Summary of Contents for iSolution IMOVE 250W

  • Page 1: Table Of Contents

    5. How To Control The Unit 5.1 Master/Slave Built-In Preprogrammed Function. 5.2 Easy Controller 5.3 iSolution Operation / DMX Controller 5.4 DMX512 Configuration 5.5 DMX512 Connection 6. Troubleshooting 7. Fixture Cleaning User Guide BEGLEC cva – ‘t Hofveld2 – 1702 Groot Bijgaarden Belgium WWW.BEGLEC.COM...

  • Page 2: Safety Instruction

    1. Safety Instruction Warning To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or Please read carefully the instruction, which includes important moisture. information about the installation, usage and maintenance. Never touch bulb with bare fingers, as it is very hot after using. WARNING Hot lamp explosion hazard.

  • Page 3: Technical Specification

    8 Channels: 2. Technical Specification Power supply - AC 120V ~ 60Hz / 230V ~ 50Hz Channel 1 = Pan Channel 2 = Tilt Lamp - Discharge lamp MSD 250/2 GY 9.5 Channel 3 = Shutter Optical system Channel 4 = Effect wheel - High efficiency optical system Channel 5 = Color - High quality optical lens and dichroic colors...

  • Page 4: Lamp

    3. Lamp In case of replacement of the lamp or maintenance, do not open the fixture within 15 minutes until the unit cools down after switching off. Because of its high internal pressure, there might be a risk that the Discharge lamp would explode during operation.

  • Page 5: Main Function

    4.2. Main Function MENU To select the programming functions To select any of the pre-set functions, press the MENU button up to when the required one DOWN To go backward in the selected functions is shown on the display. Select the function by ENTER button and the display will blink. Use To go forward in the selected functions DOWN and UP button to change the mode.
  • Page 6 Channel Mode Blackout Mode Press the MENU button up to when the is shown on the display. Pressing ENTER Press the MENU button up to when the is shown on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to select the button and the display will blink.

  • Page 7: Home Position Adjustment

    Set DMX value of channel 8 and channel 16 to 255, then all channels of the unit will return to (display inversion), It will automatically store after 8 seconds. Or press the ENTER their standard home position. button again return to the mode (display normal).

  • Page 8: Master/Slave Built-In Preprogrammed Function

    5.2. Easy Controller controller No need to turn the unit off when you change the DMX address, as new DMX address setting will be effected at once. Every time you turn the unit on, it will show 2500 on the The easy remote control is used only in master/slave mode.

  • Page 9: Dmx512 Configuration

    5.4. DMX512 Configuration 8 Channels You have to set the fixture DMX address in 8 channels mode when you use IL-0824 controller. DMX address can be set remotely by IL-0824 controller. No need to calculate the DMX channels of each fixture in the chain. Please refer to the following diagram to address your DMX512 channel for the first 4 units.

  • Page 10: Dmx512 Connection

    5.5. DMX512 Connection The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. iii.) For DMX Reset, put DMX value of CH-8 & CH-16 to 255. If you use a controller with 5 pins DMX connector, you need to use a 5 to 3 pin adapter. At last unit, the DMX cable has to be terminated with a terminator.

  • Page 11: Troubleshooting

    5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+) 1. The lamp is not working well. Check the main voltage either too high or too low. 2. Internal temperature may be too high. Check and if necessary replace the fan on the 6.

  • Page 12: Fixture Cleaning

    Pay attention to the belt tension when install the belt. 7. Fixture Cleaning Please refer to the photos below: The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
