Technical Specifications
Power
AC 120V 60Hz
AC 230/240/250V 50/60Hz
Fuse
6X30mm Glass T15A
Lamps
J Type 120V 300W
J Type 230V 500W
360mm x 225mm x 150mm(i Color-3)
Dimension
450mm x 270mm x 175mm(i Color -4)
6 kg / 13.2 lbs(i Color -3)
Weight
7 kg / 15.4lbs(i Color -4)
User Guide
Innovation , Quality , Performance
Professional Entertainment Technology
Advertisement
Related Manuals for iSolution iColor 3
Summary of Contents for iSolution iColor 3
- Page 1 Technical Specifications Power AC 120V 60Hz AC 230/240/250V 50/60Hz Fuse 6X30mm Glass T15A Lamps J Type 120V 300W J Type 230V 500W 360mm x 225mm x 150mm(i Color-3) Dimension 450mm x 270mm x 175mm(i Color -4) 6 kg / 13.2 lbs(i Color -3) Weight 7 kg / 15.4lbs(i Color -4) User Guide...
-
Page 2: Fixture Cleaning
7. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. - Page 3 6. Troubleshooting Following are a few common problems that may occur and suggestions as to how to solve them. INDEX A. No light 1. General Instructions 1. Check the power on LED and fuse 2. Check the lamp if it is ok? (The lamp may turn off, when the unit is in blackout). 2.
- Page 4 1. Getting Instructions D. By universal DMX controller The following points are important for safety as well as for the smooth installation and If you use a universal DMX controller to control the units, you have to set dip switches performance of the unit.
-
Page 5: Main Features
C. By Colormix controller 2. Main Features Voltage：AC 120V 60Hz or 230/240/250V 50/60 Hz By link the Colormix controler to the unit , you have to use 3 pin XLR cable and use 5 • Bulb： J Type 230V 500W(Euro) pin XLR cable between Colormix controller and Colormix foot controller. - Page 6 4. DMX Link & Controls 5. How To Control The Unit Channel Dip switches setting You can operate the unit in four ways: Master A. By master/slave preprogrammed function By linking the units in master/slave connection, Slave 1 the first unit will control the other units to give an Slave 2 automatic activated synchronized light show.
