iSolution IM-7S User Manual

Hide thumbs Also See for IM-7S:
Table of Contents

Advertisement

Quick Links

Enlarged version
Technical Specifications
IM-8S
Power
AC 120V~60Hz or AC 230/240/250V 50/60Hz
Fuse
20mm Glass 10A Fast Blow
Lamp
MSD 250/2
Dimension 360mm x 397mm x 503mm
Weight
26 kg
IM-7S
Power
AC 120V~60Hz or AC 230/240/250V 50/60Hz
Fuse
20mm Glass 7A Fast Blow
Lamp
HTI 150W
Dimension 373mm x 295mm x 451 mm
Weight
13 kg
Innovation , Quality , Performance
IM-8S
User Guide
WWW.BEGLEC.COM
IM-7S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM-7S and is the answer not in the manual?

Questions and answers

Related Manuals for iSolution IM-7S

Summary of Contents for iSolution IM-7S

  • Page 1 Fuse 20mm Glass 10A Fast Blow Lamp MSD 250/2 Dimension 360mm x 397mm x 503mm Weight 26 kg IM-7S Power AC 120V~60Hz or AC 230/240/250V 50/60Hz Fuse 20mm Glass 7A Fast Blow Lamp HTI 150W Dimension 373mm x 295mm x 451 mm...

  • Page 2: Table Of Contents

    7. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

  • Page 3: Safety Instruction

    8. Put the belt around the axis gear and motor gear. The unit is designed for use with the MSD 250/2 ( IM-8S ) or HTI 150 ( IM-7S ). Do 9. Plug all the connect wires (C) that form the arm to PC board and igniter.
  • Page 4 Pay attention to the belt tension when install the belt. Please refer to the photos below: ( For IM-8S ) Warning To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

  • Page 5: Technical Specification

    Lamp - Discharge lamp MSD 250/2 GY 9.5 (IM-8S) 4. Unscrew the screws (D) that fix the bridge (E). - Discharge HTI 150W GY 9.5 (IM-7S) 5. Unscrew the screws (F) that fix the axis gear (G). Optical system 6. Change a new belt (H) by going through all connecting wires that from the arm to base, - Standard 13°...

  • Page 6: Inserting/Exchanging Rotating Gobos

    6. Troubleshooting 2.1 Inserting/Exchanging rotating gobos Following are a few common problems that may occur during operation. Here are DANGER! some suggestions for easy troubleshooting: Install the gobos with the device switched off only. Unplug from mains before changing gobos! Open the cover by loosening the fastening screw at the sides of the cover.

  • Page 7: Lamp

    The high luminance of the arc can cause severe damage to the retina if looks directly at the lamp. Discharge lamp : MSD 250/2 (IM-8S) HTI 150W (IM-7S) 1. Always switch off the main supply and never handle the lamp or luminaries when is hot.

  • Page 8: How To Set The Unit

    By connect to the 1/4” microphone jack to control the unit for Stand by, Function and Mode Sensitivity To adjust the sound sensitivity . Microphone To receive audio signal for sound activation . DMX input/output For DMX512 link, use 3-pin XLR plug cable to link the unit together. * IM-7S without Channel 8 – Focus.

  • Page 9: Main Function

    4.2 Main Function Stand by Blackout the unit Strobe X/Y moving show Color/Gobo selection X/Y moving setting To select any of the pre-set functions, press the MENU button up to when the required one is 1.Gobo/Color sync. mode selection 1. Hold on for gobo 1.Pan position strobe ( Show 1 ~ Show 4 )

  • Page 10: How To Control The Unit

    5. How To Control The Unit Show Mode You can operate the unit in three ways: 1. By master/slave built-in preprogram function Press the MENU button up to when the is showing on the display. Pressing ENTER 2. By easy controller button and the display will blink.
  • Page 11 Color Mode Display Inversion It is good for you to install the unit on the floor or under ceiling. Press the MENU button up to Press the MENU button up to when the is showing on the display. Pressing ENTER button and the display will blink.
