button and the display will show the number of working hours of the unit. To go back to the
functions press the MENU button again.
Reset
Press the MENU button up to when the
button and all channels of the unit will return to their standard position. To go back to the
functions press the MENU button again.
(display normal). To go back to the functions press
is blinking on the display. Pressing ENTER
is blinking on the display. Pressing ENTER
is blinking on the display. Pressing ENTER
is blinking on the display. Pressing ENTER
