Technical Specifications
IM-8S
Power
AC 120V~60Hz or AC 230/240/250V 50/60Hz
Fuse
20mm Glass T10A Fast Blow
Lamp
MSD 250/2
Dimension 360mm x 397mm x 503mm
Weight
26 kg
IM-7S
Power
AC 120V~60Hz or AC 230/240/250V 50/60Hz
Fuse
20mm Glass T6.3A Fast Blow
Lamp
HTI 150W
Dimension 373mm x 295mm x 451 mm
Weight
13 kg
Innovation , Quality , Performance
IM-8S
User Guide
Professional Entertainment Technology
IM-7S
Advertisement
Table of Contents
Related Manuals for iSolution IM-8S
Summary of Contents for iSolution IM-8S
- Page 1 Technical Specifications IM-8S Power AC 120V~60Hz or AC 230/240/250V 50/60Hz Fuse 20mm Glass T10A Fast Blow Lamp MSD 250/2 Dimension 360mm x 397mm x 503mm Weight 26 kg IM-7S Power AC 120V~60Hz or AC 230/240/250V 50/60Hz Fuse 20mm Glass T6.3A Fast Blow...
-
Page 2: Table Of Contents
EN61000-4-11: 1994. 5.1 Master/Slave Built-In Preprogrammed Function. & 5.2 Easy Controller Harmonized Standard 5.3 iSolution Operation / Universal DMX Controller 5.4 DMX512 Configuration EN60598-1: 2000+ALL:2000+A12:2002 5.5 DMX512 Connection Safety of household and similar electrical appliances Part 1 : General requirements 6. -
Page 3: Safety Instruction
8. Put the belt around the axis gear and motor gear. ♦ The unit is designed for use with the MSD 250/2 ( IM-8S ) or HTI 150 ( IM-7S ). Do 9. Plug all the connect wires (C) that form the arm to PC board and igniter. - Page 4 Always ensure that the structure to which you are attaching the unit is secure and is able to support a weight of 30 kgs for each unit ( Below drawing is for IM-8S only ). Photo 2...
-
Page 5: Technical Specification
2. Technical Specification G. If The IM-8S pan belt is broken Power supply 1. Turn off the main power. - AC 120V~60Hz or 230V/240V/250V 50/60Hz 2. Unscrew all the screws (A) and open the base-housing cover (B). Lamp 3. Unplug all the connect wires (C) that from the arm to PC board and igniter. -
Page 6: Inserting/Exchanging Rotating Gobos
6. Troubleshooting 2.1 Inserting/Exchanging rotating gobos Following are a few common problems that may occur during operation. Here are DANGER! some suggestions for easy troubleshooting: Install the gobos with the device switched off only. Unplug from mains before changing gobos! A. -
Page 7: Lamp
The high luminance of the arc can cause severe damage to the retina if looks directly at the lamp. Discharge lamp : MSD 250/2 (IM-8S) HTI 150W (IM-7S) 1. Always switch off the main supply and never handle the lamp or luminaries when is hot. -
Page 8: How To Set The Unit
5.4 DMX512 Configuration 4. How To Set The Unit * IM-7S without Channel 8 – Focus. 4.1 Control Panel Display To show the various menus and the selected functions . DMX input present MASTER Master Mode SLAVE Slave Mode SOUND Flashing Sound activation Button... -
Page 9: Main Function
(LED off ) (LED normal blinking) (LED on) (LED fast blinking) MENU button. The main functions are shown below: 5.3.1 iSolution Operation DMX512 Address Setting Show mode 1 ♦ Consistent DMX configuration enable iMove to be linked together with iRock and iShow Show mode 2 and controlled at the same time. -
Page 10: How To Control The Unit
5. How To Control The Unit Show Mode You can operate the unit in three ways: 1. By master/slave built-in preprogram function Press the MENU button up to when the is showing on the display. Pressing ENTER 2. By easy controller button and the display will blink. - Page 11 Color Mode Display Inversion It is good for you to install the unit on the floor or under ceiling. Press the MENU button up to Press the MENU button up to when the is showing on the display. Pressing ENTER button and the display will blink.
