Operating Gemini Utilities

The Rimage Producer Software Suite includes an application called Gemini Utilities, which is
used to update the autoloader firmware. It may also be used to change the display name of the
Rimage DLN5200/DL5200 and to enable the beeper. The Rimage DLN5200 displays the
computer name on the operator panel. The computer name is helpful when identifying the
computer on the network.
Tip: To access Gemini Utilities on a DLN5200, use the remote desktop connection from a
networked PC, or connect a monitor, keyboard, and mouse to the DLN5200.

Starting Gemini Utilities

1. Close all applications.
2. In Rimage Service Manager, stop all Rimage
Services.
Note: Refer to your Rimage Software online
help for additional information.
3. Navigate: Start > Programs > Rimage > Utilities
> Gemini Utilities. Gemini Utilities opens.
Note: When the desired tasks
restart the Rimage Services.

Changing the autoloader display name

Use Gemini Utilities to enter the name displayed on the operator panel.
1. Select the Override Name checkbox.
2. Clear the Use Computer Name checkbox.
3. In the Display Name field, enter the new name.
4. Select Set DiscLab Params to save the settings.

Enabling the beeper

You can change the number of beeps that occur when there is an error.
1. In the # of Beeps on Fault field, select or enter the number of beeps you wish to hear when
there is an error.
Tip: Entering 0 (zero) in the # of Beeps on Fault field disables the beeper.
2. Select Set DiscLab Params to save the settings.

Stopping Gemini Utilities

Select Exit to close Gemini Transporter Utilities.
110768_E
are complete,
Maintain the DLN5200/DL5200
15
