iSolution IM-5W User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Technical Specifications
Power
AC 120V~60Hz
Fuse
20mm Glass T6.3A Fast Blow 20mm Glass T5A Fast Blow
Lamp
ELC 24V 250W
Dimension
290mm x 330mm x 380mm
Weight
12 kg
Innovation , Quality , Performance
AC 230/240/250V~50/60Hz
IM-5S
User Guide
WWW.BEGLEC.COM
IM-5W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM-5W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iSolution IM-5W

Summary of Contents for iSolution IM-5W

  • Page 1 Technical Specifications Power AC 120V~60Hz AC 230/240/250V~50/60Hz Fuse 20mm Glass T6.3A Fast Blow 20mm Glass T5A Fast Blow Lamp ELC 24V 250W Dimension 290mm x 330mm x 380mm Weight 12 kg IM-5S IM-5W User Guide Innovation , Quality , Performance WWW.BEGLEC.COM...
  • Page 2 7. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

  • Page 3: Table Of Contents

    G. If The pan belt is broken 1. Turn off the main power. 2. Unscrew all the screws (A) and open the base-housing cover (B). TABLE OF CONTENTS 3. Unplug all the connect wires (C) that from the arm to PC board and ignitor. 1.

  • Page 4: Safety Instruction

    1. Safety Instruction 6. Troubleshooting Please read carefully the instruction, which includes important information Following are a few common problems that may occur during operation. Here are about the installation, usage and maintenance. some suggestions for easy troubleshooting: WARNING ♦ Please keep this User Guide for future consultation.
  • Page 5 5.5 DMX512 Connection The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. Warning ♦ To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. ♦...

  • Page 6: Technical Specification

    2 glass and 1 effect gobos with shaking and shutter effect, Independent color wheel with 11 dichroic colors with rainbow effect. IM-5W Independent color wheel with 11 dichroic colors with rainbow effect and independent shutter & dimmer. 2.1 Beam Angel...

  • Page 7: Lamp

    2.Tilt position Function 3.Two-light strobe Please refer to Show mode 3.Dimmer IM-5W in 4.2 Main Function First set Master unit, then set Slave units’ 1. Always switch off the main supply and never handle the lamp or luminaries when is position hot.

  • Page 8: How To Set The Unit

    No need to turn the unit off when you change the DMX address, as new DMX address setting will be effected at once. Every time you turn the unit on, it will show IM-5S/IM-5W on the display and move all the motors to their ‘home’ position and you may hear some noises for about 20 seconds.
  • Page 9 4.2 Main Function Display Inversion To select any of the given functions, press the MENU button up to when the required one is It is good for you to install the unit on the floor or under ceiling. Press the MENU button up to showing on the display.
  • Page 10 Press the MENU button up to when the is showing on the display. Pressing Show Mode ENTER button and the display will blink. Use DOWN and UP button to select the Press the MENU button up to when the is showing on the display. Pressing ENTER (normal) or (split color) mode.

This manual is also suitable for:

Im-5s
